SPLIT TYPE ROOM AIR CONDITIONER

INSTALLATION INSTRUCTION

SHEET
(PART NO. 9374747054)
IMPORTANT!
Please Read Before Starting
This air conditioning system meets strict safety and operating standards.
As the installer or service person, it is an important part of your job to
install or service the system so it operates safely and efficiently.
For safe installation and trouble-free operation, you must:
• Carefully read this instruction booklet before beginning.
• Follow each installation or repair step exactly as shown.
• Observe all local, state, and national electrical codes.
• Pay close attention to all danger, warning, and caution notices given in
this manual.
This symbol refers to a hazard or unsafe practice which
WARNING:
can result in severe personal injury or death.
This symbol refers to a hazard or unsafe practice which
can result in personal injury and the potential for product
CAUTION:
or property damage.
• Hazel alerting symbols
Electrical
Safety / alert
If Necessary, Get Help
These instructions are all you need for most installation sites and mainte-
nance conditions. If you require help for a special problem, contact our
sales/service outlet or your certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for improper installation
or maintenance service, including failure to follow the instructions in this
document.
SPECIAL PRECAUTIONS
When Wiring
ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL
INJURY OR DEATH. ONLY A QUALIFIED, EXPERIENCED
ELECTRICIAN SHOULD ATTEMPT TO WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and tubing are completed
or reconnected and checked.
• Highly dangerous electrical voltages are used in this system. Carefully
refer to the wiring diagram and these instructions when wiring. Improper
connections and inadequate grounding can cause accidental injury
or death.
• Ground the unit following local electrical codes.
• Connect all wiring tightly. Loose wiring may cause overheating at con-
nection points and a possible fire hazard.
When Transporting
Be careful when picking up and moving the indoor and outdoor units. Get
a partner to help, and bend your knees when lifting to reduce strain on
your back. Sharp edges or thin aluminum fins on the air conditioner can
cut your fingers.
When Installing...
...In a Ceiling or Wall
Make sure the ceiling/wall is strong enough to hold the unit's weight. It
may be necessary to construct a strong wood or metal frame to provide
added support.
...In a Room
Properly insulate any tubing run inside a room to prevent "sweating" that
can cause dripping and water damage to walls and floors.
...In Moist or Uneven Locations
Use a raised concrete pad or concrete blocks to provide a solid, level
foundation for the outdoor unit. This prevents water damage and abnor-
mal vibration.
...In an Area with High Winds
Securely anchor the outdoor unit down with bolts and a metal frame. Pro-
vide a suitable air baffle.
...In a Snowy Area (for Heat Pump-type Systems)
Install the outdoor unit on a raised platform that is higher than drifting
snow. Provide snow vents.
When Connecting Refrigerant Tubing
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces of the flare and
union tubes before connecting them, then tighten the nut with a torque
wrench for a leak-free connection.
• Check carefully for leaks before starting the test run.
NOTE:
Depending on the system type, liquid and gas lines may be either narrow
or wide. Therefore, to avoid confusion the refrigerant tubing for your par-
ticular model is specified as either "small" or "large" rather than as "liquid"
or "gas".
When Servicing
• Turn the power OFF at the main circuit breaker panel before opening
the unit to check or repair electrical parts and wiring.
• Keep your fingers and clothing away from any moving parts.
• Clean up the site after you finish, remembering to check that no metal
scraps or bits of wiring have been left inside the unit being serviced.
• After installation, explain correct operation to the customer, using the
operating manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR24DY3F and is the answer not in the manual?

Questions and answers

Summary of Contents for Friedrich MR24DY3F

  • Page 1: Installation Instruction

    SPLIT TYPE ROOM AIR CONDITIONER INSTALLATION INSTRUCTION SHEET (PART NO. 9374747054) IMPORTANT! When Transporting Be careful when picking up and moving the indoor and outdoor units. Get Please Read Before Starting a partner to help, and bend your knees when lifting to reduce strain on your back.
  • Page 2: Special Tools For R410A

    This air conditioner uses new refrigerant HFC (R410A). 5 cm or over The basic installation work procedures are the same as conventional refrigerant models. However, pay careful attention to the following points: (1) Since the working pressure is 1.6 times higher than that of conventional refrigerant models, some of the piping and installation and service tools are special.
  • Page 3: Type Of Copper Pipe And Insulation Material

    STANDARD ACCESSORIES GENERAL This INSTALLATION MANUAL briefly outlines where The following installation accessories are supplied. Use them as re- and how to install the air conditioning system. Please quired. read over the entire set of instructions for the indoor INDOOR UNIT ACCESSORIES and outdoor units and make sure all accessory parts Name and Shape Q’ty...
  • Page 4: Electrical Requirement

    INSTALLATION DIAGRAM OF ELECTRICAL REQUIREMENT INDOOR UNITS Always make the air conditioner power supply a special branch cir- cuit and provide a special switch and receptacle. Do not extend the power cord. Wall hook bracket 2" (5 cm) or over CAUTION 2-2/5"...
  • Page 5: Indoor Unit

    INDOOR UNIT CUTTING THE HOLE IN THE WALL FOR THE CONNECTING PIPING (1) Cut a 3-2/16" (80 mm) diameter hole in the wall at the position Center mark 3-2/16" (80 mm) shown in figure. dia. hole (2) When cutting the wall hole at the inside of the installation frame, cut the hole within the range of the left and right center Lower marks 3/8"...
  • Page 6: Connecting The Piping

    ● For left piping and left rear piping, align the marks on the wall hook bracket and shape the connection pipe. ● Bend the connection piping at a bend radius of 2 - 3/4" (70 mm) or more and install no more than 1- 3/8" (35 mm) from the wall. Connection pipe ●...
  • Page 7: How To Connect Wiring To The Terminals

    ELECTRICAL WIRING (INDOOR UNIT) HOW TO THE INSTALL THE INTER-UNIT WIRE HARNESS 1. Remove the screws, then remove the conduit holder. 2. Fasten the inter-unit wire harness to the conduit holder using the lock nut. 3. Use the screws to install the conduit holder with which Inter-unit wire har- ness is included.
  • Page 8: Front Panel Removal And Installation

    FINISHING Overlap the insulation (1) Insulate between pipes. ● For rear, right, and bottom piping, overlap the connection pipe heat insulation and indoor unit pipe heat insulation and bind Connection pipe Indoor unit pipe them with vinyl tape so that there is no gap. (heat insulation) (heat insulation) ●...
  • Page 9: Test Running

    TEST RUNNING ● Perform test operation and check items 1 and 2 below. 1. INDOOR UNIT ● For the operation method, refer to the operating manual. 1) Is operation of each button on the remote control unit ● The outdoor unit, may not operate, depending on the room normal? temperature.
  • Page 10: Air Cleaning Filter Installation

    AIR CLEANING FILTER INSTALLATION 1. Open the Intake Grille and remove the Air filters. (3) Engage the four fixing locations at the top and bottom of the air cleaning filter frame with the hooks of the air filter. Rear of the filter Air Filter (Right &...
