REVERSE OSMOSIS SYSTEMS OPERATING MANUAL MODELS: CP / WMXL / WXL / VXL / HXL / HXXL / X Water Tec International, Inc. Tucson, Arizona 85714 www.water-tec.com Water Tec Int’l. Inc. Version 02A... -
Page 2: Table Of Contents
This manual includes the most common components and installation specifications. Please keep in mind that Water Tec manufactures many units to customer specifications. If you do not find the information that you are looking for in this manual, please contact your local Water Tec dealer. -
Page 3: Iintroduction To Reverse Osmosis
To carry the rejected material away from the membrane surface, the feed side of the R.O. membrane is continually flushed with an excess flow, usually two to five times the product flow. T his avoids clogging of the membrane surface and reduces the tendency toward scale formation. Water Tec Int’l. Inc. Version 02A... -
Page 4: Factors That Affect The Useful Life Of A Membrane
100 gallons of feed water into the membrane and you produce 60 gallons of product water and 40 gallons of reject water, this is known as 60% recovery. PERCENT REJECTION The amount of salts or chemicals rejected by the R.O. membranes. Water Tec Int’l. Inc. Version 02A... - Page 5 When the feed water is entering at 500 PPM, the product water would be from 25-50 PPM (90-95% rejection of dissolved minerals). Usually a conductivity meter or “total dissolved solids” meter is used to measure the mineral content of the product water. Water Tec Int’l. Inc. Version 02A...
-
Page 6: Purified Water Storage And Delivery
The pumps must never be allowed to run dry, since this will rapidly deteriorate the shaft seal and cause the seal to leak. To prevent this the storage tank should be fitted with a low level switch, which shuts down the distribution pump if the water level in the tank gets dangerously low. Water Tec Int’l. Inc. Version 02A... -
Page 7: Reverse Osmosis Component Identification
Horizontally on the back of a compact unit / Vertically on the front of a fiberglass wall mount unit / Horizontally on the front of a metal wall mount unit / Vertically on the side(s) of the vertical frame unit / Horizontally on the back of the horizontal frame unit. Water Tec Int’l. Inc. Version 02A... - Page 8 This is an option for units smaller than 30,000 GPD, and larger then 1500 GPD. All X frame units include a dual switch to read the pre-membrane TDS and the post-membrane TDS. Water Tec Int’l. Inc. Version 02A...
- Page 9 This is a normally closed electric ball valve. This valve is located on the feed side of the pressure pump. Its purpose is to shut off the feed supply when the unit is in the non-operating mode. If electric power should fail this valve will not close. Water Tec Int’l. Inc. Version 02A...
-
Page 10: General System Diagrams
GENERAL SYSTEM DIAGRAMS (CP) 9&10 1. Incoming Feed Water 2. #10 PS05-10 Pre-Filter 3. #10 C1 Pre-Filter 4. #10 CB10-10 Pre-Filter 5. Recycle Needle Valve Water Tec Int’l. Inc. Version 02A... -
Page 11: The Wall Mount F.g. Ro (Wm)
2a 2b 2c 2d * This photo is shown with options. 6 12 5. Rotary Vane Pump . Incoming Feed Water (Pre-Filter supplied, but not shown) 2a:On/Off Switch 2. Electrical Control Box 2b:Power On Indicator Water Tec Int’l. Inc. Version 02A... - Page 12 3c. Incoming Pressure Gauge 2b. Power On Indicator 3d. System Pressure Gauge 2c. Low Pressure Indicator 3e. Recycle Control Valve 2d. 5amp Fuse 3f. Waste Control Valve 2e. OPTION: Digital TDS Meter 4. Single Cartridge Pre-Filter Water Tec Int’l. Inc. Version 02A...
- Page 13 5b. System Pressure Gauge 3b. Power On Indicator 5c. Waste Control Valve 3c. Low Pressure Indicator 5d. Recycle Control Valve 3d. 5amp Fuse 5e. Concentrate Flow Meter 5f. Permeate Flow Meter 4. High Pressure Pump and Solenoid Water Tec Int’l. Inc. Version 02A...
-
Page 14: The Horizontal Ro (Hxxl)
4f. Waste Control Valve 3b. Power On Indicator 3c. Low Pressure Indicator 5. High Pressure Pump and Solenoid 3d. 5amp Fuse 6. Module-R.O. Membrane & Housing Control Panel The HXXL frame has 80” housings Water Tec Int’l. Inc. Version 02A... -
Page 15: The Horizontal Ro (X)
7g. Low Pressure 10. Concentrate Valve 7h. Over Pressure 11. Fast Flush Ball Valve (OPTIONAL) 7i. Fast Flush 12. Chemical Tank (OPTIONAL) 7j. Cleaning (option) 13. Module – Membranes and Housing 14. Powder Coated Steel Frame Water Tec Int’l. Inc. Version 02A... -
Page 16: Reverse Osmosis Set-Up Specifications
Electrical Connections and Voltages All CP and WM Series standard units are 110v/60hz. They have a standard 110v 3 prong plug. WMXL, VXL, and HXL Series units are available in 110v/60hz or 220v/60hz (single or three phase). Please check your electrical requirements carefully. -
Page 17: Start -Up
After about 30 minutes the incoming and product water should be tested with a TDS Meter. There should be no less than a 90% rejection. If the rejection is lower than 90% double check the membrane installation and Water Tec Int’l. Inc. Version 02A... -
Page 18: Membrane Installation
MEMBRANE INSTALLATION Ideal Installation The brine seal should always be installed on the same side as the incoming water. Flow Note the direction of the brine seal. Incorrect Installation Acceptable Installation Flow Flow Water Tec Int’l. Inc. Version 02A... -
Page 19: Trouble Shooting Guide
Water temperature may be low Check High TDS in permeate water TDS monitor or probe Check / adjust / replace Low pump pressure Check / adjust Membranes may be clogged / dirty Check / clean / replace Water Tec Int’l. Inc. Version 02A... -
Page 20: Reverse Osmosis Pre-Treatment
Fouling and scaling on the membrane is one of the main reasons a water softener is recommended before an R.O. It is always best to use a twin alternating unit in order to ensure continuous soft water. Water Tec Int’l. Inc. Version 02A...
