2015 Pioneer AV Receivers
Audio Technologies
• MCACC Auto Room Tuning
- Phase Control
• Advanced MCACC Auto Room Tuning
- Auto Phase Control Plus
- Speaker Polarity Check
- Standing Wave Control
- Subwoofer EQ
• MCACC Pro Auto Room Tuning
- Independent Dual Subwoofer Output
- Full Band Phase Control
- Bass Management System for Dolby Atmos Enabled Speakers
• Advanced Sound Retriever
• Auto Sound Retriever
• Auto Sound Retriever for ARC
• Sound Retriever AIR
• Sound Retriever Link
• Auto Level Control
• Hi-bit24 Audio Processing
• SABRE™ Premier Audio DAC
Video Technologies
• Video Scaler (1080p to 4K) with Super Resolution
• Ultra HD (4K/60p/4:4:4/24-bit) Pass-Through with HDCP 2.2
• Deep Color
• "x.v.Color"
Audio Formats & Licenses
®
• Dolby Atmos
• Dolby TrueHD
• Dolby TrueHD Loudness Management
• DTS-HD Master Audio
• DTS-HD
• Hi-Res Audio File Playback via USB/Network
• Multi-Channel Audio File Playback via USB/Network
• Various Music File Playback via USB/Network/HDMI
• Variable File Play Action
• Gapless Playback
Sophisticated Surround System
• 7ch Speaker Configurations
• Virtual Speakers
• Advanced Surround Modes
• Front Stage Surround Advance
Connectivity
®
• HDMI
(4K/60p, 3D, ARC)
• Made for iPod and iPhone
• iPod Digital Transmission via Front USB
• Android™ Audio/Video Playback with MHL™
• Front USB Input
Network Features
• Apple AirPlay Certified
• DLNA Certified™ (1.5)
• HTC Connect™ Certified
• Compatible with Windows
®
8.1
®
• Pandora
Internet Radio
®
• Spotify
Digital Music-Streaming Service Ready
• Internet Radio (vTuner)
• Built-in Dual Band Wi-Fi
• Built-in Bluetooth Wireless Technology
Advanced Control
• Ready for Start-up Navi App
• Built-in AVNavigator
• Ready for iControlAV5 App
• Powered HDMI ZONE Out (Powered HDZONE)
• Standby Pass-Through without CEC
• Auto Power Down
• Power Save for HDMI Standby Through
* New features in blue
Applicable models displayed in icons:
VSX-1130-K
1130
VSX-830-K
830
VSX-530-K
530
AV RECEIVERS REFERENCE GUIDE
For North America

Advertisement

Table of Contents
loading

Related Manuals for Pioneer VSX-1130-K

Summary of Contents for Pioneer VSX-1130-K

  • Page 1 AV RECEIVERS REFERENCE GUIDE 2015 Pioneer AV Receivers Audio Technologies Connectivity ® • MCACC Auto Room Tuning • HDMI (4K/60p, 3D, ARC) - Phase Control • Made for iPod and iPhone • Advanced MCACC Auto Room Tuning • iPod Digital Transmission via Front USB - Auto Phase Control Plus •...

  • Page 2: Mcacc Auto Room Tuning

    Level Level signals compared to the main channel signals. As a result, the delayed bass makes the sound lack synchronization. Pioneer’s Phase Control technology effectively eliminates phase lag and significantly improves the multi-channel sound without any extra operation. Time (msec)

  • Page 3: Mcacc Pro Auto Room Tuning

    Auditory sound components to the subwoofer. This optimal signal image distribution creates superior sound localization, maximizing the advantage of Dolby Atmos content. Pioneer Mid-High 80 Hz 180 Hz Bass With New Bass Management System for...

  • Page 4: Sound Retriever Air/Link

    Auto Sound Retriever definition, the audio quality is not as high since they are compressed with various bit rates. By applying Pioneer’s Auto Sound Retriever feature to TV broadcast signals, it adjusts the effects according to the bit rate transferred via HDMI’s ARC (Audio Return Channel), letting you enjoy digital TV broadcast in high-definition sound via Pioneer AV receiver.

  • Page 5: Auto Level Control

    Audio Technologies AV RECEIVERS REFERENCE GUIDE Auto Level Control Auto Level Control for Multi Surround Playback 1130 Music Hi-Def Movie Auto Level Control equalizes volume level differences between tracks when playing music Satellite/Cable Radio from an iPod or other sources. Track 1 Track 2 Track 3...

  • Page 6: Video Scaler With Super Resolution

    Deep Color 4K/60p/4:4:4 4K/60p/4:2:0 1130 * For illustration purpose only Pioneer AV receivers support 36-bit Deep Color, featuring smooth gradation steps with more accurate precision of brightness and color information, resulting in superbly detailed, natural color. “x.v.Color” 36-bit Deep Color Image...
  • Page 7 This theater sound experience can be reproduced in your home with Pioneer’s Dolby Atmos AV receiver, which not only decodes Dolby Atmos, but also reproduces Dolby Atmos in an ideal sound stage fine-tuned by MCACC Pro.
  • Page 8 * For VSX-1130-K only ** DLNA compatible server or NAS capable of DSD streaming required This logo is used for Pioneer products capable of 96 kHz/24-bit or above WAV/FLAC file playback, and Pioneer amplifiers, speakers, or headphones supporting over 40 kHz high-frequency reproduction, designed to derive maximum performance from Hi-Resolution Audio.
  • Page 9 2 ch * MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson Multimedia ** For VSX-1130-K only. Via wired network up to 96 kHz, and via wireless network up to 48 kHz *** For VSX-1130-K only Variable File Play Action...
  • Page 10 Sophisticated Surround System AV RECEIVERS REFERENCE GUIDE 7ch Speaker Configurations 1130 With speaker terminals for 9 channels, various speaker layouts are available to suit your taste or usage patterns. New configurations have been added to provide optimum performance for Dolby Atmos playback. [A] 7.2-channel Surround System (Top Middle/Surround Back) Connection [B] 7.2-channel Surround System (Surround Back/Front Wide) Connection Simultaneous output from top middle and surround back speakers not available.

  • Page 11: Advanced Surround Modes

    Virtual Height If you want to experience vertically falling sound but can not place front height speakers, there’s a perfect solution. Pioneer’s Virtual Height mode (Fig. 2) creates a height sound image without front height speakers, letting you enjoy enveloping virtual 7.1-channel sound from 5.1-channel speaker settings.
  • Page 12 You can also view JPEG* pictures or watch a slideshow along with the music stored on the USB memory. * JPEG playback/slideshow not available for VSX-530-K, and not available in sub zone for VSX-1130-K/VSX-830-K. For slideshows, select music files up to 48 kHz.

  • Page 13: Apple Airplay Certified

    Example: TV, stereo/home theater, game console Example: TV, AV receiver, remote speakers HTC Connect™ Certified 1130 Pioneer is the first leading partner to provide HTC Connect certified devices. Through wireless transmission, HTC Connect lets you easily stream high-quality audio from compatible devices such as...

  • Page 14: Pandora ® Internet Radio

    You can even add broadcast stations unavailable on the vTuner list. Access the Pioneer internet radio site from your PC/ Mac*, and register the desired stations to your favorites list. Then, you can easily tune in to the radio stations from the AV receiver.

  • Page 15: Ready For Start-Up Navi App

    AVNavigator Top Menu Built-in AVNavigator 1130 Pioneer’s AVNavigator is a user-friendly support feature for the AV receiver’s wiring and operation, including the Wiring Navi and Interactive Operation Guide*. AVNavigator is now built-in, and you can easily set up the AV receiver straight out of the box on your PC/Mac/iPad/smartphone.
  • Page 16 1130 iControlAV5 is an iPod touch, iPhone and iPad application developed by Pioneer, freely downloadable from the App Store. It is also compatible with Android, and available from Google Play. On a simple and intuitive interface, the application allows you to use your device as a remote for operating the AV receiver’s...
  • Page 17 Advanced Control AV RECEIVERS REFERENCE GUIDE ECO MANAGER ECO MANAGER for iPhone 1130 The feature is a dedicated page for energy efficient settings (During Playback/At Stand-By/ When Not in Use) on your AV receiver. You can select ECO Mode 1 or 2 for playback settings. ECO Mode 1 features moderate energy saving operation while maintaining high-quality sound, ideal for CD music, 2ch audio files, and internet radio.

  • Page 18: Auto Power Down

    Advanced Control AV RECEIVERS REFERENCE GUIDE Powered HDMI ZONE Out (Powered HDZONE) Powered HDMI ZONE 1130 Zone A Zone B The AV receiver is equipped with HDZONE HDMI output terminal, for streaming HD audio/video content to a separate room. If unused for HDZONE, the terminal can be used for MAIN Speaker Cable ZONE OUT 2.

  • Page 19: Feature Comparison

    AV RECEIVERS REFERENCE GUIDE Feature Comparison VSX-1130-K VSX-830-K VSX-530-K Audio Technologies MCACC Auto Room Tuning • (Pro) • (Advanced) Phase Control • • • Auto Phase Control Plus • • Speaker Polarity Check • • Standing Wave Control • •...
  • Page 20 Product Sheet VSX-1130-K/CUXESM VSX-830-K/CUXESM VSX-530-K/CUXEVSM...

  • Page 21: Audio Features

    VSX-1130-K 7.2-Channel AV Receiver with Dolby Atmos , Ultra HD Pass-through with HDCP 2.2, High- ® Resolution Audio Playback, Subwoofer EQ, Dual Subwoofer Preout, Built-in Bluetooth ® Wireless Technology and Wi-Fi , and Spotify Ready ® ® Amplification › Video Scaler (1080p to 4K) with Super Resolution Home Network Features ›...

  • Page 22: Rear Terminals

    Apple performance standards. Apple is not responsible for the op- Phase Control is a trademark placed on a product with Pioneer’s Phase Control Technol- eration of this device or its compliance with safety and regulatory standards. Please note ogy concept.
  • Page 23 VSX-830-K 5.2-Channel AV Receiver with Ultra HD Pass-through with HDCP 2.2, High-Resolution Audio Playback, Subwoofer EQ, Dual Subwoofer Preout, Built-in Bluetooth Wireless ® Technology and Wi-Fi , and Spotify Ready ® ® Amplification Video Features › Channels: 5 › HDMI 6 in/1 out ›...
  • Page 24 Phase Control is a trademark placed on a product with Pioneer’s Phase Control Technol- the developer to meet Apple performance standards. Apple is not responsible for the op- ogy concept.

  • Page 25: Wireless Technology

    › Digital Core Engine with Texas Instruments Aureus™ DSP › 192 kHz/24-bit DAC › HDMI Audio Return Channel (ARC) › Phase Control › Pioneer Sound Enhancements • Advanced Sound Retriever (2ch) • Auto Level Control (2ch) • Midnight Listening Mode •...
  • Page 26 CSR plc or one of its group companies and may be registered in one or more jurisdictions. Phase Control is a trademark placed on a product with Pioneer’s Phase Control Technol- ogy concept. The technology enables high-grade sound reproduction environment by improving the phase matching for each of the components.
