Congratulations on your purchase of Simmons' SDPC1 Pro Click Metronome. It is recommended that
you read this manual once through to get a feel for the unit, and refer to back to it when necessary.

Operation Overview

The SDPC1 Pro Click Metronome is a powerful rhythm producer, capable of creating a wide range of
sounds and tempos for the professional drummer. Here are its specific functions:
• Tempo: 30-280 BPM
• Beat: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
• Rhythm Types:
• Main Volume: Controlled via the Master Volume knob.
• Main Rhythm: Controlled via several Rhythm knobs.
• Timbres: Metro1 and Metro2 each have preset timbres, while Metro3 (in advanced mode) gives you
the option of programming your own timbre from 10 unique options.
• Two LED lights: Each light shows a red color for an accented beat, or green color for all other beats.
• Metronome: Audible via clicks or human voice.
• Timer Function: Lasts for up to 90 minutes. When the time has expired, the LED turns red and the speaker
will beep for one minute; press the [START/TAP] button to stop.
• [START/TAP] button: Starts/stops the metronome.
• Remote Control Function: Starts/stops the metronome by using a remote control pedal linked to the
remote control jack. The pedal acts as the [START/TAP] button.
• Sound Signal: After connecting to a Line Out jack, the sound signal can now be sent to an amplifier.
• Tap Tempo Function: Tap the [START/TAP] button while in your tempo, as the tempo of your tapping
will reveal itself in the LCD Display. Tempo ranges from 30-280 beats/min.
• Variation Function: Set up to four sections of rhythm variation, freeing up the beat, tempo, and bars in
each section. Press the [START/TAP] button to begin the sequence demonstration.
• Programming Function: You can program/store your own rhythm by setting a beat, tempo, and timbre
(while Prog00 is a fixed rhythm, Progs1-31 are available).
www.simmonsdrums.net
SDPC1
Pro Click Metronome
PRO CLICK
SDPC1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDPC1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Simmons SDPC1

  • Page 1 PRO CLICK SDPC1 Operation Overview The SDPC1 Pro Click Metronome is a powerful rhythm producer, capable of creating a wide range of sounds and tempos for the professional drummer. Here are its specific functions: • Tempo: 30-280 BPM • Beat: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9 •...
  • Page 2: Operating Instructions

    Pro Click Operating Instructions Powering The Unit Toggle the power switch to ON to turn on, and OFF to turn off. If “BAT” flashes during battery use, the power is insufficient for proper use. If “BAT” is displayed (without flashing) the power is low. Consequently, if “BAT” does not display, power is sufficient for use.
  • Page 3: Miscellaneous Functions

    Metronome Normal Mode Functions • [MODE] button: Chooses Metro1, Metro2, Metro3 and Tap. Metro1 and Metro2 are fixed sets of timbre, while Metro3’s timbre can be set by the user. Tap is used to measure the tap tempo. • [BEAT] button: Changes beat types. •...
  • Page 4: Advanced Mode

    Simmons® products. This guarantee gives you specific legal rights. You may have other legal rights which vary from state to state.
