Chr. Ward C3 Malvern mk II Owner's Handbook Manual

Hide thumbs Also See for C3 Malvern mk II:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
C3 MALVERN CHRONOGRAPH MK II
O W N e r ' s
H a N d b O O K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C3 Malvern mk II and is the answer not in the manual?

Questions and answers

Related Manuals for Chr. Ward C3 Malvern mk II

Summary of Contents for Chr. Ward C3 Malvern mk II

  • Page 1 C3 MALVERN CHRONOGRAPH MK II O W N e r ’ s H a N d b O O K...

  • Page 2: Table Of Contents

    InTroduCTIon TIme on Your sIde... Your Christopher Ward watch has been designed ConTenTs and engineered by highly talented craftspeople to ensure not only accurate and precise timekeeping but also to bring a real pride of ownership that C3 malvern Chronograph mk II 2–3 only luxury items of the highest quality can ever TeChnICal InformaTIon...

  • Page 3: C3 Malvern Chronograph Mk Ii

    C3 malvern mk II C3 malvern Chronograph mk II The original C3 malvern Chronograph was inspired by the dashboard dials of a classic Aston Martin and reflects the quiet understatement of english design. seven years on from its appearance as Christopher Ward’s first offering, the Malvern...

  • Page 5: Technical Information

    C3 Malvern Mk II TeCHnICal InFOrMaTIOn Features technical inFormation – Swiss made Diameter: 39mm Height: 10.2mm – Quartz chronograph movement Calibre: ronda 5040.D – 1/10th second split timing function Case: 316l Stainless steel – Hand-finished 316l stainless steel case Water resistance: 5 aTM (50 metres) –...

  • Page 7: How To Operate Your C3 Malvern Chronograph

    hoW To operaTe Your C3 malvern Chronograph...
  • Page 8 hoW To operaTe Your C3 malvern Chronograph dIsplaY and ConTrol buTTons Display elements control buttons second hand minute hand push-button a hour hand Crown minute counter Centre stop-second push-button b 1/10 second counter (hour counter after 30 seconds) date window...

  • Page 9: Setting The Time

    hoW To operaTe Your C3 malvern Chronograph seTTIng The TIme for a superior water resistance your crown is of the screw-in type. To get to position turn the crown anti-clockwise until it releases itself. • pull out the crown to position (the watch stops).
  • Page 10 hoW To operaTe Your C3 malvern Chronograph seTTIng daTe (QuICk mode) • pull out the crown to position (the watch continues to run). • Turn the crown clockwise until the correct date appears. • pull the crown to position push the crown back into position until flush with the case and screw in.
  • Page 11 hoW To operaTe Your C3 malvern Chronograph seTTIng The daTe/TIme Example: date / time on the watch: 17th / 01.25 hr present date / time: 4th / 20.30 hr • pull out the crown to position (the watch continues to run). •...
  • Page 12 hoW To operaTe Your C3 malvern Chronograph • pull out the crown to position (the watch stops). • Turn the crown clockwise until the correct date ie. 4th appears (after passing through midnight). • Continue to turn the crown until the correct time 20.30 hr appears.

  • Page 13: Control Buttons

    hoW To operaTe Your C3 malvern Chronograph Chronograph funCTIons: Display elements control buttons push-button a (start / stop) minute counter Centre stop-second 1/10 second counter push-button b (hour counter after 30 seconds) (reset) • The minute counter measures please noTe: before using the chronograph 30 minutes per rotation.

  • Page 14: Basic Functions

    hoW To operaTe Your C3 malvern Chronograph basIC funCTIons (start / stop / reset) push-button a Example: Start: press push-button A. Stop: to stop the timing, press push-button A once more and read the 3 chronograph counters: 4 min / 38 sec / 7⁄10 sec. Zero positioning: press push-button B.
  • Page 15 hoW To operaTe Your C3 malvern Chronograph aCCumulaTed TImIng push-button a Example: Start: (start timing). Stop: (e.g. 15 min 5 sec following Restart: (timing is resumed). Stop: (e.g. 13 min 5 sec following = 28 min 10 sec (accumulated measured time is shown) Reset: The 3 chronograph hands are returned to their zero positions.
  • Page 16 hoW To operaTe Your C3 malvern Chronograph InTermedIaTe or InTerval TImIng push-button a Example: Start: (start timing). Display interval: e.g. 10 minutes 10 seconds (timing continues in the background). Making up the measured time: (the 3 chronograph hands are quickly advanced to the ongoing measured time).
  • Page 17 hoW To operaTe Your C3 malvern Chronograph adjusTIng Chronograph hands To zero posITIon Example: one or several chronograph hands are not in their correct zero positions and have to be adjusted (e.g. following a battery change). • pull out the crown to position (all three chronograph hands are in their correct or incorrect zero position).
  • Page 18 hoW To operaTe Your C3 malvern Chronograph adjusTIng Chronograph hands To zero posITIon Adjusting the centre stop second single step 1 x short Continuous long When correct press button B to set. Corrective mode for the 1/10 second counter is now activated. Adjusting the 1/10 second counter hand (position 6h) single step 1 x short...

  • Page 20: Water Resistance

    hoW To operaTe Your C3 malvern Chronograph WaTer resIsTanCe 1 ATM (10 metres) safe to wear your watch while washing your hands with tap water. although your watch has been through vigorous 3 ATM (30 metres) static pressure testing, it is worth remembering Washing your car and/or general that there are many variables that can affect hose pipe usage.
  • Page 21 hoW To operaTe Your C3 malvern Chronograph sTraps & braCeleTs as you would expect, we place as much Similarly, we only use the finest metals in the emphasis on the quality of our straps and construction of our bracelets, all of which bracelets as we do our watches.
  • Page 22 hoW To operaTe Your C3 malvern Chronograph bracelet With micro-aDJustment 1. press to release micro adjust 2. expand adjustment 3. adjust pin position 4. Close the clasp DiVer’s eXtension (Where applicable) 1. press to release press diver’s extension 2. expand adjustment 3.

  • Page 23: The Watch Care Programme

    our WaTCh Care programme Your watch is constructed from the finest components and materials available including one of Switzerland’s finest quartz movements. As with all watches of this quality, with the right care and attention, your new Christopher Ward watch has the potential to become an heirloom piece giving further joy to future generations.
  • Page 24 our WaTCh Care programme 60/60 GUARANTEE Christopher Ward’s 60/60 Guarantee is designed to deliver you complete peace 1. 60 Day Free returns of mind and the best support possible our success depends on you being completely happy with throughout the lifetime of your ownership. your new Christopher Ward watch.

  • Page 25: General Information

    general InformaTIon keepIng In TouCh WITh ChrIsTopher Ward from small beginnings just a few short years ago as the owner of a Christopher Ward watch, (our first workshop was actually a refurbished if ever you need to get hold of us we are at chicken shed!), Christopher Ward has won a your service.
  • Page 26 Head Office Christopher Ward (London) Limited, 1 Park Street, Maidenhead, Berkshire SL6 1SL United Kingdom +44 (0)1628 763040 custOmer services +44 (0)844 875 1515 United KingdoM: 1.877.226.8224 United StateS of aMeriCa: customerservices@christopherward.co.uk technical@christopherward.co.uk Website www.christopherward.co.uk www.christopherward-usa.com...
