Chr. Ward C7 RAPIDE CHRONOGRAPH MK II Owner's Handbook Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

C7 RAPIDE CHRONOGRAPH MK II
O W N e r ' s
H a N d b O O K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C7 RAPIDE CHRONOGRAPH MK II and is the answer not in the manual?

Questions and answers

Related Manuals for Chr. Ward C7 RAPIDE CHRONOGRAPH MK II

Summary of Contents for Chr. Ward C7 RAPIDE CHRONOGRAPH MK II

  • Page 1 C7 RAPIDE CHRONOGRAPH MK II O W N e r ’ s H a N d b O O K...
  • Page 2 InTroduCTIon TIme on Your sIde... Your Christopher Ward watch has been designed ConTenTs and engineered by highly talented craftspeople to ensure not only accurate and precise timekeeping but also to bring a real pride of C7 rAPIde CHronoGrAPH mK II 2–3 ownership that only luxury items of the highest quality can ever hope to deliver.
  • Page 3 C7 mark II honours, this is a watch that represents the pinnacle of achievement and accuracy in a chosen field. Far Left; C7 Rapide Chronograph Mark I Left/Right; C7 Rapide Chronograph MK II...

  • Page 5: Technical Information

    C7 rAPIde CHronoGrAPH TeCHnICAl InformATIon FEATUREs TEChnICAl InFoRMATIon – swiss made diameter: 42mm Height: 10.7mm – Quartz chronograph movement Calibre: ronda 3540.d – 1/10ths second split timing Case: 316l stainless steel – 316l stainless steel case Water resistance: 10 ATm (100 metres) –...

  • Page 7: Operating Instructions

    oPerATInG InsTruCTIons...
  • Page 8 oPerATInG InsTruCTIons dIsPlAY And ConTrol buTTons DIsplAy ElEMEnTs ConTRol bUTTons minute Hand Tenths counter Push-button A Hour hand Crown minutes counter seconds hand Push-button b Centre stop-second date Window...

  • Page 9: Setting The Time

    oPerATInG InsTruCTIons seTTInG THe TIme for a superior water resistance your crown is of the screw-in type. To get to position turn the crown anti-clockwise until it releases itself. • Pull out the crown to position (the watch stops). • Turn the crown until you reach the correct time e.g.
  • Page 10 oPerATInG InsTruCTIons seTTInG dATe (QuICK mode) • Pull out the crown to position (the watch continues to run). • Turn the crown anti-clockwise until the correct date appears. • Push the crown back into position until flush with the case and screw in. PleAse noTe: The date can not be changed during the date changing phase between 20.00 hrs and 02.00 hrs as the watch gearing...
  • Page 11 oPerATInG InsTruCTIons CHronoGrAPH funCTIons: DIsplAy ElEMEnTs ConTRol bUTTons Tenths Push-button A (start / stop) minutes Centre stop-second seconds Push-button b (reset) • The minute counter measures PleAse noTe: before using the chronograph 30 minutes per rotation. functions, please ensure that: •...

  • Page 12: Basic Functions

    oPerATInG InsTruCTIons bAsIC funCTIons Push-button A (sTART / sTop / REsET) Example: Start: Press push-button A. Stop: to stop the timing, press push-button A once more and read the 3 chronograph counters: 4 min / 38 sec / 7⁄10 sec. Zero positioning: Press push-button B.
  • Page 13 oPerATInG InsTruCTIons ACCumulATed TImInG Push-button A Example: Start: (start timing). Stop: (e.g. 15 min 5 sec following Restart: (timing is resumed). Stop: (e.g. 13 min 5 sec following = 28 min 10 sec (accumulated measured time is shown) Reset: The 3 chronograph hands are returned to their zero positions.
  • Page 14 oPerATInG InsTruCTIons InTermedIATe or InTervAl TImInG Push-button A Example: Start: (start timing). Display interval: e.g. 10 minutes 10 seconds (timing continues in the background). Making up the measured time: (the 3 chronograph hands are quickly advanced to the ongoing measured time). Stop: (final time is displayed).
  • Page 15 oPerATInG InsTruCTIons AdjusTInG CHronoGrAPH HAnds To zero PosITIon Example: one or several chronograph hands are not in their correct zero positions and have to be adjusted (e.g. following a battery change). • Pull out the crown to position (all three chronograph hands are in their correct or incorrect zero position).
  • Page 16 oPerATInG InsTruCTIons AdjusTInG CHronoGrAPH HAnds To zero PosITIon Adjusting the centre stop second single step 1 x short Continuous long When correct press button B to set. Corrective mode for the 1/10 second counter is now activated. Adjusting the 1/10 second counter hand (position 12h) single step 1 x short Continuous...
  • Page 17 oPerATInG InsTruCTIons usInG THe TACHYmeTrIC sCAle To CAlCulATe sPeed Example: calculating the speed of a race car over the course of a mile. record the time the race car takes to cover a known distance of 1 mile. read off the speed on the tachymetric scale indicated by the central seconds hand.

  • Page 19: Water Resistance

    oPerATInG InsTruCTIons WATer resIsTAnCe 1 ATM (10 METREs) safe to wear your watch while washing your hands with tap water. Although your watch has been through vigorous 3 ATM (30 METREs) static pressure testing, it is worth remembering Washing your car and/or general that there are many variables that can affect hose pipe usage.
  • Page 21 oPerATInG InsTruCTIons sTrAPs & brACeleTs As you would expect, we place as much Similarly, we only use the finest metals in the emphasis on the quality of our straps and construction of our bracelets, all of which bracelets as we do our watches. We only use are precision engineered for durability, the finest leathers for our straps and our efficiency and comfort.

  • Page 22: Operating Instructions

    oPerATInG InsTruCTIons bRACElET WITh MICRo-ADJUsTMEnT 1. Press to release micro Adjust 2. expand adjustment 3. Adjust pin position 4. Close the clasp DIVER’s EXTEnsIon (WhERE ApplICAblE) 1. Press to release Press diver’s extension 2. expand adjustment 3. Adjust pin position 4.

  • Page 23: Programme

    THe CW360 WATCH CAre ProGrAmme Your watch is constructed from the finest components and materials available including one of switzerland’s finest quartz movements. As with all watches of this quality, with the right care and attention, your new Christopher Ward watch has the potential to become an heirloom piece giving further joy to future generations.

  • Page 24: Programme

    THe CW360 WATCH CAre ProGrAmme Christopher Ward’s CW360 Watch 60 DAy FREE RETURns Care Programme is designed to our success depends on you being completely happy with your new Christopher Ward watch. If for any reason you aren’t, you have deliver you complete peace of up to 60 days to return your watch, absolutely free of charge, mind and the best support possible...

  • Page 25: General Information

    GenerAl InformATIon KeePInG In TouCH WITH CHrIsToPHer WArd from small beginnings just a few short years ago your service. We have listed some useful contact (our first workshop was actually a refurbished details on the back cover. chicken shed!), Christopher Ward has won a There is also always something new going on worldwide following for his eponymous watch at our website at www.christopherward.co.uk...
  • Page 26 Cer t ifiCate o f aU tH ent iC i tY MODEL SERIAL NUMBER DATE CHECKED christopherward.co.uk Christopher Ward (London) Limited, 1 Park Street, Maidenhead Berkshire SL6 iSL United Kingdom...
  • Page 27 Head Office Christopher Ward (London) Limited, 1 Park Street, Maidenhead, Berkshire SL6 1SL United Kingdom +44 (0)1628 763040 custOmer services +44 (0)844 875 1515 United KingdoM: 1.877.226.8224 United StateS of aMeriCa: customerservices@christopherward.co.uk technical@christopherward.co.uk Website www.christopherward.co.uk www.christopherward-usa.com...
