TP-MS308/TP-MS316/TP-MS324
Power Source Equipment
(AC+DC Input, Gigabit PoE Midspan)
USER'S MANUAL
TYCON POWER SYSTEMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP-MS308 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tycon Power Systems TP-MS308

Summary of Contents for Tycon Power Systems TP-MS308

  • Page 1 TP-MS308/TP-MS316/TP-MS324 Power Source Equipment (AC+DC Input, Gigabit PoE Midspan) USER’S MANUAL TYCON POWER SYSTEMS...

  • Page 2: Table Of Contents

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Contents 1. Introduction................Features....................Package Contents................. 2. Hardware Description............Physical Dimension................Front Panel.................... LED Indicators..................Rear Panel.................... Power On....................Network Application................RJ-45 Remote Control Port..............3. Software Utility Installation..........4. GUI Management..............Display and Illustration................System Login..................

  • Page 3: Introduction

    User’s Manual TP-MS308/TP-MS316/TP-MS324 1. Introduction Mstronic’s family of Power over Ethernet TP-MS308/TP-MS316/TP-MS324 ( Power Sourcing Equipment ), is an AC+DC input, gigabit PoE Midspan which injects power over data-carrying Ethernet cabling. The TP-MS308/TP-MS316/TP-MS324, support 8, 16 and 24 ports respectively in a 10/100/1000BaseT Ethernet network, over TIA/EIA-568 Category 5/5e/6 cabling.

  • Page 4: Package Contents

    This Section mainly describes the hardware of the TP-MS308/TP-MS316/TP-MS324 and gives a physical and functional overview. Physical Dimension TP-MS308/TP-MS316/TP-MS324 physical dimension is: 430mm x 290mm x 44mm (Lx W x H) (1U,19” or 23” Rack mountable) Front Panel Figure 2-1. The Front panel of TP-MS308/TP-MS316/TP-MS324...

  • Page 5: Led Indicators

    User’s Manual TP-MS308/TP-MS316/TP-MS324 LED Indicators The LED Indicators gives real-time information of systematic operation status. The following table provides descriptions of LED status and their meaning. Status Color Description A network device is detected(10/100/1000 Mbps) Green but no communication activity is...

  • Page 6: Rear Panel

    Figure 2-2. The Rear Panel of TP-MS308/TP-MS316/TP-MS324 The AC inlet, DC input terminal and 2 Ventilation fan are located at the rear panel of the TP-MS308/TP-MS316/TP-MS324. The device will work with AC in the range 100-240V AC, 50-60Hz. Or work with DC -48V(-42V~-57V).

  • Page 7: Remote Control Port

    Microsoft Internet Explorer or Mozila, to set the TCP/IP parameter. Before you use the web interface to set the PoE TCP/IP, verify that TP-MS308/TP-MS316/TP-MS324 is properly installed on your network and PC on the network can access PoE via the web-browser.
  • Page 8 9. Key in ID (user name) and password to enter PoE TCP/IP parameter setting. Default ID and password is admin and system. 10. TP-MS308/TP-MS316/TP-MS324 TCP/IP parameter has 4 pages interface (administrator setting, TCP Mode, UDP Mode and UART). You must change the...
  • Page 9 User’s Manual TP-MS308/TP-MS316/TP-MS324 11. Administrator setting: you can assign nickname, IP setting, user name, password and view system information. Nickname: You can assign a name to the device. IP Address: You must assign the IP address reserved by your network. The default IP is 192.168.1.10.
  • Page 10 User’s Manual TP-MS308/TP-MS316/TP-MS324 12. TCP Mode: You can update the TCP control parameter here. Telnet Server/Client: Set to Server for PoE management operation. Port Number: You can assign port number for TCP/IP operation. The default Port Number is 23. Remote Server IP Address: Unused.
  • Page 11 User’s Manual TP-MS308/TP-MS316/TP-MS324 13. UDP Mode: This mode is not used in the PoE application.
  • Page 12 User’s Manual TP-MS308/TP-MS316/TP-MS324 14. UART: You must set UART Control to RS232,9600,8,N,1 for PoE operation. Mode: Set to RS232 for PoE operation. Baud rate: Set to 9600 bps for PoE operation. Character Bits: Set to 8 bits for PoE operation.
  • Page 13 User’s Manual TP-MS308/TP-MS316/TP-MS324 15. When you have configured your set up, you must reset the device to take effect.

  • Page 14: Software Utility Installation

    User’s Manual TP-MS308/TP-MS316/TP-MS324 3. Software Utility Installation Before you start to remote configure the PD, please install the software utility. Through the software utility, you can easily to control the PD which connects with PoE and view the PD parameter information. The software utility provides GUI interface and it is easy to install.

  • Page 15: Gui Management

    User’s Manual TP-MS308/TP-MS316/TP-MS324 4. GUI Management Display and Illustration Connect the PSE with a PC through the remote control port. Then, run the software utility (Netclient). You will see the main utility interface below. Tools bar PSE station selection & alarm indicator...

  • Page 16: System Login

    User’s Manual TP-MS308/TP-MS316/TP-MS324 System Login Run the management software or click “File”, and select “Login”, the system will show the diagram below. Now enter the password, first enter the default setting which is “0000”...

  • Page 17: Modify Password

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Modify Password Click “File” and select “Modify PSW”, you can modify the password, the system permits 3 sets of password.

  • Page 18: Edit Station Tcp/Ip

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Edit Station TCP/IP In the TCP/IP Status display window, you can edit the station name, TCP/IP address and port number. Click the Edit icon to modify this parameter. In the Edit window, click the View icon to display TCP/IP parameter.

  • Page 19: Edit Remote Poe Ip

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Edit Remote PoE IP In the TCP/IP Status display window, you can use “PoE IP Setting” icon to start the web-browser. To modify the remote PoE TCP/IP parameter, please reference RJ-45 Remote Control Port of section 2 Hardware Description (page 7).

  • Page 20: Gui Connect

    User’s Manual TP-MS308/TP-MS316/TP-MS324 GUI Connect In the TCP/IP Status display window, edit TCP/IP parameter, then click “GUI” and select “Connect All” command or click “connect” icon, if the Station Select window shows the name icon and displays power status(green or red) light, it means that the...
  • Page 21 User’s Manual TP-MS308/TP-MS316/TP-MS324 GUI connect example: In the Station Selection window, the LED indicates real time connection of PSE. Green-----this connection and PSE power are normal. Red--------this connection is OK but PSE power is not correct. Orange---this connection is not working..

  • Page 22: Station And Status Window Select

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Station and Status Window Select The PSE management software can monitor 8 PSE simultaneously. In the GUI Disconnect mode, only the TCP/IP Status display window can be used to set the TCP/IP parameter. In the GUI Connector mode, there three display windows can choose - TCP/IP Status/Port Status/Board Status.

  • Page 23: Configuration

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Configuration In the “Module” window, select the suitable port that you require, then, click “Config”, and select “Setup”, the screen will show the system control panel as below. Set icon: Apply the operation mode to PSE system.

  • Page 24: Factory Setting

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Factory Setting Click “Config”, and select “Factory” or click the “Factory” icon. The screen will show the factory setting control panel as below: then click “Y” for the Factory Setting.
  • Page 25 User’s Manual TP-MS308/TP-MS316/TP-MS324 Factory setting as below: Operation Mode → Auto (Auto, Force & Shutdown) AC Disconnect → On (On & Off) DC Disconnect → Off (On & Off)

  • Page 26: Board Status

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Board Status Click “Config”, and select “GetBoardStatus”, or click “Board STATUS” icon, the screen will show current status of each port.

  • Page 27: Port Status

    User’s Manual TP-MS308/TP-MS316/TP-MS324 Port Status In the “Module” window, select the suitable port that you require, then, click “StatusDisp”, and select “PortStatus”, or click the “PORT STATUS” icon, the screen will show current status of each port and current power supply status of each module.

  • Page 28: Gui Version

    User’s Manual TP-MS308/TP-MS316/TP-MS324 GUI Version Click “StatusDisp”, and select “GUI Version”, the screen will show the version of the EMS utility...

  • Page 29: Gui Disconnect

    User’s Manual TP-MS308/TP-MS316/TP-MS324 GUI Disconnect Click the “GUI”, and select “Disconnect All”, or click the “GUI disconnect” icon to disconnect the communication between GUI and PSE.

  • Page 30: File Open And Save

    User’s Manual TP-MS308/TP-MS316/TP-MS324 File Open and Save You may click “File” and select “Open”, or click the ”Open file” icon, to open the previous setting file. Click “Save”, or “Save file” icon, to save the current setting.

  • Page 31: Technical Specification

    User’s Manual TP-MS308/TP-MS316/TP-MS324 5. Technical Specification PARAMETER TP-MS308 TP-MS316 TP-MS324 Data Ports PoE Ports Pass through Data Rates 10/100/1000Mbps Console Port 1× RJ45 console interface for management Per port DC 48V@350mA 16.8W(Maximum) Output power Pair4/5(+),Pair7/8(-) Power consumption 134W 268W 403W...
