Action Star UK-2AA0-A-EL User Manual

Kvm switch
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

INTRODUCTION

UK-2AA0-A-EL
The KVM switch allows a single keyboard, video display monitor, and mouse to be
switched to access multiple computers. The switch provides more table space in addition to
saving the cost of multiple keyboards and monitors.

FEATURES

Access multiple PCs with one set of Keyboard, Mouse, Monitor and Audio.
Space saving and cost effective.
Front panel LEDs indicate which PC is selected.
Select PCs by using front panel SELECT button or Hot Key command.
Auto Scan Mode sequences through PC.
Supports SVGA , VGA and multi-sync Monitors, resolutions up to 2048*1536
Can switch independent KVM and Audio.
Buzz for switching confirmation.
Windows 98, Me, 2000, XP, Vista and Linux OS compatible.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UK-2AA0-A-EL and is the answer not in the manual?

Questions and answers

Related Manuals for Action Star UK-2AA0-A-EL

Summary of Contents for Action Star UK-2AA0-A-EL

  • Page 1 INTRODUCTION UK-2AA0-A-EL The KVM switch allows a single keyboard, video display monitor, and mouse to be switched to access multiple computers. The switch provides more table space in addition to saving the cost of multiple keyboards and monitors. FEATURES Access multiple PCs with one set of Keyboard, Mouse, Monitor and Audio.

  • Page 2: Package Contents

    SPECIFICATION Function Specification Model No. UK-2AA0-A-GL PC Port USB Device Port (only for one keyboard and one mouse) Cable Length 1.8 m Port Selection Select button or Hot-key commands PC Port LED Selected 2 x Green Color LED 1 x USB Type A Male (while) 1 x 3.5mm Mini-Phone Stereo Jack Male (Green) Cable Connector 1 x HDB -15 Male (Blue)
  • Page 4 Configuration After installation, you can either choose the "SELECT" button that leads you through multiple computers or Hot Key controls. The SELECT button...
  • Page 5 Keyboard Hot Key Menu: Press [Scroll Lock] twice, and you will hear an audible switching confirmation tone to ensure you are already in the Hot Key Mode (LED is blinking) In the Auto Scan mode, the KVM switch remains on one port for 10 seconds before switching to the next.

  • Page 6: Troubleshooting

    Troubleshooting Q1: When switching the computer on, the keyboard is not detected, or keyboard / mouse shows error message. If computer BIOS does not support USB boot-up, the system is unable to detect mouse and keyboard during computer start. Q2: What if the computer BIOS is correct but the computer still unable to detect the mouse and keyboard? We suggest user to directly connect the USB KVM switch to USB port on PC, not connect through PCI card, Card Bus, or USB Hub.
