JMC RTP-1000 Service Manual

Jmc rtp-1000 radio
Hide thumbs Also See for RTP-1000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
Service Manual
for
RTP-1000
Japan Marina Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTP-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for JMC RTP-1000

Summary of Contents for JMC RTP-1000

  • Page 1 Service Manual RTP-1000 Japan Marina Co., Ltd.

  • Page 2: Revision History

    Revision History DATE Contents Version Author 04/10/14 1.00 T.KOGURE 04/10/26 2 Releace 1.01 T.KOGURE 04/12/27 3 Releace 1.02 T.KOGURE 05/01/11 4 Releace 1.03 T.KOGURE UT606BH Operation Specification...

  • Page 3: Table Of Contents

    Table Contents Revision History ......................1 Table Contents ......................2 Preface ........................3 Features ........................3 Layout......................... 4 Controls ........................5 Display........................6 Tones ......................... 7 6.1. THE KIND OF TONES..................7 6.2. TIMING DETAILS ....................7 Operations........................8 7.1. COMMON NOTES....................8 7.2.

  • Page 4: Preface

    1. Preface This document is the Operation Specification of Portable transceiver for ATLANTIS 250/CE 2. Features MRN Channels: International EMG 16CH / 09CH mode Battery Level Display Programmable Scan Triple Watch TX Power Select (1W/5W) Channel Select (UP( ) / DOWN( ) sw) Key Lock On/Off Battery Save MRN Channels: All USA and Canadian (Hidden feauture)

  • Page 5: Layout

    3. Layout *The dimension of this layout is different from the actual design and is intended for reference only. UT606BH Operation Specification...

  • Page 6: Controls

    4. Controls a) Push Type SW Table 4-1. Push Switches Channel Up & Auto Repeat Channel Down & Auto Repeat LOCK This key will press and hold, it is possible to set Key Lock On/Off. This key will press the unit will be Triple Watch mode. This key will press, the radio will step to the next channel that has been memorized for scan channel.

  • Page 7: Display

    5. Display *The design is different from the actual design and is intended for reference only. Fig5- 1. LCD Displays TX (Transmit) - This indicator will appear only when the [PTT] sw is pressed and the radio is sending a transmission. 1W / 5W - This indicator will indicate whether the transmitting power is 1W or 5W.

  • Page 8: Tones

    6. Tones 6.1. THE KIND OF TONES Power On Tone This sounds when Radio's power is turned on. Key Touch Tone (single tone) This sounds when a switch is pressed. Key Touch Tone (double tone) This sounds when a switch is pressed and hold for 2 seconds. Error Tone This sounds when pressed switch is invalid.

  • Page 9: Operations

    7. Operations 7.1. COMMON NOTES 1. When all keys except [PTT] sw is pressed, back light lights up for 5 seconds. But TX Power Select temporary by [1/5W] sw is pressed while transmitting is an exception. 7.2. POWER SUPPLY ON/OFF 1.

  • Page 10: Channel Select

    7.3. CHANNEL SELECT 1. Press [ ] sw to increment the Channel number. 2. Press [ ] sw to decrement the Channel number. *Continuous pressing of [ ]/[ ] sw for 0.5 seconds will activate the Auto Repeat function causing the channel to change at 100ms interval. *While scanning, this function is invalid.

  • Page 11: Transmitting

    3. When it keeps pressing [1/5W] sw while Transmitting in the state of a TX POWER 1W. It is set to TX POWER 5W and "5W" icon appears temporarily as long as [1/5W] sw is pressed. Tx Power 1W Tx Power 5W (temporary) *Even if [1/5W] sw is pressed while transmitting in the state of a TX POWER 5W, it will not be set to TX POWER 1W.

  • Page 12: Key Lock On/Off

    7.6. KEY LOCK ON/OFF 1. When it keeps pressing [LOCK] sw for 2 seconds in state of KEY LOCK Off It is set to KEY LOCK On and "LOCK" icon appears. 2. When it keeps pressing [LOCK] sw for 2 seconds in state of KEY LOCK On It is set to KEY LOCK Off and "LOCK"...

  • Page 13: Emergency (Emg) 16Ch/09Ch Mode

    When voltage falls rather than Level 0, the right figure is displayed. In Battery Empty, all sw is inhibit and neither receive nor transmission Ex. Battery Empty is carried out at this time. It is necessary to charge or change new battery.

  • Page 14: Triple Watch

    *This function is valid when it is in Emergency mode or staying by Triple Watch. *While scanning, Memory Channel CANCEL cannot be performed. *If [MEM] sw is press and hold while staying channel in SCAN mode, the Memory Channel is canceled.

  • Page 15: Scan Mode On/Off

    7.12. SCAN MODE ON/OFF 1. Press [SCAN] sw in state of SCAN mode Off. It is set to Triple Watch SCAN On, "SCAN" and "TRIPLE" icons appear. 2. Press [SCAN] sw in state of SCAN mode On. It is set to SCAN mode Off, "SCAN" icon disappears. When "TRIPLE" icon is displayed, this icon also disappears.

  • Page 16: Step Function

    7.13 STEP Function The user will push [MEM] sw to activate the step operation. If time this key is pushed, the radio will step to the next channel that has been placed into Memory. 7.14 KEY BEEP ON/OFF feature The unit has the feature that turns ON/OFF Key Beep. 1.

  • Page 17: Free Ch Active On/Off (Hidden Feature)

    7.16 Free CH active ON/OFF (Hidden feature) Transmission and reception of 30,31,L1, L2, L3, F1, F2, F3 and M1 of 9CH are enabled in addition to existing MRN CH. The unit power supply is turned on pushing [1/5W] sw and [16/9] sw . Active Mode(4 Mode)/Inactive of Free CH changes.

  • Page 18: Others

    8. Others 8.1. TIMING / SPECIFIC QUALITY Table 8-1-1. SPECIFIC QUALITY FUNCTION CONTENTS UNIT REM. BATTERY SAVE TIMING (Battery Save On) BATTERY SAVE TIMING (Battery Save Off) SCANNING SPEED per CH Watch INTERVAL of TRIPLE WATCH Watch TIME of TRIPLE WATCH 100 / 100 09CH/16CH DROP OUT DELAY TIME (SCAN, DW)

  • Page 19: Frequency List

    8.2. FREQUENCY LIST Table 8-2-2. MRN BAND USA / CANADA / INTERNATIONAL Note: Lo = TX Lo Power only / DUP, D = RX Duplex CH / INH = TX, RX INHIBIT MODE MODE MODE MODE CH NO TX FRQ.(MHz) RX FRQ.(MHz) note TX FRQ.(MHz)

  • Page 20: Appendix

    8.3. APPENDIX Battery Charging Please shut off a power supply, when a battery is charged. UT606BH Operation Specification...

  • Page 21: Revision

    9. Revision 1.00->1.01 P15 Clerical error correction 1. Press and hold [MEM] sw for 2second at International mode. It is set to Canadian mode, "INT" icon disappears, and "CAN" icon appears. 2. Press and hold [MEM] sw for 2second at Canadian mode. It is set to USA mode, "CAN"...
