- Page 1 1. 2 (A)
-
Page 2: Table Of Contents
Warning Signs and Indications ..................4 General Safety........................ 4 Specific Safety ........................ 4 Regulatory Compliance ......................5 Disposal ........................... 5 Introduction to sinaCAM ......................5 Description ..........................6 Remote Head HDC1-100 ....................6 Base Unit HDC1-200 ...................... 7 6.2.1 The Control Panel ....................8 6.2.2 The Rear Panel .................... -
Page 3: About This Document
Alignment of contents in several chapters with the sinaCAM user manual, revision A. Purpose This document provides a basic description, safety and quick start information for the sinaCAM camera system. However, this document does not replace the detailed user manual, which can be downloaded from: www.sinacam.eu Copyright Copyright ©... -
Page 4: Safety Instructions
Do not open the housing of the camera system. Risk of electric shock! Do not open the housing or attempt to repair or modify any part of the camera system. Repairs must only be carried out by authorized sinaCAM service centers. ... -
Page 5: Regulatory Compliance
HD studio camera system for professional 2D/3D broadcast and cinema production. Two signals of two sinaCAM remote heads are processed by the same im- age processor. This enables: – Pixel synchronous 3D output –... -
Page 6: Description
Description sinaCAM Description Remote Head HDC1-100 Figure 1: The Remote Head Table 2: Elements and Controls of the Remote Head Item Designation Description Locking lever Locking/unlocking the adjustment ring Flange back Flange back distance adjustment ring rotates adjustment ring independently of C-mount and lens... -
Page 7: Base Unit Hdc1-200
It does not supply the camera with power. Do not open the system battery compartment. Replacement of the system battery must only be carried out by authorized sinaCAM service centers. Rear panel Panel with all terminals to connect equipment Quick Start Guide Rev.: 1.2 (A) -
Page 8: The Control Panel
Description sinaCAM 6.2.1 The Control Panel Figure 3: The Control Panel POWER Table 4: Controls and their Functions Item Designation Description USB 2.0 port Enables frame grabs to USB sticks Display Graphical user interface display F1 button To select a menu item as displayed... -
Page 9: The Rear Panel
Description 6.2.2 The Rear Panel Figure 4: Arrangement of the Terminals Table 5: Terminals on the Rear Panel Item Designation Description Remote head CoaXPress interface with 18 V power supply for terminals the remote camera heads, connection via 75 ohms... -
Page 10: Installation
The base unit supplies 18 V power to the remote camera head terminals 1 and 2. NOTICE Connect only sinaCAM remote camera heads to terminals 1 and 2 of the base unit. Connection of any other equipment to terminal 1 or 2 may not only cause damage to the camera system, but also to the connected equipment. -
Page 11: Connection Examples
Installation Connection Examples Figure 5: Standard Single-Link Setup DC IN 12...24V (Electronic View Finder) 3D Recorder Figure 6: Advanced Dual-Link Setup Dual Link Dual Link DC IN Recorder Recorder 12...24V Figure 7: Broadcast Setup Genlock OUT Genlock IN DC IN 12...24V... -
Page 12: The Menus At A Glance
The Menus at a Glance sinaCAM The Menus at a Glance 24p; 24psf; 25p; 25psf; 50i; 30p; 30psf; 60i; 48pDL; 50pDL; 60pDL; F1 - S A F2 - Save 23,9p; 23,9psf; 29,9p; 29,9psf; 59,9i; 59,9pDL; 720 24p; 720 25p; ... 720 30p; 720 50p; 720 60p; 720 23p; 720 29p; 720 59p ... -
Page 13: Operation
The system LED of the remote head lights up in orange, starts flashing green and finally glows green continuously. Note: The system LED of the remote head can indicate additional status in- formation. For more indications refer to sinaCAM’s detailed user manual. Switching OFF ... -
Page 14: Technical Specifications
Technical Specifications sinaCAM Technical Specifications Remote Head HDC1-100 Image Sensor 2/3” Single Chip Kodak CCD Sensor (RGB) 2004x1144 Pixels, Progressive Scan Sensitivity 2000 Lux @ f 8.0 / 0 dB Gain (100% video out) 160 Lux @ f 2.2 / 0 dB Gain (100% video out) - Page 15 Technical Specifications Base Unit HDC1-200 HD-SDI Video Formats YCbCr 4:2:2 / 10 Bit 1920x1080 / 24p, 24psf, 25p, 25psf, 50i, 30p, 30psf, 60i, 48pDL*, 50pDL*, 60pDL*, 23.98p, 23.98psf, 29.97p, 29.97psf, 59.94i, 59.94pDL* * = HD-SDI Dual-Link Mode With May 2012 firmware update: 1280x720 / 24p, 25p, 30p, 50p, 60p, 23.98p,...
