Warning Signs and Indications ..................4 General Safety........................ 4 Specific Safety ........................ 4 Regulatory Compliance ......................5 Disposal ........................... 5 Introduction to sinaCAM ......................5 Description ..........................6 Remote Head HDC1-100 ....................6 Base Unit HDC1-200 ...................... 7 6.2.1 The Control Panel ....................8 6.2.2 The Rear Panel .................... -
Page 3: About This Document
April 18, 2012 First edition Purpose This document provides a basic description, safety and quick start information for the sinaCAM camera system. However, this document does not replace the detailed user manual, which can be downloaded from: www.sinacam.eu Copyright Copyright © 2012, by Solectrix Systems and anadicon solutions. -
Page 4: Safety Instructions
Do not open the housing of the camera system. Risk of electric shock! Do not open the housing or attempt to repair, or modify, any part of the camera system. Repairs must only be carried out by authorized sinaCAM service centers. ... -
Page 5: Regulatory Compliance
HD studio camera system for professional 2D/3D broadcast and cinema production. Two signals of two sinaCAM remote heads are processed by the same im- age processor. This enables: – Pixel synchronous 3D output –... -
Page 6: Description
Description sinaCAM Description Remote Head HDC1-100 Figure 1: The Remote Head Table 2: Elements and Controls of the Remote Head Item Designation Description Locking lever Locking/unlocking the adjustment ring Flange back Flange back distance adjustment ring rotates adjustment ring independently of C-mount and lens... -
Page 7: Base Unit Hdc1-200
It does not supply the camera with power. Do not open the system battery com- partment. Replacement of the system battery must only be carried out by authorized sinaCAM service centers. Rear panel Panel with all terminals to connect equipment Quick Start Guide Rev.: 1.0... -
Page 8: The Control Panel
Description sinaCAM 6.2.1 The Control Panel Figure 3: The Control Panel POWER Table 4: Controls and their Functions Item Designation Description USB 2.0 port Enables frame grabs to USB sticks Display Graphical user interface display F1 button To select a menu item as displayed... -
Page 9: The Rear Panel
Description 6.2.2 The Rear Panel Figure 4: Arrangement of the Terminals Table 5: Terminals on the Rear Panel Item Designation Description Remote head CoaXPress interface with 18V power supply for terminals the remote camera heads, connection via 75 ohms... -
Page 10: Installation
The base unit supplies 18V power to the remote camera head terminals 1 and 2. NOTICE Connect only sinaCAM remote camera heads to terminals 1 and 2 of the base unit. Connection of any other equipment to terminal 1 or 2 may not only cause damage to the camera system, but also to the connected equipment. -
Page 11: Connection Examples
Installation Connection Examples Figure 5: Standard Single Link Setup DC IN 12...24V (Electronic View Finder) 3D Recorder Figure 6: Advanced Dual Link Setup Dual Link Dual Link DC IN Recorder Recorder 12...24V Figure 7: Broadcast Setup Genlock OUT Genlock IN DC IN 12...24V... -
Page 12: The Menus At A Glance
The Menus at a Glance sinaCAM The Menus at a Glance Home Menu F1 - S A F2 - Save 24p; 24psf; 25p; 25psf; 50i; 30p; 30psf; 60i; 48pDL; 50pDL; 60pDL; ... 23,9p; 23,9psf; 29,9p; 29,9psf; 59,9i; 59,9pDL ... FULL; 1/50; 1/60; 1/125; 1/250; 1/500; 1/1000; 1/2000; 1/5000... -
Page 13: Operation
Operation Operation Switching ON and OFF After the base unit is connected to the power supply, the power LED glows red. Switching ON Push the power switch. – The power LED of the base unit changes from red to green. -
Page 14: Technical Specifications
Technical Specifications sinaCAM Technical Specifications Remote Head HDC1-100 Image Sensor 2/3” Single Chip Kodak CCD Sensor (RGB) 2004×1144 Pixels, Progressive Scan Sensitivity 2000 Lux @ f 8.0 / 0dB Gain (100% video out) 160 Lux @ f 2.2 / 0dB Gain (100% video out) Resolution 1920×1080 Pixels... - Page 15 Technical Specifications Base Unit HDC1-200 HD-SDI Video Formats YCbCr 4:2:2 / 10 Bit ; 1080 / 24p, 24psf, 25p, 25psf, 50i, 30p, 30psf, 60i, 48pDL*, 50pDL*, 60pDL* 1080 / 23.9p, 23.9psf, 29.9p, 29.9psf, 59.9i, 59.9pDL* * = HD-SDI Dual Link Mode Option: 1280×720...
