LED MOVING HEAD
FLEX BEAM K8 RGBW

User Manual

Please read the instruction carefully before use
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEX BEAM K8 RGBW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ArtFox Lightning FLEX BEAM K8 RGBW

  • Page 1: User Manual

    LED MOVING HEAD FLEX BEAM K8 RGBW User Manual Please read the instruction carefully before use...
  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions ....................3 2. Technical Specifications ................... 4 3. How To Set The Unit ....................5 3.1 Front & Rear Panel ....................5 3.2 Main Function ...................... 6 4. How to Control the Unit ................... 9 4.1 Master/Slave Built In Preprogrammed Function ..........9 4.2 DMX Address Setting ...................
  • Page 3: Safety Instructions

    1. Safety Instructions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING • PLEASE keep this User Manual for future consultation. If you sell the fixture to another user, make sure that they also receive this instruction booklet. •...
  • Page 4: Technical Specifications

    Caution: There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. Installation: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating.
  • Page 5: How To Set The Unit

    • Dimension: 405 x 148 x 381mm 3. How To Set The Unit 3.1 Front & Rear Panel 1. Function Display: Used to show the various menus and the selected functions. 2. Button: FUNCTION return to the upper menu one by one DOWN To go backward in the selected functions To go forward in the selected functions...
  • Page 6: Main Function

    4. Fuse (T 3.15A): Used to protect the unit from the damage of over-current; 5. DMX IN/OUT: For DMX512 links, use 3-pin XLR plug cable to link the unit together; 3.2 Main Function To select any functions, press the ENTER button until the required function is showing on the display.
  • Page 7: How To Control The Unit

    Defaults YES, NO System Reset YES, NO Note: There is only one Projector to be set as a Master in a signal Cable. If Master’s functions used, Please disable DMX control signal. When multiple projectors’ work together in synchronous control state, Parameters can be transmitted from the master projector to the slave projectors such as DMX channel mode, Display setting status and operation mode (User memory data is included).
  • Page 8: Dmx512 Configuration

    press the FUNCTION button. Press the FUNCTION button to exit the menu mode. Please refer to the following diagram to address your DMX512 channel for the first 4 units. Channel Mode Unit 1 Unit 2 Unit 3 Unit 4 11 channel 37 channels 5.
  • Page 9 Chase 10 Chase 11 Chase 12 Chase 13 Chase 14 Chase 15 Chase 16 Full on Chase speed Speed from slow to fast 37CH Mode( 37 Channels ) Number Channel DMX Value Description Pan 0 to 540 degree Tilt from 0-360 degree Tilt 1 CW Infinity tilt Fast-Slow CCW infinity tilt slow-fast...
  • Page 10: Dmx Connection

    Red6 Red6 Dimming 0-100% Green6 Green6 Dimming 0-100% Blue6 Blue6 Dimming 0-100% White6 White6 Dimming 0-100% Red7 Red7 Dimming 0-100% Green7 Green7 Dimming 0-100% Blue7 Blue7 Dimming 0-100% White7 White7 Dimming 0-100% Red8 Red8 Dimming 0-100% Green8 Green8 Dimming 0-100% Blue8 Blue8 Dimming 0-100% White8...
  • Page 11: Troubleshooting

    Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system 2. The DMX output and input connectors are pass-through to maintain the DMX circuit when one of the units’ power is disconnected. 3.
  • Page 12: Fixture Cleaning

    2. Check microphone to see if it is good by tapping the microphone. D. One of the channels is not working well 1. The stepper motor might be damaged or the cable connected to the PCB is broken. 2. The motor’s drive IC on the PCB might be out of condition. 8.
