Summary of Contents for Sky Angel AMX

  • Page 1 Assembly and Operating Manual...
  • Page 2 The radio control system Glued joints, suitable adhesives Congratulations on your choice of a To fly the AMX you will need a radio control system Foam safe epoxy is recommended and available factory-assembled model aircraft from the with at least four channels. 2.4GHz radios systems from most reputable model retail shops.
  • Page 3: Parts Illustration

    Assembly and Operating Manual Fig. 1 Open the box and check all the parts. Parts Illustration Parts List Description Fuselage Wing Set – One Left (and one Right) Wing Panel Tail Set - One Left (and one Right) Horizontal Stabilizer with Elevator Tail Set - One Vertical Stabilizer Landing Skids...
  • Page 4 Assembly and Operating Manual Fig. 2 - Glue the horizontal tail wings into the slots Fig. 3 - Remove any excess glue and hold in Fig. 4 - Locate the elevator push rods set. at the rear of the fuselage (glue not included). position until the glue sets.
  • Page 5 Assembly and Operating Manual Fig. 8 - The photo shows the finished view after Fig. 9 - Locate the aileron push rods set. Fig. 10 - Connect the push rods to the aileron gluing the wings in place. servo arm and control horns. Fig.
  • Page 6 Assembly and Operating Manual Fig. 14 - Locate the blue landing skid and apply Fig. 15 - Photo shows the finished view after the Fig. 16 - Glue the vertical stabilizer as shown in the glue to the front of the fuselage. (white mark shows skid is assembled.
  • Page 7 Assembly and Operating Manual Fig. 20 - Insert the battery into the front of the Fig. 21 - The canopy is held in place by magnets Fig. 22 - Photo shows the finished view after fuselage. and can be lifted off. canopy is assembled.
  • Page 8 Assembly and Operating Manual Optional parts (not required) Fig. 26 - Three sets of 3 painted missiles, for extra realism, are included. Fig. 27 - Missiles shown after being separated. Cut apart for assembly as shown Fig. 28 - Glue missiles into the main wing slots (glue not included). Fig.
  • Page 9 Assembly and Operating Manual Fig. 30 - Charge the flight battery; connect the Equalizer lead using and adapter lead matching your charger (adapter lead not included). Fig. 31 - Switch the transmitter on, and move the throttle stick to the “Motor OFF” position.
  • Page 10 Assembly and Operating Manual Fig. 32 and 33 - Checking Ailerons and Elevators - Check that the control surfaces respond to the appropriate movements of the transmitter sticks. If not, swap over the connectors at the receiver. - Check the neutral position of the control surfaces; you may need to screw the clevises in or out to correct any discrepancy.
  • Page 11 Assembly and Operating Manual Fig. 35 - Checking the model’s balance - Place the flight battery in its compartment, without connecting. - Mark the Centre of Gravity (CG) on both sides of the fuselage; the position is shown in the photo. - Support the model at the marked points and allow it to hang freely.
  • Page 12 Switch the motor on, and launch the airplane strongly into the wind, with the fuselage and wings level. Allow the AMX Jet to fly straight and level initially; don’t try to turn it when it is close to the ground.
