User Manual

MV1-R1280-50-G2 Camera Series
Ultra low light CMOS camera with GigE interface
MAN066 04/2015 V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV1-R1280-50-G2 Camera Series and is the answer not in the manual?

Questions and answers

Related Manuals for Photon Focus MV1-R1280-50-G2 Camera Series

Summary of Contents for Photon Focus MV1-R1280-50-G2 Camera Series

  • Page 1: User Manual

    User Manual MV1-R1280-50-G2 Camera Series Ultra low light CMOS camera with GigE interface MAN066 04/2015 V1.0...
  • Page 2 All information provided in this manual is believed to be accurate and reliable. No responsibility is assumed by Photonfocus AG for its use. Photonfocus AG reserves the right to make changes to this information without notice. Reproduction of this manual in whole or in part, by any means, is prohibited without prior permission having been obtained from Photonfocus AG.

  • Page 3: Table Of Contents

    Contents 1 Preface 1.1 About Photonfocus ........1.2 Contact .
  • Page 4 CONTENTS 5.5 Hotpixel Correction ........50 5.6 Crosshairs .
  • Page 5 9 Warranty 9.1 Warranty Terms ........87 9.2 Warranty Claim .
  • Page 6 CONTENTS...

  • Page 7: Preface

    Preface 1.1 About Photonfocus The Swiss company Photonfocus is one of the leading specialists in the development of CMOS image sensors and corresponding industrial cameras for machine vision. Photonfocus is dedicated to making the latest generation of CMOS technology commercially available.

  • Page 8: Legend

    1 Preface Reproduction of this manual in whole or in part, by any means, is prohibited without prior permission having been obtained from Photonfocus AG. Photonfocus can not be held responsible for any technical or typographical er- rors. 1.5 Legend In this documentation the reader’s attention is drawn to the following icons: Important note Alerts and additional information...

  • Page 9: Introduction

    Introduction 2.1 MV1-R1280 Introduction The Photonfocus MV1-R1280 camera series is built around a ultra-low noise CMOS image sensor with a high dynamic range. The image sensor uses an innovative integration mode and an advanced analog to digital conversion (ADC) to achieve a read out noise of less than 1e . Fig.
  • Page 10 2 Introduction...

  • Page 11: How To Get Started (Gige G2)

    How to get started (GigE G2) 3.1 Introduction This guide shows you: • How to install the required hardware (see Section 3.2) • How to install the required software (see Section 3.3) and configure the Network Adapter Card (see Section 3.4 and Section 3.5) •...
  • Page 12 3 How to get started (GigE G2) Remove the Photonfocus GigE camera from its packaging. Please make sure the following items are included with your camera: • Power supply connector • Camera body cap If any items are missing or damaged, please contact your dealership. Connect the camera to the GigE interface of your PC with a GigE cable of at least Cat 5E or - t h e r n e t J a c k ( R J 4 5 ) P o w e r S u p p l y...

  • Page 13: Software Installation

    3.3 Software Installation This section describes the installation of the required software to accomplish the tasks described in this chapter. Install the latest drivers for your GigE network interface card. Download the latest eBUS SDK installation file from the Photonfocus server. You can find the latest version of the eBUS SDK on the support (Software Down- load) page at www.photonfocus.com.
  • Page 14 3 How to get started (GigE G2) Figure 3.3: PFInstaller components choice...

  • Page 15: Network Adapter Configuration

    3.4 Network Adapter Configuration This section describes recommended network adapter card (NIC) settings that enhance the performance for GigEVision. Additional tool-specific settings are described in the tool chapter. Open the Network Connections window (Control Panel -> Network and Internet Connections -> Network Connections), right click on the name of the network adapter where the Photonfocus camera is connected and select Properties from the drop down menu that appears.
  • Page 16 3 How to get started (GigE G2) By default, Photonfocus GigE Vision cameras are configured to obtain an IP address automatically. For this quick start guide it is recommended to configure the network adapter to obtain an IP address automatically. To do this, select Internet Protocol (TCP/IP) (see Fig.
  • Page 17 Open again the Local Area Connection Properties window (see Fig. 3.4) and click on the Configure button. In the window that appears click on the Advanced tab and click on Jumbo Frames in the Settings list (see Fig. 3.6). The highest number gives the best performance. Some tools however don’t support the value 16128.
  • Page 18 3 How to get started (GigE G2) No firewall should be active on the network adapter where the Photonfocus GigE camera is connected. If the Windows Firewall is used then it can be switched off like this: Open the Windows Firewall configuration (Start -> Control Panel -> Network and Internet Connections ->...

  • Page 19: Network Adapter Configuration For Pleora Ebus Sdk

    3.5 Network Adapter Configuration for Pleora eBUS SDK Open the Network Connections window (Control Panel -> Network and Internet Connections -> Network Connections), right click on the name of the network adapter where the Photonfocus camera is connected and select Properties from the drop down menu that appears. A Properties window will open.

  • Page 20: Getting Started

    3 How to get started (GigE G2) 3.6 Getting started This section describes how to acquire images from the camera and how to modify camera settings. Open the PF_GEVPlayer software (Start -> All Programs -> Photonfocus -> GigE_Tools -> PF_GEVPlayer) which is a GUI to set camera parameters and to see the grabbed images (see Fig.
  • Page 21 Click on the Select / Connect button in the PF_GEVPlayer . A window with all detected devices appears (see Fig. 3.10). If your camera is not listed then select the box Show unreachable GigE Vision Devices. Figure 3.10: GEV Device Selection Procedure displaying the selected camera Select camera model to configure and click on Set IP Address..
  • Page 22 3 How to get started (GigE G2) Select a valid IP address for selected camera (see Fig. 3.12). There should be no exclamation mark on the right side of the IP address. Click on Ok in the Set IP Address dialog.
  • Page 23 If no images can be grabbed, close the PF_GEVPlayer and adjust the Jumbo Frame parameter (see Section 3.3) to a lower value and try again. Figure 3.14: PF_GEVPlayer displaying live image stream Check the status LED on the rear of the camera. The status LED light is green when an image is being acquired, and it is red when serial communication is active.
  • Page 24 3 How to get started (GigE G2) To modify the exposure time scroll down to the AcquisitionControl control category (bold title) and modify the value of the ExposureTime property.

  • Page 25: Product Specification

    Product Specification 4.1 Introduction The Photonfocus MV1-R1280 GigE camera is built around an ultra-low noise CMOS image sensor with a high dynamic range. The camera is targeted at demanding ultra-low light scientific applications and high-end night vision systems. The principal advantages are: •...
  • Page 26 4 Product Specification Figure 4.1: Photonfocus MV1-R1280 GigE camera series with C-mount lens.

  • Page 27: Feature Overview

    4.2 Feature Overview The general specification and features of the camera are listed in the following sections. The detailed description of the camera features is given in Chapter 5. Characteristics Photonfocus MV1-R1280 GigE Camera Series Interface Gigabit Ethernet, GigE Vision and GenICam compliant Camera Control GigE Vision Suite Trigger Modes...

  • Page 28: Technical Specification

    4 Product Specification 4.4 Technical Specification MV1-R1280-CL Sensor Ultra-low light CMOS sensor Technology CMOS Optical format / diagonal 2/3” (11.7 mm diagonal) Resolution 1280 x 1024 pixels Pixel size 7.1 m x 7.1 m Active optical area 9.1 mm x 7.3 mm Dark current 10 e /s Read out noise...
  • Page 29 MV1-R1280 GigE Operating temperature / moisture 0°C ... 50°C / 20 ... 80 % Storage temperature / moisture -25°C ... 60°C / 20 ... 95 % Camera power supply +12 V DC (- 10 %) ... +24 V DC (+ 10 %) Trigger signal input range +5 ..
  • Page 30 4 Product Specification...

  • Page 31: Functionality

    Functionality This chapter serves as an overview of the camera configuration modes and explains camera features. The goal is to describe what can be done with the camera. The setup of the cameras is explained in later chapters. 5.1 Reduction of Image Size 5.1.1 Region of Interest (ROI) Some applications do not need full image resolution.

  • Page 32: Maximal Frame Rate

    5 Functionality 5.1.2 Maximal Frame Rate The maximal frame rate of the camera depends on the camera settings. The following factors influence the maximal frame rate (see also Table 5.1): • The length of the exposure time: A shorter exposure time can lead to an increase in the maximal frame rate.

  • Page 33: Trigger And Strobe

    Exposure time >= read out time When the exposure time is equal or bigger than the read out time then the maximal frame rate depends only on the exposure time (see Fig. 5.2). MaxFrameRate = 1 / ExposureTime F r a m e < n > F r a m e <...
  • Page 34 5 Functionality TriggerMode = Off. In Constant Frame Rate mode (AcquisitionFrameRateEnable = True), exposure starts after a user-specified time has elapsed from the previous exposure start so that the resulting frame rate is equal to the value of AcquisitionFrameRate. Software Trigger The trigger signal is applied through a software command (TriggerSoftware in category AcquisitionControl).

  • Page 35: Trigger And Acquisitionmode

    Figure 5.4: Trigger Inputs - Multiple GigE solution 5.2.3 Trigger and AcquisitionMode The relationship between AcquisitionMode and TriggerMode is shown in Table 5.2. When TriggerMode=Off, then the frame rate depends on the AcquisitionFrameRateEnable property (see also under Free running in Section 5.2.2). The ContinuousRecording and ContinousReadout modes can be used if more than one camera is connected to the same network and need to shoot images si- multaneously.
  • Page 36 5 Functionality AcquisitionMode TriggerMode After the command AcquisitionStart is executed: Continuous Camera is in free-running mode. Acquisition can be stopped by executing AcquisitionStop command. Continuous Camera is ready to accept triggers according to the TriggerSource property. Acquisition and trigger acceptance can be stopped by executing AcquisitionStop command.

  • Page 37: Exposure Time Control

    5.2.4 Exposure Time Control Depending on the trigger mode, the exposure time can be determined either by the camera or by the trigger signal itself: Camera-controlled Exposure time In this trigger mode the exposure time is defined by the camera. For an active high trigger signal, the camera starts the exposure with a positive trigger edge and stops it when the preprogrammed exposure time has elapsed.
  • Page 38 5 Functionality results then from the synchronous design of the FPGA state machines and from to trigger offset requirement to start an exposure at a fixed point from the start of the read out of a row. The exposure time t is controlled with an internal exposure time controller.

  • Page 39: Trigger Delay

    The falling edge of the trigger pulse is delayed by the time t which results from the d iso input signal isolator. This signal is clocked into the FPGA which leads to a jitter of t . The pulse is jitter then delayed by t by the user defined value which can be configured via camera...
  • Page 40 5 Functionality A x t e r n a l t r i g g e r p u l s e i n p u t t r i g g e r a f t e r i s o l a t o r d - i s o - i n p u t t r i g g e r p u l s e i n t e r n a l c a m e r a c o n t r o l j i t t e r...

  • Page 41: Trigger Timing Values

    5.2.8 Trigger Timing Values Table 5.3 shows the values of the trigger timing parameters. MV1-R1280-50 GigE MV1-R1280-50 GigE Timing Parameter Minimum Maximum 1.5 s d iso input 65 ns 185 ns d RS422 input 20 ns jitter 0.33 s trigger delay 0.33 s burst trigger delay depends on camera settings...

  • Page 42: A/B Trigger For Incremental Encoder

    5 Functionality 5.2.9 A/B Trigger for Incremental Encoder An incremental encoder with A/B outputs can be used to synchronize the camera triggers to the speed of a conveyor belt. These A/B outputs can be directly connected to the camera and appropriate triggers are generated inside the camera.
  • Page 43 There is a bug in the single A/B trigger mode in some camera revisions (see Ap- pendix B, A/B Trigger Bug). In this case when the encoder position moves back and forth by a small amount, the EncoderCounter is incremented and the decre- ment is sometimes omitted, leading to a wrong EncoderPosition indication in the camera.
  • Page 44 5 Functionality A/B Trigger Debounce A debouncing logic can be enabled by setting ABTriggerDeBounce=True. It is implemented with a watermark value of the EncoderCounter (see Fig. 5.11). Suppose ABTriggerDirection=fwd, then the watermark value is increased with the increments of the EncoderCounter. If EncoderCounter decreases, e.g.
  • Page 45 A/B Trigger Divider if ABTriggerDivider>1 then not all internally generated triggers are applied to the camera logic. E.g. If ABTriggerDivider=2, then every second trigger is applied to the camera (see Fig. 5.13). G r a y C o u n t e r E n c o d e r C o u n t e r I n t e r n a l T r i g g e r F w d A p p l i e d T r i g g e r F w d...

  • Page 46: Missed Trigger Counters

    5 Functionality By default the Encoder Position is only generated when TriggerMode=On and TriggerSource=ABTrigger. When the property ABTriggerCountAlways=True, then the Encoder Position is generated regardless of the trigger mode. 5.2.10 Missed Trigger Counters The missed trigger counters are important tools to make sure that the frequency of an external trigger can be processed by the camera.

  • Page 47: Trigger Acquisition

    The setting Counter_ResetCounterMode=Continuous resets the counters on every occurrence of an active edge of the reset source without the requirement to arm the device first. This setting is suited if the reset source signal is different than the camera trigger. The active edge of the reset input can be set by the property Counter_ResetCounterSourceInvert.
  • Page 48 5 Functionality Feature Value Category TriggerAcquisition_Enable True Trigger/TriggerAcquisition TriggerAcquisition_Mode Level Trigger/TriggerAcquisition TriggerAcquisition_StartSource PLC_Q5 Trigger/TriggerAcquisition PLC_I0 Line0 <PLC>/SignalRoutingBlock PLC_Q5_Variable0 PLC_I0_Not <PLC>/LookupTable/Q5 PLC_Q5_Operator0 <PLC>/LookupTable/Q5 PLC_Q5_Variable1 Zero <PLC>/LookupTable/Q5 PLC_Q5_Operator1 <PLC>/LookupTable/Q5 PLC_Q5_Variable2 Zero <PLC>/LookupTable/Q5 PLC_Q5_Operator2 <PLC>/LookupTable/Q5 PLC_Q5_Variable3 Zero <PLC>/LookupTable/Q5 Table 5.4: Example of using ISO_IN0 as trigger enable in level mode Edge Triggered Trigger Acquisition The Edge Triggered mode is enabled by setting TriggerAcquisition_Mode to Edge and TriggerAcquisition_Enable=True.

  • Page 49: Data Path Overview

    5.3 Data Path Overview The data path is the path of the image from the output of the image sensor to the output of the camera. The sequence of blocks is shown in figure Fig. 5.18. 1 m a g e S e n s o r D i g i t a l O f f s e t D i g i t a l G a i n D i g i t a l F i n e G a i n...

  • Page 50: Gain And Offset

    5 Functionality 5.4 Gain and Offset There are two different gain settings on the camera: Gain (Digital Fine Gain) Digital fine gain accepts fractional values from 0.01 up to 15.99. It is implemented as a multiplication operation. Digital Gain Digital Gain is a coarse gain with the settings x1, x2, ..., x2048. It is implemented as a binary shift of the image data where the two LSB from the image sensor and ’0’...
  • Page 51 Figure 5.19: Crosshairs Example with different grey values 5.6 Crosshairs...

  • Page 52: Image Information

    5 Functionality 5.7 Image Information There are camera properties available that give information about the acquired images, such as an image counter, average image value and the number of missed trigger signals. These properties can be queried by software. Alternatively, a status line within the image data can be switched on that contains all the available image information.
  • Page 53 Start pixel index Parameter width [bit] Parameter Description Preamble: 0x55AA00FF Image Counter (see Section 5.7.1) Real Time Counter (see Section 5.7.1) Missed Trigger Counter (see Section 5.7.1) Image Average Value("raw" data without taking in account gain settings) (see Section 5.7.1) Integration Time in units of clock cycles (see Table 4.3) Reserved (Burst Trigger Number)

  • Page 54: Camera Type Codes

    5 Functionality 5.7.3 Camera Type Codes Camera Model Camera Type Code MV1-R1280-50-G2-16 Table 5.6: Type codes of Photonfocus MV1-R1280 GigE camera series 5.8 Test Images Test images are generated in the camera FPGA, independent of the image sensor. They can be used to check the transmission path from the camera to the acquisition software.

  • Page 55: Lfsr

    5.8.2 LFSR The LFSR (Linear Feedback Shift Register) test image outputs a constant pattern with a pseudo-random grey level sequence containing every possible grey level that is repeated for every row. The LFSR test pattern was chosen because it leads to a very high data toggling rate, which stresses the interface electronic and the cable connection.
  • Page 56 5 Functionality Figure 5.23: LFSR test pattern received and typical histogram for error-free data transmission Figure 5.24: LFSR test pattern received and histogram containing transmission errors...

  • Page 57: Hardware Interface

    Hardware Interface 6.1 GigE Connector The GigE cameras are interfaced to external components via • an Ethernet jack (RJ45) to transmit configuration, image data and trigger. • a 12 pin subminiature connector for the power supply, Hirose HR10A-10P-12S (female) . The connectors are located on the back of the camera.

  • Page 58: Status Indicator (Gige Cameras)

    6 Hardware Interface A suitable power supply can be ordered from your Photonfocus dealership. For further details including the pinout please refer to Appendix A. 6.3 Status Indicator (GigE cameras) A dual-color LED on the back of the camera gives information about the current status of the GigE CMOS cameras.
  • Page 59 C a m e r a I n t e r n a l P o w e r S u p p l y 2 o w e r S u p p l y P O W E R D C / D C V C C _ 1 D C / D C...

  • Page 60: Trigger And Strobe Signals For Gige Cameras

    6 Hardware Interface 6.5 Trigger and Strobe Signals for GigE Cameras 6.5.1 Overview The 12-pol. Hirose power connector contains two external trigger inputs, two strobe outputs and two differential inputs (G2 models: RS-422, H2 models: HTL). All inputs and outputs are connected to the Programmable Logic Controller (PLC) (see also Section 6.6) that offers powerful operations.
  • Page 61 C a m e r a I S O L A T O R R S 4 2 2 I S O _ I N C 0 _ P I S O _ I N C 0 _ N - 1 0 V t o + 1 3 V e x t e n d e d I S O _ I N C 1 _ P...
  • Page 62 6 Hardware Interface C a m e r a I S O L A T O R H T L : i n p u t r a n g e : 1 0 V t o 3 0 V I S O _ I N C 0 _ P I S O _ I N C 0 _ N I S O _ I N C 1 _ P...

  • Page 63: Single-Ended Inputs

    6.5.2 Single-ended Inputs ISO_IN0 and ISO_IN1 are single-ended isolated inputs. The input circuit of both inputs is identical (see Fig. 6.3). Fig. 6.5 shows a direct connection to the ISO_IN inputs. In the camera default settings the PLC is configured to connect the ISO_IN0 to the PLC_Q4 camera trigger input.

  • Page 64: Single-Ended Outputs

    6 Hardware Interface 6.5.3 Single-ended Outputs ISO_OUT0 and ISO_OUT1 are single-ended isolated outputs. ISO_OUT0 and ISO_OUT1 have different output circuits: ISO_OUT1 doesn’t have a pullup resistor and can be used as additional Strobe out (by adding Pull up) or as controllable switch. Maximal ratings that must not be exceeded: voltage: 30 V, current: 0.5 A, power: 0.5 W.
  • Page 65 Fig. 6.9 shows the connection from ISO_OUT1 to a LED. 1 2 p o l . H i r o s e C a m e r a C o n n e c t o r ; O U R _ P W R P T C I S O _ O U T 1 P o w e r...

  • Page 66: Differential Rs-422 Inputs (G2 Models)

    6 Hardware Interface 6.5.4 Differential RS-422 Inputs (G2 models) ISO_INC0 and ISO_INC1 are isolated differential RS-422 inputs (see also Fig. 6.3). They are connected to a Maxim MAX3098 RS-422 receiver device. Please consult the data sheet of the MAX3098 for connection details. Don’t connect single-ended signals to the differential inputs ISO_INC0 and ISO_INC1 (see also Fig.

  • Page 67: I/O Wiring

    6.5.6 I/O Wiring The Photonfocus cameras include electrically isolated inputs and outputs. Take great care when wiring trigger and strobe signals to the camera, specially over big distances (a few meters) and in noisy environments. Improper wiring can introduce ground loops which lead to malfunction of triggers and strobes.
  • Page 68 6 Hardware Interface Common Grounds with Star Wiring Ground loops can be avoided using "star wiring", i.e. the wiring of power and ground connections originate from one "star point" which is typically a power supply. Fig. 6.14 shows a schematic of the star-wiring concept. Fig.
  • Page 69 Fig. 6.16 shows an example of how to connect a flash light and a trigger source to the camera using star-wiring. The trigger in this example is generated from a light barrier. Note how the power and ground cables are connected to the same power supply. S t a r t P o i n t 2 o w e r S u p p l y S T R...
  • Page 70 6 Hardware Interface An example of improper wiring that causes a ground loop is shown in Fig. 6.17. C o n n e c t i n g C A M _ G N D a n d G r o u n d l o o p I S O _ G N D t h e w r o n g w a y 1 s o l a t o r I S O _ I N...

  • Page 71: Plc Connections

    6.6 PLC connections The PLC (Programmable Logic Controller) is a powerful device where some camera inputs and outputs can be manipulated and software interrupts can be generated. Sample settings and an introduction to PLC are shown in Section 7.7. PLC is described in detail in the document [PLC]. Name Direction Description...
  • Page 72 6 Hardware Interface...

  • Page 73: Software

    Software 7.1 Software for Photonfocus GigE Cameras The following packages for Photonfocus GigE (G2 / H2) cameras are available on the Photonfocus website (www.photonfocus.com): eBUS SDK Contains the Pleora SDK and the Pleora GigE filter drivers. Many examples of the SDK are included.

  • Page 74: Pf_Gevplayer Main Window

    7 Software 7.2.1 PF_GEVPlayer main window After connecting the camera (see Chapter 3), the main window displays the following controls (see Fig. 7.1): Disconnect Disconnect the camera Mode Acquisition mode Play Start acquisition Stop Stop acquisition Acquisition Control Mode Continuous, Single Frame or Multi Frame modes. The number of frames that are acquired in Multi Frame mode can be set in the GEV Device Control with AcquisitionFrameCount in the AcquisitionControl category.
  • Page 75 To have a quick overview of the available categories, all categories should be collapsed. The categories of interest can then be expanded again. If the name of the property is known, then the alphabetical view is convenient. If this is the first time that you use a Photonfocus GigE camera, then the visibility should be left to Beginner.

  • Page 76: Display Area

    7 Software 7.2.3 Display Area The images are displayed in the main window in the display area. A zoom menu is available when right clicking in the display area. Another way to zoom is to press the Ctrl button while using the mouse wheel.

  • Page 77: Get Feature List Of Camera

    7.2.6 Get feature list of camera A list of all features of the Photonfocus GigE cameras in HTML format can be found in the GenICam_Feature_Lists sub-directory (in Start -> All Programs -> Photonfocus -> GigE_Tools). Alternatively, the feature list of the connected camera can be retrieved with the PF_GEVPlayer (Tools ->...

  • Page 78: Persistent Ip Address

    7 Software The calibration values of the FPN calibration are not stored with UserSetSave (or CameraHeadStoreDefaults). Use the command Correction_SaveToFlash for this (see Correction_SaveToFlash). 7.6 Persistent IP address It is possible to set a persistent IP address: Set GevPersistentIPAddress (in category TransportLayerControl) to the desired IP address. Set GevPersistentSubnetMask (in category TransportLayerControl) to the sub net mask.

  • Page 79: Plc

    7.7 PLC 7.7.1 Introduction The Programmable Logic Controller (PLC) is a powerful tool to generate triggers and software interrupts. A functional diagram of the PLC tool is shown in Fig. 7.4. The PLC tool is described in detail with many examples in the [PLC] manual which is included in the PFInstaller. The AB Trigger feature is not available on all camera revisions, see Appendix B for a list of available features.

  • Page 80: Plc Settings For Iso_In0 To Plc_Q4 Camera Trigger

    7 Software Identify the PLC notation of the desired input. A table of the PLC mapping is given in Section 6.6. In our example, ISO_IN0 maps to A0 or Line0. Select a Signal Routing Block (SRB) that has a connection to the desired PLC input and connect it to the PLC input.

  • Page 81: Plc Settings For A/B Trigger From Differential Inputs

    7.7.3 PLC Settings for A/B Trigger from differential inputs This settings connects the ISO_INC differential inputs to the A/B camera inputs. ISO_INC0 is mapped to the A signal and ISO_INC1 to the B signal, see Table 7.2 (the visibility in the PF_GEVPlayer must be set to Guru for this purpose).

  • Page 82: Plc Settings For A/B Trigger From Single-Ended Inputs

    7 Software 7.7.4 PLC Settings for A/B Trigger from single-ended inputs This configuration maps the single-ended inputs to the A/B camera inputs: ISO_IN0 is mapped to the A signal and ISO_IN1 to the B signal see Table 7.3 (the visibility in the PF_GEVPlayer must be set to Guru for this purpose).

  • Page 83: Miscellaneous Properties

    7.8 Miscellaneous Properties 7.8.1 PixelFormat The property PixelFormat (in category ImageFormatControl) sets the pixel format. For 10 bits and 12 bits there is a selection of plain or packed format. The plain format uses more bandwidth than the packed format, but is easier to process in the software. Table 7.4 shows the number of bits per pixel to are required for a pixel format.
  • Page 84 7 Software...

  • Page 85: Mechanical Considerations

    Mechanical Considerations 8.1 Mechanical Interface During storage and transport, the camera should be protected against vibration, shock, moisture and dust. The original packaging protects the camera adequately from vibration and shock during storage and transport. Please either retain this packaging for possible later use or dispose of it according to local regulations.

  • Page 86: Adjusting The Back Focus

    8 Mechanical Considerations 8.2 Adjusting the Back Focus The back focus of your Photonfocus camera is correctly adjusted in the production of the camera. This section describes the procedure to adjust the back focus if you require that because e.g. you are using a special lens.

  • Page 87: Warranty

    Warranty The manufacturer alone reserves the right to recognize warranty claims. 9.1 Warranty Terms The manufacturer warrants to distributor and end customer that for a period of two years from the date of the shipment from manufacturer or distributor to end customer (the "Warranty Period") that: •...
  • Page 88 9 Warranty...

  • Page 89: References

    References All referenced documents can be downloaded from our website at www.photonfocus.com. AN007 Application Note "Camera Acquisition Modes", Photonfocus, March 2004 GEVQS GEVPlayer Quick Start Guide, Pleora Technologies. Included in eBUS installer. MAN051 Manual "Photonfocus GigE Quick Start Guide", Photonfocus PLC iPORT Programmable Logic Controller Reference Guide, Pleora Technologies.
  • Page 90 10 References...

  • Page 91: A Pinouts

    Pinouts A.1 Power Supply Connector The power supply connectors are available from Hirose connectors at www.hirose-connectors.com. Fig. A.1 shows the power supply plug from the solder side. The pin assignment of the power supply plug is given in Table A.2. It is extremely important that you apply the appropriate voltages to your camera.
  • Page 92 A Pinouts I/O Type Name Description CAMERA_GND Camera GND, 0V CAMERA_PWR Camera Power 12V..24V ISO_OUT0 Default Strobe out, internally Pulled up to ISO_PWR with 4k7 Resistor ISO_INC0_N INC0 differential input (G2: RS-422, H2: HTL), negative polarity ISO_INC0_P INC0 differential input (G2: RS-422, H2: HTL), positive polarity ISO_PWR Power supply 5V..24V for output signals;...

  • Page 93: B Camera Revisions

    Camera Revisions B.1 General Remarks This chapter lists differences between the revisions of the camera models. List of terms used in this chapter: Standard Trigger Standard trigger features. Trigger Source: Free running, Software Trigger, Line1 Trigger, PLC_Q4 Trigger. Exposure Time Control: Camera-controlled, Trigger-controlled.
  • Page 94 B Camera Revisions...

  • Page 95: C Document Revision History

    Document Revision History Revision Date Changes April 2015 First version...
