Dynex DX-PCCNG50 Quick Setup Manual

DX-PCCNG50
PCI-Express Gigabit Ethernet
Adapter Card
PACKAGE CONTENTS
• One DX-PCCNG50 PCI-Express Gigabit
Ethernet Adapter card
• Quick Setup Guide
• One Resource CD for DX-PCCNG50,
including:
• Drivers
• User Guide
• Other Helpful Information
Before using your new product, please read
these instructions to prevent any damage.
QUICK SETUP GUIDE
FEATURES
• Integrated 10/100/1000Mbps transceiver
• Supports PCI Express 1.1
• Fully compliant with IEEE 802.3, IEEE 802.3u,
IEEE802.3ab
• Auto-Negotiation with Next Page capability
• Supports pair swap/polarity/skew correction
• Crossover Detection & Auto-Correction
• Wake-on-LAN and remote wake-up support
• Microsoft NDIS5, NDIS6 Checksum Offload
(IPv4, IPv6, TCP, UDP) and Segmentation
Task-offload (Large send v1 and Large send
v2) support
• Supports Full-Duplex flow control
(IEEE802.3X)
• Supports IEEE 802.1p Layer 2 Priority
Encoding and IEEE802.1Q VLAN tagging
• Supports power down/link down power
saving
• Support drivers for Windows Vista (32 and
64 bit), Windows 7 (32 and 64 bit), and
Windows 8 (32 and 64 bit)
SYSTEM REQUIREMENTS
• Windows® 8.1 (32 and 64 bit), Windows® 8
(32 and 64 bit), Windows® 7 (32 and 64 bit),
or Windows Vista® (32 and 64 bit)
• PCI Express-enabled system with an
available PCI Express x1 slot. (We
recommend PCI Express 2.0)
INSTALLING THE HARDWARE
1 Turn off your computer and unplug the
power cord and all cables.
2 Remove your computer's case cover. See
your computer's user guide for information
about removing the cover.
3 Locate an available PCI Express slot, remove
the screw that secures the backplate (the
small piece of metal that covers the opening
for the PCI card on the back panel of your
computer), then remove the backplate.
4 Carefully insert the adapter into the PCI
Express slot, seating it firmly into the slot.
5 Secure the adapter to the case using the
screw you removed from the backplate.
6 Reinstall your computer's case cover.
7 Plug in the power cord and other cables,
then turn on your computer.
