- Page 1 PCI-Express Gigabit Ethernet Adapter Card DX-PCCNG50 U SE R GUIDE Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Legal notices ........... 10 One-year limited warranty - Dynex ......11 Introduction Thank you for purchasing this high-quality PCI-Express Gigabit Ethernet Network Adapter. -
Page 3: Features
Windows® 8 (32 or 64 bit), and Windows® 8.1 (32 or 64 bit) Package contents: • One DX-PCCNG50 PCI-Express Gigabit Ethernet Adapter card • Quick Installation Guide • One Resource CD for DX-PCCNG50, including: • Drivers • User Guide • Other Helpful Information Make sure that the package contains the above items. -
Page 4: Components
DX-PCCNG50 Components Card description LED status There are three LEDs: a 10Mbps Link/Act LED, a 100Mbps Link/Act LED, and a 1000Mbps Link/Act LED. The Link/Act LEDs on the adapter card indicate link and activity status. They light when connection has... -
Page 5: Installing Your Pci Express Gigabit Ethernet Adapter Card
PCI-Express Gigabit Ethernet Adapter Card Installing your PCI Express Gigabit Ethernet Adapter Card System requirements • PCI Express-enabled system with an available PCI Express x1 slot. (We recommend PCI Express 2.0) • Windows® 8.1 (32 or 64 bit), Windows® 8 (32 or 64 bit), Windows® 7 (32 or 64 bit), Windows Vista®... -
Page 6: Windows Driver Installation
DX-PCCNG50 Connect an available floppy 4-pin power plug from your PC's power supply to the adapter card's 4-pin power connector. PCI Express slot Secure the adapter to the case using the screw you removed from the backplate. Reinstall your computer's case cover. - Page 7 PCI-Express Gigabit Ethernet Adapter Card To install the Windows driver: Save all files and close all programs. Insert the included resource CD into your optical drive. The driver home page opens. Click Install Driver. The installation wizard opens. Click Next, then follow the on-screen instructions to install the driver. Click Install to begin the installation.
-
Page 8: Troubleshooting
Click Start, right-click Computer (or My Computer), then select Properties. Click Device Manager, then click Network Adapters. If the device has been correctly installed, its sub-entry should be displayed as Dynex PCI-Express Gigabit Ethernet Adapter. To uninstall the Windows driver: Click the Add or Remove Programs tab (Uninstall a Program in Windows 7) in the Windows Control Panel. - Page 9 PCI-Express Gigabit Ethernet Adapter Card System support Windows® 8.1, Windows® 8, Windows® 7, Windows Vista® Indicator LEDs One 10M Link/Act LED, one 100M Link/Act LED, one 1000M Link/Act LED Safety and Emissions Operating temperature 32°F~104°F (0°C~40°C) Storage temperature -4°F~158°F (-20°C~70°C) Operating humidity 10%~90% RH, non-condensing Storage humidity...
-
Page 10: Legal Notices
DX-PCCNG50 Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 11: One-Year Limited Warranty - Dynex
If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own your Dynex Product during the Warranty Period. - Page 12 REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. DYNEX SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS.
- Page 13 1-800-305-2204 (U.S. and Canada) or 01-800-926-3020 (Mexico) DYNEX is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. © 2015 Best Buy. All rights reserved.
