Life 7700C User Manual

Water ionizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Life 7700C

Summary of Contents for Life 7700C

  • Page 3: Table Of Contents

    Table of Contents Safety Guide Parts Guide Name & Function of Ionizer 10-11 Special Installation Notes Conversion from 7700C to 7700UC Installation Instructions Installation Guide Installation of the Pre-filter Internal Filter Replacement LCD Display LCD Functions Special Features Operation Instructions...

  • Page 4: Safety Guide

    Safety Guide - Read Completely Before installation or operation of the LIFE Ionizer®, read this instruction manual completely. Note- Some parts may have been altered to improve product quality, function or ease of use. Symbols Refer to the following key symbols and indicators throughout the manual.
  • Page 5 Improper use may cause bodily injury When drinking Ionized Alkaline Water - Do not take prescription or other medications for approximately one hour before and after drinking water. As with most electrical appliances, electrical parts in this ionizer are electrically live even when the switch is off. This machine should not be repaired or otherwise disassembled by any unauthorized person as it may cause electrical fire or shock, and will void the...
  • Page 6 If the ionizer machine falls into water- 1. Unplug power cord from electrical outlet 2. Wipe the machine down and place in shaded area 3. Contact your LIFE Ionizer dealer Use only (110v) in the U.S.A. and Mexico. Use (100v) in Japan.
  • Page 7 Improper use may cause bodily injury Place machine in an upright position only. Do not install this unit in direct sunlight or near a heater, fireplace or other heat source. Do not use water with a temperature of over 95 degrees Fahrenheit or 35 degrees Celcius.
  • Page 8 Improper use may cause structural damage to the unit or physical injury. Aluminum and brass containers will be tarnished by Alkaline and acidic water. When handling the pH test (reagent drops) 1. Keep away from eye area. If eyes become irritated, flush thoroughly and consult a doctor.

  • Page 9: Parts Guide

    2. Be aware that a 110v outlet (USA) or 220v outlet is required. 3. If after installation the water has an odor, you may need to install a pre-filter. Please consult your LIFE Ionizer® dealer. 4. How to use reagent drops: (BTB Chemical). Put 2-3 drops in approximately 1 ounce of water to be tested.

  • Page 10: Name & Function Of Ionizer

    Name & Function of Unit 1. Front View (3) LCD Screen (1) Main Body (4) Selection/Function (2) Water Outlet Touch Control 2. Internal Filters (5) Sliding Door (6) First Filter (7) Second Filter 7700 www.LifeIonizers.com/Support...
  • Page 11 3. Bottom View (10) Power Cord (11) Power Switch (9) Drain Outlet (8) Water Inlet (1) Main Body (case): Outer shell of the system. (2) Water Outlet: Dispenses alkaline/acid water. (3) LCD Screen: All the functions of system are displayed on the LCD screen.

  • Page 12: Special Installation Notes

    Special Installation Notes • Before installation, check the unit’s voltage setting. This unit is only for use with 110V/220V. • The unit should be installed away from direct sunlight or cold areas, as it may cause damage to the unit. •...

  • Page 13: Conversion From 7700C To 7700Uc

    Conversion from 7700C to 7700UC 1. Snap in plastic adaptor into top of unit where flexible metal hose was in place. 2. Cut a piece of 1/4 inch tubing and connect it to plastic adaptor on top of unit, then insert other end of tubing into the alkaline tubing connection on faucet.

  • Page 14: Installation Instructions

    Use Cold Water Only With Your Ionizer STEP 1: Unscrew the existing aerator from your faucet. STEP 2: Use teflon plumbers tape on the threads. Screw the LIFE Ionizer diverter valve onto your faucet. Three different sized adaptors are included for non-standard sized faucets.

  • Page 15: Installation Guide

    Installation Guide Assembly method of valve for Deck-sink water taps Assembly method of valve for Deck sink water taps Connect by rotation after insertion of rubber packing Screw in the adaptor Cold Water inlet Remove the aerator from Remove the aerator from the water tap. the water tap.

  • Page 16: Installation Of The Pre-Filter

    Installation of the Pre-Filter 1. Cut the tubing leading to the ionizer at the desired location and length. 2. The cap on top of the filter housing is marked “OUT” and “IN”. TOP VIEW OF FILTER HOUSING 3. The tubing coming from the cold water connector needs to be inserted into the side of the housing marked “IN”.

  • Page 17: Internal Filter Replacement

    The unit will not work when the filter life is fully used. 2nd filter: The 2nd filter life is indicated on the right side of the LCD screen. The lights will decrease as the filter life diminishes. When the filter life has 100 liters remaining, there will be a voice message to exchange the filter.

  • Page 18: Lcd Display

    LCD Display LCD Display 1. 1st filter life indicator 7. Operation display lamp 8. 2nd filter life indicator 2. Wash lamp indicator 9. Alkaline/Acid water level 3. Mode display indicator 10. Alkaline water selection lamp 4. Water pH indicator 11. Acid water selection lamp 5.

  • Page 19: Lcd Functions

    • Wash lamp indicator: Lights up when washing function is se- lected and during automatic flushing. • Mode display indicator: Lit while Mode function is being used. • 1st filter life indicator: Shows how much life is remaining for the 1st filter. • 2nd filter life indicator: Shows how much life is remaining for the 2nd filter.

  • Page 20: Special Features

    7. System is self-diagnosing and displays errors on the LCD screen. 8. Dual internal high capacity filters. 9. LCD screen displays remaining filter life for both filters. 10. Voice message prompts for each function. 11. Amount of water dispensed is displayed by per liter minute 12.

  • Page 21: Operation Instructions

    Operation Instructions 1. Touch the main operation control on the front of the unit. • When the powered ON for first time, the unit will flush itself automatically. The “Washing” LED will blink. • Once the system is flushed, it will be in standby mode, select the type of water desired on the touch control panel.

  • Page 22: Amperage/Volume Adjustments/Filter Reset

    Amperage/Volume Adjustments/Filter Reset MACHINE AMPERAGE (PH LEVEL) ADJUSTMENT (Do this to adjust the pH level of water dispensed by the unit.) • Ensure machine is plugged in. • Hold down the "Mode" button for 10 seconds until the mode option appears on screen.

  • Page 23: Operation Warnings/Error Messages

    Do not use well water, underground water, polluted water or metallic water. • Do not use water with a temperature of over 35° Celcius/ 95° Fahrenheit as it may cause damage or short filter life (Room temperature is best). • Do not use pre-ionized water. •...

  • Page 24: Filters

    Filters High Density Sediment Layer Eliminates sediments (mud, rust, sand, etc) 5 microns or larger. Activated Carbon Ultra-fine coconut shell carbon. High Density Sediment Layer Eliminates sediments (mud, rust, sand, etc) 5 microns or larger. Sediment Layer Eliminates sediments (mud, rust, sand, etc) 10 microns or larger.

  • Page 25: Explanation Of Ionized Water

    Explanation of Ionized Water anode cathode During electrolysis, the cathode has a negative charge and produces alkaline ionized water (pH range 7.5~10) with negatively charged hydroxyl ions, and attracts alkaline minerals - such as calcium, potassium, magnesium, and sodium. The anode has a positive charge and produces acidic ionized water (pH range 3.5~6.5) with positively charged hydroxide ions and attracts acidic minerals –...

  • Page 26: Alkaline And Acidic Water Usage Guide

    Alkaline and Acidic Water Usage Guide 1. If the machine has not been used for several days, let the water run on the “Purified Water” setting for at least 3-5 minutes before any operation. 2. First time users who are not familiar with this water are recommended to start with Ionized Alkaline Water level 1 and adjust the quantity or level of wate which might fit you the best.

  • Page 27: Uses Of Ionized Alkaline/Acidic Water

    Uses for Ionized Alkaline Water Highly Ionized Alkaline Water: pH 11.0+ Highly Ionized Alkaline Water is useful for cleaning and preparing food. Food Preparation: Wash Vegetables and fruit. Cleaning: Clean cutting boards with. Good for cleaning oil and tough grime from vents, as well as for general cleaning in the kitchen.
  • Page 28 Plants: Watering plants and flowers. Ionized Alkaline Water extends the freshness and life of plants. Ionized Alkaline Water with a pH level of 9.0 can also restore the health of sick plants. Ionized Alkaline Water stimulates germination and improves seeding development.
  • Page 29 Uses for Acidic Water Water pH: 4.0-6.0 Face wash: The astringent properties of acidic water are effective in toning and firming your skin. Pat the skin and leave to dry. This water is also excellent as a toner after shaving. Hair Care: Use this water to rinse your hair after shampooing.

  • Page 30: Performance Features

    UV Light System- LIFE UV Light Technology™ is an optional feature on our Life Ionizers™. UV light kills cysts and bacteria as the water passes around the light inside the unit. UV Light is being used by major municipal water authorities such as New York City and Orange County, CA as added treatment to disin- fect their water.

  • Page 31: Common Problems And Solutions

    (RO system, sprinkler system, etc) • House water pressure is Call LIFE Ionizer Tech too low. Support for assistance. •Pre-filter and/or unit • If unit has been used for filters are blocked.
  • Page 32 • Call your dealer to place an need to be replaced. unpleasant order for new filters. odor or taste. • Call LIFE Ionizers for a water • Water source requires a quality report for your area. pre-filter or RO* filter.

  • Page 33: Acidic Cleaning Instructions & Routine Maintenance

    A routine acidic cleaning of the ionizer chamber can help maximize the life and performance of your ionizer by reducing the build up of these harmful minerals.

  • Page 34: Frequently Asked Questions

    Frequently Asked Questions Q: What should I expect from drinking Ionized Alkaline Water? A: This will initially depend on what level of strength you begin drinking Ionized Alkaline Water. Ionized Water provides your body with lots of oxygen, which is why it gives us energy. Ionized Water is much smoother tasting than conventional water.
  • Page 35 and strength level 2 (two). Children between the ages of 4 and 12 years of age should never drink Ionized Alkaline Water at strength level 3 (three) or strength level 4 (four). Q: Should I take medication or supplements with Ionized Ionized Alkaline Water? A: You should not drink Ionize Ionized Alkaline Water 45 minutes to 1 hour before or after taking medication or supplements.
  • Page 36 better it is for you because the water is more Alkaline, more Detoxifying, and a stronger Antioxidant that provides your body with more Oxygen. Q: When will I begin noticing the health benefits? A: It varies from person to person. You might start noticing a positive response in as little as one day or within a few weeks.
  • Page 37 Water should be consumed. NEVER DRINK THE ACIDIC WATER. Q: Should Pregnant Women Drink Alkaline Water? A: We at Life Ionizers are often asked the question as to whether alkaline, ionized water should be consumed by a pregnant or lactating woman. We believe the prudent approach is to exclude alkaline, ionized water throughout pregnancy and breast feeding.
  • Page 38 Q: How does a water ionizer work? A: Our counter top Alkaline LIFE Ionizer® 7700 can be directly connected to a diverter valve at the end of your faucet. Connecting directly to your faucet takes about 10-15 minutes and enables your water ionizer to use a two step process.
  • Page 39 Q: How do I know when the filter needs replacing? A: An LED or counter indicator on the front panel gives an indication of remaining filter life. Generally the 1st filter will last for about 8 months, the 2nd filter for about 12 months (when 2.5 gallons of water is produced per...
  • Page 40 Q: What should be done if the machine is not to be used for 7 days or more? A: Remove the filter from the main body, wrap in plastic wrapping, and store in a refrigerator. Remove the power plug. When ready to use again, install the filter and run in the Ionizer in the ‘PURFIED’...
  • Page 41 Q: What is hard water? A: According to the U.S. Geological Survey, more than 85 percent of the United States geography has hard water. Hard water forms when naturally occurring minerals enter water sources. Over time these minerals are absorbed by groundwater.
  • Page 42 Q: Why do I want to adjust the amperage on my Water Ionizer? A: As you know, all water sources are not created equal. Your water source plays an important role on how your water Ionizer creates Ionized Alkaline Water. Being able to adjust the amperage will allow you to find the optimum pH for the best production of Alkaline Ionized water based on your water source.
  • Page 43 Q: How do I set up the pre-filter unit? A: The pre-filter is installed in the supply line on the ionizer. Quick connects are provided for your convenience. Simply push the tubing in the connector and it seals automatically. When installing the filter for the first time, it is suggested to let the filter fill with water for a few minutes before turning on the ionizer.
  • Page 44 Q: What is your return policy? A: We invite you to try out our new range of LIFE Ionizer® and enjoy the benefits for 60 days. We are so sure that you will be satisfied with your ionizer that we offer you a 60-day money back guarantee.
  • Page 45 LIFE Ionizer® authorized repair facility. LIFE Ionizer® will repair or replace any malfunctioning ionizer for the specified time frames disclosed above.
  • Page 47 Contact U 6352 Corte Del Abeto, Suite H Carlsbad, CA 92011 866.321.3116 (Technical Support) 760.585.1692 *When calling technical support please be prepared to give your ionizer serial number located on the back of the unit. www.LifeIonizers.com/Support...
  • Page 48 revised 10-5-11...

This manual is also suitable for:

7700uc
