- Page 2 Replacing the HDD/ODD Cage and Top Panel Foreword Thank you for your purchase of this Streacom product, every care has been taken to ensure that it meets with the high standards that we have set for ourselves. Should you have any questions that are not covered in this user guide, support can be offered via email through our website at www.streacom.com...
- Page 3 Specification Chassis Material Aluminum Available Colours Silver / Black - sandblast finish Motherboard Compatibility Mini ITX HDD Drive Support 3 x 2.5" (depending on components installed) ODD Drive Support Slot loading drive, universal eject button Cooling Method 1 x 40x40x10mm or 1 x 60x60x10mm fan (not Included) Dimensions 197 ×...
- Page 4 Removing the Top Panel The top panel is held in place by 2 long screws that are accessed from the bottom of the case. Turn the chassis upside down and remove the 2 screws from either side. The top panel can now be lifted off the chassis. M3 x 5 M3 x 5 Removing the HDD/ODD Cage...
- Page 5 Installing the Motherboard Locate the I/O shield that is supplied with your motherboard and firmly push it in place. Ensure that it clicks in place fully otherwise the motherboard will be difficult to fit. M3 x 4 Carefully lower the motherboard into the chassis, with the I/O port side leading so that the ports can fit into the I/O shield.
- Page 6 Installing the HD and OD Drives Depending on the type of components fitted, you can install a maximum of 3 x 2.5" hard drives and 1 slot loading optical drive. If you are using a low profile CPU cooler, up to 2 hard drives can be fitted under the cage and should be installed prior to fitting the optical drive.
- Page 7 Replace the HDD/ODD Cage M3 x 5 With the HDD/ODD installed, the cage can now be replaced into the chassis. Carefully lower the assembly ensuring cables are routed correctly and that the ODD eject button clears the front of the chassis and slots into the hole.
- Page 8 Melbournestraat 56, 3047 BJ Rotterdam, The Netherlands www.streacom.com V1.12.09...
