- Page 1 Interpreters Control Console Manual and User Guide MAN 152H...
- Page 2 IC-2 Interpreters Control Console MAN 152H...
-
Page 3: Table Of Contents
IC-2 Interpreters Control Console IC-2 Interpreters Control Console Contents Important Safety Instructions ..............................4 Safety Cautions ................................4 Safety Warnings ................................4 Recycling Instructions ..............................5 Overview ....................................6 System Includes ..................................6 Top Panel Controls.................................. 7 Mode Selection Controls ............................7 Microphone Controls .............................. -
Page 4: Important Safety Instructions
IC-2 Interpreters Control Console Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Safety Cautions This product is designed to amplify sounds to a high volume level which could potentially cause hearing damage if used improperly. -
Page 5: Recycling Instructions
Product Recycling for Customers in the European Union: Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the equipment to a electronics recycling center; OR return the product to the factory for proper disposal. -
Page 6: Overview
· Selectable feedthrough ( automatic routing ) of the Floor signal onto unoccupied channels. The IC-2 can be used with Williams Sound FM, IR and Digi-Wave transmitters for portable installations. It is designed to meet international standards for interpretation consoles and is backed by a 5-year warranty. If you need assistance with this product, contact Williams Sound Customer Service at 1.800.843.3544 or 952.943.2252. -
Page 7: Top Panel Controls
IC-2 Interpreters Control Console Top Panel Controls Figure 2: Top Panel BASS TREBLE BASS TREBLE VOLUME VOLUME CH1 / CH2 CH1 / CH2 OUTPUT OUTPUT RELAY INPUT RELAY INPUT FLOOR INPUT MIC ON MIC ON FLOOR INPUT MUTE INTERPRETER (B) INTERPRETER (A) “CH2 IN USE”... -
Page 8: Back Panel Controls
· Floor XLR Jack – balanced or unbalanced audio signal in from the PA system, mixer, or microphone. Note: while the IC-2 will work with balanced or unbalanced audio on Floor In; balanced, line-level audio is desirable for best performance. -
Page 9: Side Panel Controls
IC-2 Interpreters Control Console Side Panel Controls Figure 4: Side Panel XLR MIC JACK XLR MIC LEVEL PHANTOM POWER ELECTRET MIC JACK ELECTRET MIC AND HEADPHONE JACK ELECTRET MIC LEVEL HEADPHONE JACK A167 Switches · Phantom Power ( +12 V ) – enables 12VDC “phantom” power to XLR Microphone Input. -
Page 10: Signal Setup
IC-2 Interpreters Control Console Signal Setup Figure 5: Signal schematics SIGNAL DISTRIBUTION FLOOR FLOOR FLOOR RELAY RELAY IC-2 IC-2 IC-2 INPUT SELECTION FLOOR SELECTED IC-2 FLOOR IN INTERPRETER CH2 SELECTED IC-2 (FROM IC-2 BUS) INTERPRETER OUTPUT SELECTION CH1 ON (DEFAULT SETTING, NO LIGHT) -
Page 11: Configurations
Simple Configuration Instructions Plug the line cord into the TFP 044 power supply that comes with your IC-2. Connect the plug on the power supply to the DC power jack on the rear panel of the IC-2. Plug the line cord into an AC power outlet (100 to 240 V, 50-60Hz). -
Page 12: Bilingual Configuration Instructions
IC-2 Interpreters Control Console Bilingual Configuration Instructions Connect a transmitter to the CH2 Out XLR jack and set it up according to its instructions. Assign a language to each output channel. Example: CH1 Out is Spanish, and CH2 Out is English. Have the interpreters enable CH2 Output to interpret into English, and disable CH2 Output to interpret into Spanish. - Page 13 IC-2 Interpreters Control Console Figure 7: Bilingual Configuration B ENGLISH SPANISH – – S et – – – S et – ENGLISH SPANISH FLOOR INPUT SELECTED INTERPRETER HEARS SPANISH CH2 OUTPUT SELECTED (LIGHT ON) INTERPRETER SPEAKS ENGLISH FLOOR FEEDTHROUGH TO CH1 OUT (ENABLED)
-
Page 14: Multilingual System Setup
Multilingual (Multi-Unit) System Setup In multilingual configuration, the audience needs to listen to interpretations of the presentation in multiple languages. When IC-2 interpreter consoles are set up as a system, CH2 audio is shared between them. Any interpreter can work on this interlocked bus, providing a relay for all others. -
Page 15: Multilingual Configuration Instructions
Connect the audio signal from the PA system or mixer to the first unit in the system. Connect the IC-2 Bus Out on this unit to the IC-2 Bus In on the second unit using the CAT-5 cable included with your system. -
Page 16: Specifications
+19dBu IC-2 Bus In / Out CAT5 8p8c RJ45 female receptacle, distributes balanced line level Floor and Relay audio to another IC-2 XLR Microphone Inputs 3-pin XLR female jack, balanced (or unbalanced) input. Switchable 12VDC simplex power. Variable gain of 58 dB, 2.4k Ω... -
Page 17: Faqs
A: The IC-2 has a protection circuit built in that will shut down the headphone circuitry if a bad headset is plugged in ( one that would damage circuitry ). If you experience intermittent audio on one or both sides of the console, or both headphones turn off, it’s probably thermal shutdown feature kicking in. -
Page 18: Limited Warranty
IC-2 Interpreters Control Console · Unplug the IC-2’s power and plug it back in (this will reset the audio chip and turn it back on after the shutdown). · Check to see if the problem has gone away. If not, repeat with the other headset. - Page 19 IC-2 Interpreters Control Console your warranty begins. Please take a moment to fill it out and mail the enclosed card. You may also register your product online: http://www.williamssound.com/Warranty-registration This information will help us serve you better in the future. Thank you!
- Page 20 IC-2 Interpreters Control Console 10300 Valley View Rd • Eden Prairie, MN 55344 800-328-6190 / 952-943-2252 • FAX: 952-943-2174 www.williamssound.com ©2012 Williams Sound • All Rights Reserved MAN 152G...
