- Page 2 This manual explains how to operate the KT-X bipedal humanoid robot with a PS2 gamepad controller. Step 1: Make sure the KT-X battery is fully charged the controller programs have been uploaded into the robot. Step 2: Place the CPU rotary switch to the desired position. Note: only positions with values assigned during the motion programming phase of the setup will be assigned controller values.
- Page 3 Your KT-X should have sprung to life at this point. If not, go back and assess the following: 1. The robot is turned on. 2. Both the battery on the robot and inside the controller is fully charged. 3. The upload to the robot’s CPU was successful.
- Page 4 Digital Combat Mode Hold down select and press the button as shown above to digital combat mode. Punch Digital Combat Mode Walk forward L. Slap Turn left R. Slap Turn Right Take Walk backward Down Push inward to raise from Push inward to raise from a face up position a face down position...
- Page 5 Digital Soccer Mode Hold down select and press the button as shown above to digital soccer mode. Quick Dribble Walk forward Digital Soccer Mode Goal Block Left Turn left Goal Block Right Turn Right Middle Walk backward Save Push inward to raise from Push inward to raise from a face up position a face down position...
- Page 6 Rotary Switch Position “1” Analog Action Mode Hold down select and press the button as shown above to activate analog action mode. Technique: Front flip by dance holding Action Mode Walk forward down R1 Canon and pushing Turn left this button. Greeting Turn Right Intro...
- Page 7 Analog Combat Mode Hold down select and press the button as shown above to analog combat mode. Technique: change Punch direction of Digital Combat Mode Walk forward slap by L. Slap holding Turn left down R1. R. Slap Turn Right Take Technique: Walk backward...
- Page 8 Analog Soccer Mode Hold down select and press the button as shown above to analog soccer mode. Quick Dribble Walk forward Digital Soccer Mode Goal Block Technique: Turn left Left Power kick by holding Goal Block Turn Right down R1. Right Walk backward Middle...
- Page 9 Step 3: Place robot on flat, open surface Step 4: Turn on robot. He will sit down autonomously, so please do not touch, unless he falls over. Contact: KumoTek Robotics 1601 N. Glenville Dr. Ste. 105 Richardson, Texas 75081 USA Tel: 972-664-9263 Email: services@kumotek.com...
