OWNER´S MANUAL
Now, as always, speakers form the most important link in a stereo and home theater
system. Therefore, they should be positioned and connected with care. It is our hope
that the information contained within this manual will help you in setting up your new
speakers and provide you with many years of listening pleasure.
Your Vienna Acoustics Team
CABINETS
For WALTZ Grand, the same outstanding veneer wrapping technique as for all our other
speakers is used, and the same high grade quality in finish and workmanship is
executed.
Just like all the other Vienna Acoustics speakers, WALTZ Grand features massive and
inert cabinet construction. Vienna Acoustics cabinets are designed with the latest
computer modeling techniques and use a combination of amorphous materials in order
to ensure that they are both stiff and well damped. Additionally, our designs feature
narrow front baffles in order to promote accurate imaging. The combination of precise
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vienna Acoustics WALTZ Grand
Summary of Contents for Vienna Acoustics WALTZ Grand
- Page 1 Your Vienna Acoustics Team CABINETS For WALTZ Grand, the same outstanding veneer wrapping technique as for all our other speakers is used, and the same high grade quality in finish and workmanship is executed.
- Page 2 The speaker comes with a set of two banana plugs in which the wire is inserted and held in place by screwing down the insert post. WALTZ Grand offers two possibilities of input sockets, necessitated by the options of parallel and angled wall mounting.
- Page 3 1. OnWall application: 8 positions: 4 x 90 degrees, and in each of the 4 positions is the possibility to angle WALTZ Grand towards or away from the listener, or parallel to the wall. 2. Stand alone application, for placing on top of a TV or in a bookshelf.
- Page 4 ACCESSORIES IN PAPER BOX Wall mounting device: 1 pc. for on-wall application. Knurled screws: 2 pcs. for connecting the cabinet with the wall mounting device. Banana plugs: 2 pcs. for connecting the speaker cables. Teethed washer: 2 pcs. must be used to prevent loosening of the knurled screws. American wall mounting screws plus wall mounting anchors: 2 pcs.
- Page 5 MOUNTING àAfter placing the wall-mounting anchor into the wall, fix the wall-mounting device with the wall mounting screws. ATTENTION: Use the inner, longer hole of the wall-mounting device for vertical positioning. Use the outer, round hole just for center position (horizontal positioning). Center position (horizontal) Vertical positioning guide ways...
- Page 6 Knurled screws Teeth washers Wall mounting device ATTENTION: For safety reasons it is necessary to check the knurled screws, which fix the speaker to the wall-mounting device, twice a year. Keeping the speaker secure depends: 1. on the force you are able to apply on the screw 2.
