M
ake sure to read the Safety Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for future reference.
S
ee the label attached on the product and give the information to your dealer when you ask
for service.
User's Guide
M2900S
M3800S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2900S and is the answer not in the manual?

Questions and answers

Related Manuals for LG M2900S

Summary of Contents for LG M2900S

  • Page 1 Safety Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service. User’s Guide M2900S M3800S...

  • Page 2: Using The Remote Control

    Using the Remote Control Name of the Remote Control Buttons • Power On/Off Button • Source Button Select input source (RGB, DVI) • Menu Button OSD On/ Off Sub OSD Menu out • button Zoom Hot key (Normal Zoom Full) * Only OSD menu off Inserting batteries into remote control.

  • Page 3: Name And Function Of The Parts

    Name and Function of the Parts * The product image in the user’s guide could be different from the actual image. Rear View AC-IN DVI IN RGB IN RS-32C IN REMOTE CONTROL IN DVI, RGB Ports RS-232C Serial Port Wired Remote Control Port Power Connector : Connect the power cord...

  • Page 4: Connecting To External Devices

    Connecting to External Devices When Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. When connecting with the D-Sub signal input cable. (RGB) RGB IN Rear side of the product.
  • Page 5 Connecting to External Devices Turn on power by pressing the power button on the product. Turn on the PC. To change input source Press the SOURCE button on the remote control to select the input signal. Or, press the SOURCE button on the bottom of the product. DVI signal D-Sub signal •...
  • Page 6 Connecting to External Devices VESA FDMI wall Mounting This product supports a VESA FDMI compliant mounting interface. These mounts are purchaed separately and not available from LG. Refer to the instructions included with hte mount for more info.

  • Page 7: User Menus

    User Menus Screen Adjustment options • Press this button to turn on the power. Press this button again to Power Button turn it off. • This Indicator lights up green when the display operates normally(on Power Indicator mode). If the display is in sleep (Energy Saving) mode, this indicator color changes to amber.
  • Page 8 User Menus Screen Adjustment options To change input source depending on connected signal. SOURCE Button Press the SOURCE button on the remote control to select the input signal. Or, press the SOURCE button on the bottom of the product. DVI signal Digital signal IR Receiver •...

  • Page 9: Osd Menu

    User Menus OSD Menu Icon Adjusts screen brightness, contrast and color that you prefer. PICTURE Adjusts the screen size. ZOOM Adjusts the timer options. TIMER Adjusts the OSD image. Note OSD(On Screen Display) The OSD function enables you to adjust the screen status conveniently since it provides graphical presentation.

  • Page 10: How To Adjust The Osd (On Screen Display) Screen

    How to adjust the OSD (On Screen Display) screen MENU Move where Pops up Select a the menu you want to menu icon screen adjust Press the MENU Button, then the main menu of the OSD appears. To access a control, use the When the icon you want becomes highlighted, press the Use the Buttons to adjust the item to the desired level.

  • Page 11: Adjusting Screen Color

    User Menus Adjusting Screen Color P I C T U R E C o n t r a s t B r i g h t n e s s C o l o r T e m p . H - P o s i t i o n V - P o s i t i o n C l o c k...
  • Page 12 Adjusting Screen Color P I C T U R E C o l o r T e m p . U s e r - R U s e r - G U s e r - B Red / Green / Blue Set your own color levels.

  • Page 13: Adjusting Screen Size

    Adjusting Screen size Resolution Z O O M R e s o l u t i o n M o d e Z o o m F i n e Move Z O O M R e s o l u t i o n S e t u p M o d e Move Z O O M...
  • Page 14 When an image created based on M2900S model resolution (1366 X 480) Zoom and an image based on M3800S model resolution (1366 X 398) are used in different models, this function adjusts an image to fit to the screen size without cutting it or leaving any empty space on screen.

  • Page 15: Adjusting The Timer Function

    Adjusting the timer function T I M E R C l o c k O n T i m e O f f T i m e F u n c t i o n Move Clock If the current time is incorrect, reset the clock manually. 1) Press the MENU button and then use 2) Press the button and then use...

  • Page 16: Adjusting Osd Image

    User Menus Adjusting OSD image O S D S e t I D H - P o s i t i o n V - P o s i t i o n O n - S c r e e n T i m e H a l f t o n e F a c t o r y R e s e t Move...

  • Page 17: Troubleshooting

    Troubleshooting No image is displayed G Is the product power cord connected? G Is the power indicator light on? G Power is on, power indicator is green but the screen appears extremely dark. G the power indicator amber? G Does the 'Out of range' message appear? G Does the 'no signal' message appear? 'Unknown Product' message appears when the product is connected.

  • Page 18: The Screen Image Looks Abnormal

    Troubleshooting The screen image looks abnormal. G Is the screen position wrong? G Do thin lines appear on the background screen? G Horizontal noise appears or the characters look blurred. G The screen is displayed abnormally. After-image appears on the product. G After-image appears when the product is turned off.

  • Page 19: Screen Color Is Abnormal

    Troubleshooting Screen color is abnormal. G Screen has poor color resolution (16 colors). G Screen color is unstable or mono- colored. G Do black spots appear on the screen? • Set the number of colors to more than 24 bits (true color) Select Control Panel –...

  • Page 20: Specifications

    The product specifications can change without prior notice for product improvement. M2900S LCD Panel 29.1 inches (73.95 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 73.95 cm 0.17025 mm X RGB X 0.51075 mm (Pixel Pitch)
  • Page 21 The product specifications can change without prior notice for product improvement. M3800S LCD Panel 38.1 inches (96.89 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 96.89 cm 0.227 mm X RGB X 0.681 mm (Pixel Pitch) Power Rated Voltage Power Consumption On Mode...
  • Page 22 The product specifications can change without prior notice for product improvement. Video Signal Max. Resolution Recommended Resolution RGB : 1360 X 768 @60Hz Horizontal Frequency Vertical Frequency Synchronization Type Separate/Digital Input Connector Environmental Operational Condition Temperature: 5˚C ~ 35˚C , Humidity: 10% ~ 80% Conditions Storage Condition NOTE...

  • Page 23: Power Indicator

    Specifications PC Mode – Preset Mode Horizontal Frequency Preset mode (kHz) 31.469 640 x 480 31.468 720 x 400 31.5 720 x 400 37.354 800 x 600 37.879 800 x 600 47.816 1024 x 768 48.363 1024 x 768 47.72 1360 x 768 Power Indicator Mode...

  • Page 24: Controlling The Multiple Product

    Controlling the Multiple Product RS-232C Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. Connecting the cable Connect the RS-232C cable as shown in the picture. * The RS-232C protocol is used for communication between the PC and product.
  • Page 25 Controlling the Multiple Product RS-232C Command Reference List 01. Power 02. Source 03. Brightness 04. Contrast 05. Color Temperature 06. Resolution 07. Zoom 08. Auto Adjust COMMAND1 COMMAND2 DATA(ASCII) 000 - 001 000 - 001 000 - 100 000 - 100 000 - 003 000 - 002 000 - 002...
  • Page 26 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol Transmission [Command1][Set ID][Command2][Data][Cr] * [Command 1]: First command. (j) * [Command 2]: Second command. * [Set ID]: Set up the Set ID number of product. range : 00~99. by setting '0', server can control all products. * In case of operating with more than 2 sets using set ID as '0' at the same time, it should not be checked the ack message.
  • Page 27 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 01. Power(Command : k) To control Power On/Off of the Set. Transmission [j][Set ID][k][Data][Cr] Data(ASCII) 000 : Power Off Acknowledgement [OK] 02. Source (Command : l) To select input source for the Set. You can also select an input source using the SOURCE button on the remote control.
  • Page 28 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 03. Brightness(Command : m) To adjust screen brightness. You can also adjust the brightness in the Picture menu. Transmission [j][Set ID][m][Data][Cr] Data(ASCII) Min : 000 ~ Max : 100 Acknowledgement [OK] 04.
  • Page 29 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 05. Color Temperature (Command : p) To adjust the screen color temperature. Transmission [j][Set ID][p][Data][Cr] Data (ASCII) 000 : Normal 001 : Cool 002 : Warm 003 : User Acknowledgement [OK] 06.
  • Page 30 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 07. Zoom (Command : r) To adjust the enlarged or reduced areas on the screen when the product is in Zoom mode. Transmission [j][Set ID][r][Data][Cr] Data (ASCII) 000 : Normal 001 : Zoom 002 : Full Acknowledgement [OK]...

  • Page 31: Remote Control

    Remote Control Connect your wired remote control to Remote Control port on the Product. Output waveform single pulse, modulated with 37.917KHz signal at 455KHz Configuration of frame • 1st frame Lead code custom code C0 C1 C2 C3 C4 C5 C6 C7 C0 C1 C2 C3 C4 C5 C6 C7 D0 D1 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7 Lead code Bit description •...
  • Page 32 Remote Control Code(Hexa) Function POWER ON/OFF SOURCE MENU AUTO ADJUST IR Codes Note (Menu Navigation, R/C Button (Menu Navigation) R/C Button (Increment Value, Select menu item) R/C Button (Decrement Value, Select menu item) R/C Button PR/C Button (Power On/Off) R/C Button (D-Sub, DVI) R/C Button (Menu On/Off) Discrete IR Code (D-Sub Only) Zoom Hot key...
