LG M2294A User Manual

LG M2294A User Manual

Hide thumbs Also See for M2294A:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Make sure to read the Safety Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
See the label attached on the product and give the information to your dealer when you ask for
service.
User's Guide
M1994A
M2294A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2294A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG M2294A

Summary of Contents for LG M2294A

  • Page 1 User’s Guide M1994A M2294A Make sure to read the Safety Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. See the label attached on the product and give the information to your dealer when you ask for...

  • Page 2: Before Connecting To The Pc

    Before Connecting to the PC Stand Installation Before setting up the product, ensure that the power supply, the computer system, and other attached devices is turned off. Carefully place the product screen side down on a cushioned surface that will protect product and screen from damage.

  • Page 3: Detaching Stand

    Before Connecting to the PC Detaching Stand Before setting up the product, ensure that the power supply, the computer system, and other attached devices is turned off. Place the set screen side down on a Detach the monitor to the Stand cushion or soft cloth.

  • Page 4: Positioning Your Display

    Before Connecting to the PC Before setting up the product, ensure that the power supply, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range 12°~ 18°...

  • Page 5: Name And Function Of The Parts

    Name and Function of the Parts Name of the Remote Control Buttons TV/PC : TV/PC button Not working POWER TV/PC INPUT POWER INPUT Input Each time you press the Input button it will A.PROG MEMORY/ERASE CAPTION change to Component Component HDMI.
  • Page 6 Name and Function of the Parts Name of the Remote Control Buttons MUTE Switches the sound on or off. Not working. CH ( ) Buttons Up and Down Button. MUTE VOL ( ) Buttons Volume Button ENTER ENTER Button Use when functional adjustment is completed. MENU REVIEW SLEEP...

  • Page 7: Rear View

    Name and Function of the Parts Rear View COMPONENT S-VIDEO RGB IN (PC) DVI-D VIDEO AC IN HDMI AUDIO IN (RGB/DVI) COMPONENT S-VIDEO RGB IN (PC) VIDEO DVI-D AC IN HDMI AUDIO IN (RGB/DVI) Power Connector : Connect the power cord. HDMI Digital Signal Connector DVI Digital Signal Connector AC IN...

  • Page 8: Av Input Terminal

    Name and Function of the Parts AV Input Terminal S-VIDEO S-Video Input Terminal Video Input Terminal VIDEO (MONO) Audio Input Terminal...

  • Page 9: Connecting To External Devices

    Connecting to External Devices Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. Rear side of the product. COMPONENT S-VIDEO RGB IN (PC) DVI-D VIDEO AC IN HDMI AUDIO IN...
  • Page 10 Connecting to External Devices Connect the power cord. Rear side of the product. COMPONENT S-VIDEO RGB IN (PC) DVI-D VIDEO AC IN HDMI AUDIO IN (RGB/DVI) Turn on power by pressing the power button on the product. Power button Turn on the PC. Select an input signal.

  • Page 11: Connecting To Vcr/Dvd

    Connecting to External Devices Connecting to VCR/DVD Connect the video/audio cable as shown in the figure below and then connect the power cord (See page 9). When using the S-Video cable. When using the RCA cable. Connect to the S-Video input terminal to •...
  • Page 12 Connecting to External Devices Connecting to Set-top Box /DVD (480i/576i/480p/576p/720p/1080i) Connect the video/audio cable as shown in the figure below and then connect the power cord (See page 9). Connect the input terminal with a proper color match. • Rear side of the Product Audio Cable Component Cable (Not included)

  • Page 13: When Watching Hdmi From The Dvd/Set-Top Box

    Connecting to External Devices When watching HDMI from the DVD/Set-top Box Connect the HDMI cable as shown in the figure below and then connect the power cord (See page 9). Rear side of the Product HDMI cable (not included) [Set-top Box/DVD] Select an input signal.

  • Page 14: When Watching Rgb/Dvi From The Set-Top Box /Dvd

    Connecting to External Devices When watching RGB/DVI from the Set-top Box /DVD Connect the D-sub cable, RCA/PC cable as shown in the below figure and then connect the power cord. (see page 9) [Rear side of the Product] [Rear side of the Product] AUDIO IN AUDIO IN (RGB/DVI)

  • Page 15: To Arrange The Cables

    To arrange the cables Tie cables together with a cable tie as shown in the illustration. COMPONENT S-VIDEO RGB IN (PC) DVI-D VIDEO AC IN HDMI HDMI AUDIO IN (RGB/DVI) AUDIO IN (RGB/DVI) Cable tie...

  • Page 16: Adjusting The Screen

    Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit • This Indicator lights up blue when the display operates normally Power Indicator (On Mode). If the display is in Sleep (Energy Saving) Mode, this indicator colour changes to amber. Power Button •...
  • Page 17 Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit • ENTER button is usually used in choosing the MENU. ENTER Button When there is no MENU on the screen pushing the ENTER button will give the information about the current input source. Input INPUT Button CVBS, S-Video...

  • Page 18: Osd (On-Screen Display) Menu

    Adjusting the Screen OSD (On Screen Display) Menu Icon Function Description Adjusting the picture function. Picture Adjusting the sound function. Sound Adjusting the time function. Timer Selecting the special function. Special Adjusting the screen function. Screen Note OSD(On Screen Display) The OSD function enables you to adjust the screen status conveniently since it provides graphical presentation.

  • Page 19: Osd (On Screen Display) Screen Tracking Order

    Adjusting the Screen OSD (On Screen Display) Screen Tracking Order ENTER ENTER ENTER ENTER Pop up the Move where Select a menu icon Adjust the status Save Exit from the you want to menu screen adjustment menu screen. adjust • Use the remote control to adjust the OSD screen. Press the MENU Button, then the main menu of the OSD will appear.

  • Page 20: Picture Id Adjust The Picture Function (Rgb-Pc/Dvi-Pc)

    Adjusting the Screen PICTURE ID adjust the picture function (RGB-PC/DVI-PC) APC (Auto Picture Control) The APC function automatically adjusts the screen image quality. • Clear Picture Select this option to display with a sharp image. Clear • Optimum Optimum The most general and natural screen display status.
  • Page 21 PICTURE ID adjust the picture function (RGB-PC/DVI-PC) XD is LG Electronics unique picture improving technology to display a real HD source through an advanced digital signal processing algorithm. It's not available to use this function in RGB-PC or DVI-PC modes.
  • Page 22 Adjusting the Screen PICTURE ID adjust the picture function (AV/Component/RGB-DTV/DVI-DTV/HDMI-DTV) APC (Auto Picture Control) The APC function automatically adjusts the screen Picture image quality. • Clear Clear Select this option to display with a sharp image. Optimum • Optimum Soft The most general and natural screen display Cinema User...
  • Page 23 Adjusting the Screen PICTURE ID adjust the picture function (AV/Component/RGB-DTV/DVI-DTV/HDMI-DTV) Picture XD is LG Electronics unique picture improving technology to display a real HD source through an advanced digital signal processing algorithm. Manual is activated after selecting the user of APC.

  • Page 24: Sound Id To Adjust The Sound Function

    Adjusting the Screen SOUND ID to adjust the sound function Sound Flat DASP Music Balance Movie Sports User MENU DASP The best sound tone quality will be selected automatically depending on the video type that (Digital Auto you're currently watching. •...

  • Page 25: Timer Id To Adjust The Time Function

    Adjusting the Screen TIMER ID to adjust the time function Timer -- : -- AM Clock Off timer On timer Auto off MENU Clock This function is used to set up of current time. You must set the time correctly before using On/Off timer function. 1) Press the MENU button and then use button to select the Timer menu.

  • Page 26: Special Id To Select The Special Function

    Adjusting the Screen SPECIAL ID to Select the special function Special Language Key lock Caption/Text DDC-CI XD Demo MENU To choose the language in which the control names are displayed. Language Key lock Use the buttons to select On or Off. It can be set up so that it can only be used with the remote control.

  • Page 27: Screen Id To Adjust The Screen Function

    Adjusting the Screen SCREEN ID to adjust the screen function Screen To set Auto config. Manual config. Reset MENU Auto This button is for the automatic adjustment of the screen Position, Clock and Phase. (It is not working in RGB-DTV, DVI.) config.

  • Page 28: Troubleshooting

    * Maximum resolution M1994A : RGB : 1440 X 900 @75 Hz DVI : 1440 X 900 @60 Hz M2294A : 1680 X 1050 @60 Hz G Does the 'Check signal cable' • The signal cable between PC and product is not connected.

  • Page 29: The Screen Image Looks Abnormal

    Troubleshooting The screen image looks abnormal. G Is the screen position wrong? • Adjust the Position menu in OSD . • See if the video card resolution and frequency are supported by the product. If the frequency is out of range, set to the recommended resolution in the Control Panel –...

  • Page 30: The Audio Function Does Not Work

    Troubleshooting The audio function does not work. G No sound? • Check if the audio cable is connected properly. • Adjust the volume. • Check if the sound is set properly. G Sound is too low. • Adjust the volume. Screen color is abnormal.

  • Page 31: Specifications

    Specifications The product specifications can change without prior notice for product improvement. M1994A LCD Panel Screen Type 19 inches Wide (48.133 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 48.133 cm Pixel Pitch 0.2835 mm Video Signal Max.
  • Page 32 Specifications The product specifications can change without prior notice for product improvement. M2294A LCD Panel Screen Type 22 inches Wide (55.867 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 55.867 cm Pixel Pitch 0.282 mm Video Signal Max.

  • Page 33: Power Indicator

    1024 x 768 60.123 1024 x 768 67.500 1152 x 864 63.981 1280 x 1024 79.976 1280 x 1024 * 1~13 : RGB mode * 1~12 : DVI mode M2294A Horizontal Vertical Horizontal Vertical Preset mode Frequency Frequency Frequency Frequency Preset mode...
