  • Page 1 MBC-2000A/S...
  • Page 2 Batterie-Ladegerät...
  • Page 3 Batterie-Ladegerät...

  • Page 4: Table Of Contents

    battery charger Please read this manual carefully before starting the system. Keep the manual in a safe place for future reference. If the system is resold, this manual must be handed over to the purchaser along with the system. Contents Notes on using the instruction manual.

  • Page 5: Notes On Using The Instruction Manual

    battery charger Notes on using the instruction manual Notes on using the instruction manual Warning! Safety note: failure to observe this instruction can lead to per- sonal injury or damage to the machine. - The appliance is not intended for use by young children or infirm persons without supervision.

  • Page 6: General Safety Instructions

    General safety instructions battery charger General safety instructions General safety The battery charger may only be used as described in this manual. Warning! Explosive gases can be produced during the charging procedure. Always avoid open flames, sparks or naked light when operating the battery charger (see Fig.

  • Page 7: Proper Use

    Make sure that children have no access to the battery charger. There may be hazards that children cannot detect! Proper use The MBC-2000A/S battery charger may be used to charge batteries of the following types: Lead starter batteries Lead-gel batteries...

  • Page 8: Description

    Description battery charger Description Function The battery charger charges 12-V or 24-V vehicle batteries. It automatically detects a full battery and switches to idle mode. This prevents batteries from being overcharged. The device is protected against incorrect polarity. A LED illuminates when you connect the battery clamps to the wrong poles.

  • Page 9: Using The Battery Charger

    battery charger Using the battery charger Using the battery charger You can use the battery charger either to charge dead batteries or to jump- start vehicles with dead batteries. Charging batteries ➤ Before charging, isolate the vehicle battery from the vehicle’s electrical system so that the system cannot be damaged.
  • Page 10 Using the battery charger battery charger ➤ Check the level of the battery fluid. If the fluid is below the minimum level in one or more cells, add distilled water until the fill mark is reached. Never use normal tap water. ➤...
  • Page 11 battery charger Using the battery charger ✓ The green LED illuminates when the charging procedure is completed and the battery is recharged (Fig. 8 F, Page 3). The device switches to idle mode. Unclamping the battery charger Caution! When unclamping the battery charger, make sure not to cause a short-circuit.
  • Page 12 Using the battery charger battery charger ➤ Connect the black minus clamp of the battery charger to the negative pole (-) of the battery (see Fig. 7, page 3). ➤ Now plug the mains plug into an earthed and properly fuse-protected 240-V mains socket.

  • Page 13: Maintaining And Cleaning The Battery Charger

    battery charger Maintaining and cleaning the battery charger Maintaining and cleaning the battery charger Caution! Do not use any hard or abrasive materials to clean the charger, since they can damage the device. ➤ Clean the battery charger occasionally with a damp cloth. Troubleshooting If you have any detailed questions regarding the battery data, please consult the battery manufacturer.
  • Page 14 Troubleshooting battery charger 24-V battery The multimeter displays a voltage of 20 V or less. ➤ Make sure that the C switch (Fig. 8, page 3) is set to “8 A/24 V”. If the switch is properly set, it means that the battery is defective and cannot be further charged.

  • Page 15: Disposal

    battery charger Disposal Disposal Disposing of packaging material Do not simply throw the packaging material away. Please observe the follow- ing instructions: The cardboard packaging material should be disposed of with other waste paper. Plastic packaging material should be added to other recyclable waste. Ask your local authority for the location of the recycling unit closest to you.

  • Page 16: Technical Data

    Technical data battery charger Technical data Input voltage 240 V AC Rated battery voltage 12 V DC 24 V DC Activation / deactivation voltage 12.7/14.4 V 25.8/28.8 V Charging voltage 14.4 V 28.8 V 14 A Maximum charging current Maximum jump-starting current 70 A 35 A Ammeter display range...
  • Page 17 Headquarters WAECO International GmbH · D-48282 Emsdetten Hollefeldstraße 63 · phone +49-25 72/8 79-0 · fax +49 -25 72/8 79-3 00 E-mail: info@waeco.de WAECO Queensland (Head Office) 21 Taree Street WEST BURLEIGH QLD 4220 Ph: (07) 5507 6000 Fax: (07) 5522 1003 Ausführungen, dem technischen Fortschritt dienende Internet: www.waeco.com Änderungen und Liefermöglichkeiten vorbehalten.
