Wireless system operation.
1
The Sound Machine SM-5 is available with single
or dual built-in Shure wireless receivers. The
instructions on the following pages describe how
to set-up and operate the receiver units and wire-
less transmitters.
Note: Remove antennas before transporting to avoid damage.
Operating the optional wireless mic system.
The built-in wireless receiver(s) turn on automatically
when the Sound Machine is turned "on." Plug the anten-
nas onto the mating connecotors on the SM-5 as follows:
line up the pins, push inward and rotate clockwise a
quarter turn until they snap in place. Orient the antennas
up and out at a slight angle (see photo); single wireless
options will have two antennas, dual wireless will have four. Also, note the location of
the wireless mic volume controls on the Sound Machine's rear panel.
1
2
Features and controls of the built-in wireless receiver.
audio LED: Indicates strength of incoming audio signal:
1
green for normal, amber for strong, red for peak.
ready LED: Green light indicates wireless system is receiving signal.
2
Channel number readout: See "Signal System Setup" on page 11.
3
4
Group and Channel Buttons
Scan: Push and release Group Button to scan for an open group
and channel.
Manual: Push and hold Group Button to select a group. Push
Channel Button to select a channel in the current group.
8
one
wireless mic
wireless mic
3
4
Operating the handheld wireless mic/transmitter.
Indicator LED for Power and battery status
1
two
2
Power Button: Press and hold for 2 seconds to turn "on" (
and hold again to turn "off."
3
Group Button: Changes group setting.
Channel Button: Changes channel and microphone gain setting.
4
5
LED Display: Displays group and channel setting
6
Battery Compartment
Changing batteries.
Install 2 new AA alkaline batteries in the transmitter for best
results; expected battery life is approximately 14 hours.
When the transmitter light
Adjusting Gain Settings.
Hold the channel button
right-hand corner of the LED display, which indicates -10db (lower) gain
setting has been activated.
To change back, hold channel button again for 5 seconds until dot
disapears.
4
3
5
6
1
2
LED
glows red, replace the batteries.
1
4
for 5 seconds. A dot appears on the lower
green), press
9
