20 Volt Worklight
241-0423
OPERATOR'S MANUAL
CAUTION:
Read, understand and follow all safety rules and
instructions before using this tool. These safety instructions should be
followed at all times. Failure to follow these safety instructions could
result in injury to yourself or others. Also, failure to read and follow these
instructions may cause damage to your equipment.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)
Advertisement
Table of Contents
Related Manuals for Master-force flexpower
Summary of Contents for Master-force flexpower
- Page 1 20 Volt Worklight 241-0423 OPERATOR’S MANUAL CAUTION: Read, understand and follow all safety rules and instructions before using this tool. These safety instructions should be followed at all times. Failure to follow these safety instructions could result in injury to yourself or others. Also, failure to read and follow these instructions may cause damage to your equipment.
-
Page 2: Table Of Contents
TAbLE Of CONTENTS Safety Symbols ............Page 2 Safety Instructions . -
Page 3: Safety Symbols
SAfETy SyMbOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage... -
Page 4: Safety Instructions
SAfETy INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. -
Page 5: General Safety Rules
SAfETy INSTRUCTIONS ELECTRICAL SAfETy IMPORTANT SAfETy INSTRUCTIONS 1. Power tool plugs must match the outlet. Never modify the plug in any way. Do not INSTRUCTIONS PERTAINING TO RISK Of use any adapter plugs with earthed fIRE, ELECTRIC SHOCK, OR INJURy TO (grounded) power tools. - Page 6 SAfETy INSTRUCTIONS 3. When the battery pack is not in use, 5. Use only with the batteries and charger keep it away from other metal objects, listed: like paper clips, coins, keys, nails, battery pack Charger screws or other small metal objects that make connection from...
-
Page 7: Safety Rules For Charger
SAfETy INSTRUCTIONS 15. for best results, your battery tool should 4. Do not abuse the cord or charger. Never be charged in a location where the use the cord to carry the charger. Do not temperature is more that 32°f (0°C) but pull the charger cord to disconnect the less that 104°f (40°C). -
Page 8: Overview/Specifications
SAfETy INSTRUCTIONS 10. Do not operate the charger if it has 13. Disconnect the charger from the received a sharp blow, been dropped, or power supply when not in use. This will has otherwise been damaged in any way. reduce the risk of electric shock or Take it to a qualified service technician damage to the charger if metal items for an electrical check to determine if the... -
Page 9: Assembly
SPECIfICATIONS Illumination source Incandescent lamp Run-time More than 2 hours Bulb Type Incandescent ( single contact base) Bulb power 18V DC 300mA Pivoting head 90 degrees Pivoting handle 130 degrees Worklight weight (without battery) 10 oz. ASSEMbLy PACKING LIST WARNING: If any part is broken or missing, DO NOT attempt to attach the Worklight, Operator’s Manual... -
Page 10: Operation
OPERATION TO ATTACH bATTERy PACK ADJUSTING THE WORKLIGHT (fIG. 2) HANDLE AND HEAD (fIGS. 3-4) FIG. 2 FIG. 3 PUSH Handle adjusts 130° PUSH 1. Align the raised portion on the battery pack with the grooves on the bottom FIG. 4 of the worklight, and then attach the battery pack to the worklight as shown. -
Page 11: Maintenance
MAINTENANCE GENERAL MAINTENANCE For Lithium-Ion battery pack storage longer than 30 days: • Store the Lithium-Ion battery pack The tool may be cleaned most effectively where the temperature is below 80°F with compressed dry air. Always wear (26°C) and free of moisture. safety goggles when cleaning tools with •... -
Page 12: Troubleshooting
MAINTENANCE bULb REPLACEMENT (fIG. 5) FIG. 5 To loosen To tighten 1. Remove the battery pack from the worklight. 2. Rotate the reflector counterclockwise to remove it. 3. Remove the old bulb by rotating it. 4. Insert new bulb by rotating bulb in place. 5. - Page 13 NOTES Page 12...
- Page 14 NOTES Page 13...
-
Page 15: Warranty
20 VOLT WORKLIGHT WARRANTy 90-DAy MONEy bACK GUARANTEE: This MASTERFORCE brand power tool carries our 90-DAY Money Back ® Guarantee. If you are not completely satisfied with your MASTERFORCE brand ® power tool for any reason within ninety (90) days from the date of purchase, return the tool with your original receipt to any MENARDS retail store, and we will provide ®... - Page 16 © 2013 Menard, Inc., Eau Claire, WI 54703 09/2013 Page 15...
