Master-force 241-0316 Operator's Manual

12 volt lithium-ion led worklight
Hide thumbs

Advertisement

Quick Links

Download this manual
Operator's Manual
12 VOLT Lithium-Ion LED Worklight
Model No. 241-0316
IMPORTANT :
WARNING! To reduce the risk of injury, user must read instruction manual.
Safety symbols in this manual are used to flag possible dangers. The
safety symbols and their explanations require your full understand-
ing. The safety warnings do not, by themselves, eliminate any dan-
ger, nor are they substitute for proper accident prevention measures.
This Safety Alert Symbol indicates caution, warning, or danger. Failure to
obey a safety warning can result in serious injury to yourself or others. To reduce
the risk of injury, fire, or electric shock, always follow the safety precautions..

Advertisement

loading

Related Manuals for Master-force 241-0316

Summary of Contents for Master-force 241-0316

  • Page 1 Operator’s Manual 12 VOLT Lithium-Ion LED Worklight Model No. 241-0316 IMPORTANT : WARNING! To reduce the risk of injury, user must read instruction manual. Safety symbols in this manual are used to flag possible dangers. The safety symbols and their explanations require your full understand- ing.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Symbols ....................page 2 Safety Instructions ..................page 4 Description .......................page 9 Assembly ......................page 10 Operation ......................page 11 Maintenance ....................page 15 Warranty ......................page 16 INTRODUCTION SAVE THESE INSTRUCTIONS! This cordless worklight has many features for making its use more pleasant and enjoyable.
  • Page 3 Indicates a potentially hazardous situation, CAUTION: which, if not avoided, could result in minor or moderate injury. (Without Safety Alert Symbol) Indicates a CAUTION: situation that may result in property damage. WARNING: To ensure safety and reliability, all repairs should be per- formed by a qualified service technician at an Authorized Service Center.

  • Page 4: Safety Instructions

    .../min Do not expose to rain or use in damp Conditions locations. Alert Read The To reduce the risk of injury, user must read Operator’s operator’s manual. Manual Always wear safety goggles or safety glasses Eye Protection with side shields, or a full face shield when operating this product.
  • Page 5 c) Only use attachments recommended or sold by manufacturer. d) Do not use outdoors. e) For a portable appliance – To reduce the risk of electrical shock, do not put Flashlight and Battery Pack in water or other liquid. Do not place or store appliance where or can fall or be pulled into a tub or sink.
  • Page 6 any other battery packs may create a risk of injury and fire. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
  • Page 7 Remove the battery pack from the Worklight before performing any routine maintenance or cleaning. Do not disassemble the Worklight. Do not place the Worklight or battery pack near fire or heat. They may explode. Do not operate the Worklight or the charger near flammable liquids or in a gaseous or explosive environment.
  • Page 8 Use of an attachment not recommended or sold by the battery-charger manufacturer may result in a risk of fire, electric shock or injury to persons. Do not abuse the cord or charger. Never use the cord to carry the charger. Do not pull the charger cord to disconnect the plug from receptacle.

  • Page 9: Description

    reduce the risk of electric shock or damage to the charger if metal items should fall into the opening. It will also help prevent damage to the charger during a power surge. Risk of electric shock. Do not touch the uninsulated portion of output connector or uninsulated battery terminal.

  • Page 10: Assembly

    SPECIFICATIONS Run-time Approximately 7 hours Worklight Weight Lithium-Ion Battery Type Battery Voltage 12 Volt DC Charger Input 120-Volts, 60 Hz AC only Optimum Charging Temperature 50°F (10° C) -104°F (40°C) ASSEMBLY WARNING! If any part is broken or missing, do not attempt to attach the battery or operate the worklight until the broken or missing part is replaced.

  • Page 11: Operation

    OPERATION BATTERY PROTECTION The integrated protective circuitry prevents the battery pack from extreme temperature, over discharge, and over-charge. To protect the battery from damage and prolong its life, the battery pack circuitry will turn off the battery pack if the temperature becomes too high during use. NOTE: The battery can automatically reset after it cools down.
  • Page 12 5. The charger will communicate with the battery pack to evaluate the condition of the battery pack. 6. The green lights will flash while the battery pack is charging. After charging is complete, the green LED on the charger will be on. The flickering red light indicates a defective battery or a bad connection between the battery and the charger.
  • Page 13 charger. If the LED status reads “defective” a second time, try charging a different battery pack. 2. If a different battery pack charges normally, dispose of the defective battery pack (see Maintenance section). 3. If a different battery pack also indicates “defective,” the charger may be defective.
  • Page 14 WARNING! when placing the battery pack in the tool, be sure that the raised rib on the battery pack aligns with the groove inside the worklight and that the latches snap into place properly. Improper attachment of the battery pack can cause damage to internal components. TURN ON/OFF THE WORKLIGHT (FIG.5) Fig.

  • Page 15: Maintenance

    MAINTENANCE GENERAL MAINTENANCE Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust, oil, grease, etc. WARNING! Do not at any time let brake fluid, gasoline, petroleum-based products, penetrating oils, etc.

  • Page 16: Warranty

    BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING To preserve natural resources, please recycle or dispose of batteries properly. This product contains lithium-ion batteries. Local, state, or federal laws may prohibit disposal of lithium-ion batteries in ordinary trash. Consult your local waste authority for information regarding available recycling and/or disposal options.
