Summary of Contents for Baxi Bermuda PW5 Deluxe
- Page 1 Please keep these Instructions safe. Should you move house, please hand them over to the next occupier. Baxi Bermuda PW5 Deluxe/C5/C5W Fireside Gas Central Heating Unit Installation and Servicing Instructions PW5 Deluxe...
-
Page 2: Natural Gas
Everyone who works at Baxi has a commitment to quality because we know that satisfied customers mean continued success. We hope you get a satisfactory service from Baxi. If not, please let us know. Baxi is a BS-EN ISO 9001... - Page 3 Codes of Practice, most recent version Information should be used In GB the following Codes of Practice apply: Safe Installation Standard Scope BS 6891 Gas Installation. BS 5546 Installation of hot water supplies for The appliance is suitable only for installation in domestic purposes.
-
Page 4: Installation Instructions
Installation Instructions Ventilation Ventilation air supply should be in accordance with the relevant standards. In GB this is BS 5440 Pt. 2. In IE this These instructions must be read in conjunction with the is I.S. 813 “Domestic Gas Installations”. The permanent separate instructions for the boiler section ventilation area size requirements are INTRODUCTION... -
Page 5: Fitting The Fire
Fitting the Fire Bend the central flap of the backing plate and the two securing brackets as shown in the diagram. 675mm Min. in) C5W Fireplace 560mm 660mm Min. Backing Plate Opening (26in) PW5 &C5 (22in) Hearth Level 406-584mm (16-23in) PW5 991mm Min. -
Page 6: Commissioning The Fire
Commissioning the Fire 12.Hand the user the User’s Instructions, explain the operation of the boiler and fire and leave the unit set to suit their requirements. 1. Remove the four radiants from their packing. Fit them by inserting their upper edge into the heat exchanger 13.Leave these instructions with the user or adjacent to and then lowering them on to the burner rail. - Page 7 Fire Flue Spigot Casting Boiler Draught Diverter End Baffle - Fire Flue Spigot Smoke Tube Spillage Clearance Inserted Checked Here Smoke Match Approx. Smoke Match Door - Boiler Fire Boiler Smoke Match Position Combustion Box Fig.7 Spillage Test Fig.6 Pilot Viewing Window Fire Control Knob 76mm Indicator Light...
- Page 8 Servicing the Fire Changing Components CAUTION: ISOLATE THE ELECTRICAL SUPPLY. TURN CAUTION: ISOLATE THE ELECTRICAL SUPPLY, TURN OFF THE GAS SUPPLY, ENSURE THAT THE FIRE IS OFF THE GAS SUPPLY, ENSURE THAT THE FIRE IS COLD, TEST FOR GAS SOUNDNESS UPON RE- COLD, AFTER REPLACING ANY COMPONENTS ASSEMBLY.
-
Page 9: Pilot/A.s.d Assembly
F.F.D./Electro-Magnet Unit individual component.The complete assembly must be replaced in the event of one or other component Piezo Igniter failure(s). Only use a Genuine Baxi Spare Part. Release the thermocouple and pilot feed pipe from the gas tap connection points. Spindle... -
Page 10: Fault Finding Chart
Fault Finding Chart BAXI BERMUDA C5 / C5W / PW5 DELUXE Gas Type G20 (Natural Gas) Does the START pilot ignite ? Turn on gas supply there a strong gas supply spark at the turned on ? electrode ? Adjust spark gap... - Page 11 Does Fire satisfactory the fire remain alight ? Open gas cocks gas cocks fully open ? Contact the Gas meter pressure Supplier correct ? Pipe restricted or supply pressure undersized correct ? pilot flame stable and approx 40mm long ? thermocouple Clean thermocouple tip...
-
Page 12: Short Parts List
Short Parts List BAXI BERMUDA C5 / C5W BAXI BERMUDA PW5 DELUXE Key N Description G.C. Manufact'rs Key N Description G.C. Manufact'rs Part N Part N Dressguard 155 693 043036 Dressguard 155 693 043036 Knob - Gas Tap Control E00-108... - Page 13 C5 Renewal G.C.N 37 077 07A The kit supplied with Renewal appliances provides all the necessary components to fit a Baxi Bermuda firefront to the following Bermuda Boilers. The Renewal Fires may be used with the following 401 & 552...
- Page 14 WALL FIXING Two wall fixing plates are supplied in the Renewal Kit, one for Bermuda 401/552 and one for Bermuda 45/3, 57/3, 45/4, 57/4 & 51/5. BERMUDA 401 & 552 Take the fire support plate from the fire unit packaging Fire Support Plate - Bermuda 401 &...
- Page 15 Bermuda C5 Propane (See diagram). (G.C.No. 37 077 74) Propane appliances can be converted to operate on Natural Gas if required. A conversion kit is available, Baxi Part No 247064. Outercase Pilot Shield Bracket page 15...
- Page 16 B A X I P O T T E R T O N Brownedge Road Bamber Bridge Preston Lancashire PR5 6SN After Sales Service 08706 096 096 Technical Enquiries 08706 049 049 www.baxi.co.uk Comp N 237650 - Iss 11 - 1/03...
