section 1.1 Class A-B amplifiers) the LED will be continuously green when the amplifier has
warmed up and is ready for normal operation. The LED will flicker red with music peaks to indicate that the
amplifier is 2db under clip. The clip indication should be used as a guide that the amplifier is approaching
clip, which should be avoided for audible integrity. If the amplifier detects a fault or over heats
the LED will be continuously red. If the amplifier has over heated and the LED has turned red
refer to section 5.2 Thermal.
5.4

Signal Level

Input sensitivity can be adjusted with the ten position rotary switch recessed in the rear panel
by using a flat bladed screwdriver. The control has an 18dB range in 2dB steps and accurately
sets the SPL level for a known input signal level. With the switch set at the 0dB position, 0dBu
of pink noise will produce 96dB SPL at 1 meter.
5.5 Co ntour Sel ectors
There are two switch groups that control the HF and LF contour settings. These can be used to
adjust for room conditions or personal preference. The nominal flat position is indicated with a
flat line. The spea ker will only operate correctly if the switches are in one of the
positions shown on the rear panel.
6

TECHNICAL SPECIFICATION

S8
Dimensions:
Weight:
Drivers:
Maximum SPL:
music)
Frequency Response:
Connector:
Impedance:
Wiring:
Sensitivity:
Subsonic:
Ultrasonic:
Crossover:
LF EQ:
300(w) x 428(h) x 334(d) mm
17.6 kgs
Bass cone - 1 x 200 mm (8 ")
High Frequency soft dome - 1 x 28 mm (1 ⅛")
110 dB (c) continuous pink noise @ 1 m (122 dB (c) per pair RMS
50 Hz-20 kHz ± 2 dB
XLR and ¼ inch Jack combo socket
10k electronically balanced with RF filters
Ω
Pin 1 ground Sleeve
Pin 2 hot Tip
Pin 3 cold Ring
-12 dBu to +6 dBu for 96 dB SPL @ 1 m set by 10 position rotary switch on
rear
-3dB @ 20 Hz, 24dB/oct
-3dB @ 75kHz, 4dB/oct
1k40
-2/-4 @ 42 Hz
