OPERATING INSTRUCTIONS
GB
LEISTER Welding-Pen R
Hot air tool
Please read operating instructions carefully
before use and keep for further reference.
APPLICATION
The LEISTER Welding-Pen R is a hot air tool that can be installed for continuous operation.
It has an ergonomic shape and is light weight what makes it suitable as hand tool as
well as for the installation into machines and vent constructions.
The cooled heater tube as well as the LEISTER screw-on drawing nozzle with
taking tip make the Welding Pen to a very efficient tool for plastic welding.
• Welding of thermoplastic materials and also single-ply flexible plastics in the
form of boards, tubes, profiles, foams, tiles and sheets.
• The following procedures are possible:
Rod and melt welding by means of LEISTER nozzles
• The hot air tool Welding PenR needs an external air-supply
(LEISTER blower or compressed air).
• Digital display of SET and ACTUAL
temperature values
• Temperature steplessly controlled
• Heating element protection
• Adaptor tube with heat protection
LEISTER Process Technologies, Riedstrasse, CH-6060 Sarnen / Switzerland
Tel. + 41 41 662 74 74 Fax + 41 41 662 74 16
www.leister.com
sales@leister.com
1
®
Advertisement
Table of Contents
Related Manuals for Leister Welding-Pen R
Summary of Contents for Leister Welding-Pen R
-
Page 1: Operating Instructions
APPLICATION The LEISTER Welding-Pen R is a hot air tool that can be installed for continuous operation. It has an ergonomic shape and is light weight what makes it suitable as hand tool as well as for the installation into machines and vent constructions. - Page 2 WARNING Danger to life when opening the tool, as live components and connections ar exposed. Unplug the tool before opening it. Incorrect use of hot air blowers can cause fire and explosion hazard, especially near combustible materials and explosive gases. Do not touch the element housing and nozzle when they are hot as they can cause burns.
- Page 3 USAGE Welding-Pen R Description of tool 7. Hose connection for 1. Heat protection tube air-supply G1/4” 2. Potentiometer for temperature 8. Cable screw fitting for mains supply adjustment M16 × 1.5 3. Handle 9. Power-supply cord 4. Hose clamp 10. Digital display of SET and ACTUAL 5.
- Page 4 Welding-Pen R AIR SUPPLY • Use an air filter, if air is dusty. • Air flow can be adjusted by the LEISTER air flow adjuster. Compressed air • When using compressed air, an oil and water filter must be connected.
- Page 5 • Check hose connection, air flow, air volume and power supply. • Connect tool to the mains. Contact LEISTER Service Centre if malfunction does not disappear. ATTENTION! Do not operate tool without air supply! Function of heat protection Welding-Pen R •...
- Page 6 • Check mains cable and plug SERVICE AND REPAIR • Repairs have to be carried out by authorised LEISTER Service Centres only. They guarantee a specialized and reliable repair service within 24 hours using original LEISTER spare parts according to connection diagramms and spare parts lists.
- Page 7 ® LEISTER Process Technologies, Riedstrasse, CH-6060 Sarnen / Switzerland www.leister.com sales@leister.com Tel. + 41 41 662 74 74 Fax + 41 41 662 74 16...
- Page 8 ® LEISTER Process Technologies, Riedstrasse, CH-6060 Sarnen / Switzerland www.leister.com sales@leister.com Tel. + 41 41 662 74 74 Fax + 41 41 662 74 16...
