- Page 1 C.T.M. MOBILITY SCOOTER C.T.M. MOBILITY SCOOTER C.T.M. MOBILITY SCOOTER 8-Series Instruction Booklet HS-850 HS-890...
-
Page 2: Table Of Contents
8-Series Instruction Booklet TABLE OF CONTENTS INTRODUCTION --------------------------------------------------------1 IMPORTANT PRECAUTIONS ----------------------------------------2 ELECTROMAGNETIC INTERFERENCE AND WARNINGS ----3 IDENTIFICATION OF PARTS ----------------------------------------5 OPERATING YOUR SCOOTER -------------------------------------7 DISASSEMBLING YOUR SCOOTER -------------------------------9 ASSEMBLING YOUR SCOOTER ----------------------------------11 CHARGING THE BATTERIES --------------------------------------12 CARE AND MAINTENANCE ----------------------------------------13 TROUBLESHOOTING ------------------------------------------------14 TECHNICAL SPECIFICATIONS... -
Page 3: Introduction
Also, please retain this booklet for future reference. If you have any question, you can contact : C.T.M.HOMECARE PRODUCT, INC. 6191 Schaefer Ave Suite B Chino CA 91710 Tel : +909-590-1388 Fax : +909-590-3365 E-Mail : ctm@ctmhomecare.com http : //www.ctmhomecare.com... -
Page 4: Important Precautions
IMPORTANT PRECAUTIONS Only one person at a time could ride a C.T.M. Mobility Scooter. Maximum load is HS-850 205 kgs/ 450 lbs & HS-890 227 kgs/ 500 lbs. Turn key off before getting on or off. Always drive carefully and be aware of others using the same area. -
Page 5: Electromagnetic Interference And Warnings
8-Series Instruction Booklet ELECTROMAGNETIC INTERFERENCE AND WARNINGS CAUTION: It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your motorized scooter. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. - Page 6 8-Series Instruction Booklet Motorized Scooter Electromagnetic Interference Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the motorized scooter control system while using these devices.
-
Page 7: Identification Of Parts
8-Series Instruction Booklet IDENTIFICATION OF PARTS Before attempting to drive this scooter on your own, it is important that you familiarize yourself with the controls, and how to operate Tiller Angle Swivel Seat Adjustment With Head Rest Thumb Lever Basket Storage Area Tiller Angle Seat Rotation... - Page 8 8-Series Instruction Booklet FUNCTION OF PARTS TOP CONTROL PANEL Speed Dial Knob The Rabbit means fast and Turtle is slow. By turning this you control total speed transferred to thumb controls. Battery Gauge There is a meter shows batteries capacity status. ADJACENT TO TOP CONTROL PANEL Thumb Lever Pushing right thumb lever moves scooter forward.
-
Page 9: Operating Your Scooter
8-Series Instruction Booklet OPERATING YOUR SCOOTER You could make the following adjustments to increase your comfort when driving. adjust seat height and location adjust armrest width to comfortable position. adjust legroom. 1.Before operating your scooter, check the following: free-wheeling lever in D speed dial knob is at turtle picture. - Page 10 8-Series Instruction Booklet Keep in mind these rules Release thumb levers and allow scooter to stop completely before changing from forward to reverse, or reverse to forward. When turning to corner, swing front wheels widely, so back wheels will turn more tightly. Use scooter only where it is safe for walting.
-
Page 11: Disassembling Your Scooter
8-Series Instruction Booklet DISASSEMBLING YOUR SCOOTER The HS-890's compact design and light weight style make it fit easily into trunk or back seat of most vehicle. No tools are necessary to disassemble scooter. Remove seat by releasing Seat Rotation Lever (A) and then lift seat off. (See Fig. 4) Remove rear shroud (B) off scooter. - Page 12 8-Series Instruction Booklet Remove front basket (G) and lower tiller by pulling tiller adjustment (H) and push tiller doun. (See Fig. 10) When fintsh instruction from figure (4) to figure (10) , there are 5 main parts. (See Fig. 11) Figure 10 Figure 10 Figure 11...
-
Page 13: Assembling Your Scooter
8-Series Instruction Booklet ASSEMBLING YOUR SCOOTER To assemble scooter, you can repeat disassembly directions in reverse. Abbreviated directions are given below. Refer to Figures on pages 9 - 11 to locate parts. 1.Use the tiller adjustment to move tiller up and out of the way. 2.Place front basket. -
Page 14: Charging The Batteries
8-Series Instruction Booklet CHARGING THE BATTERIES Batteries must be charged before using the scooter for the first time and should be recharged after each day use. You will need the scooter and the battery charger. Each country may supply different charger. -
Page 15: Care And Maintenance
8-Series Instruction Booklet CARE AND MAINTENANCE Cleaning Your Scooter If your scooter is dirty, use a damp or lightly soapy cloth to wipe it down. Do not use running water to wash or rinse scooter in order to protect electrical parts. Polish with an automotive liquid polish. -
Page 16: Troubleshooting
8-Series Instruction Booklet TROUBLESHOOTING Here are some suggestions about solving problems you may have with your scooter. There is a Self-Diagnostic Warning Light on the Control Panel. To check the Self-Diagnostic Warning Light, turn on the key and count the number of blinks on the Warning Light. Number of Problem Solution... -
Page 17: Technical Specifications
8-Series Instruction Booklet TECHNICAL SPECIFICATIONS SPECIFICATIONS HS-850 HS-890 Overall Length 57.1" 60.2" Overall Width 27" 27" Overall Height 42.9" 42.1" Wheels: Front 13" 13" Wheels: Rear 13" 13" Weight w/ Batteries 214 lbs 241 lbs Max. Speed 9.3 mph 8 mph...
