Summary of Contents for Sycamore APEX 3
-
Page 2: Forward
Before using the generator, please take a moment to familiarize yourself with the proper safety, operation, and maintenance procedures. The equipment you have purchased is a complex piece of machinery. Please contact a Sycamore Professional Dealer or Sycamore Professional directly with questions or concerns related to any aspect of the generator you have purchased. -
Page 3: Table Of Contents
Control Panels Controls and Features Engine On/Off Switch Ignition Switch Choke Fuel Shut-Off Valve Recoil Starter Low Oil Shut-Off Control Panel Lighting Digital Meter Main AC Circuit Breaker Voltage Selector Switch Push Button Circuit Breakers © 2008, SYCAMORE SCS, LLC. -
Page 4: Table Of Contents (Continued)
Connecting to a Building’s Electrical System Maintenance and Storage Changing Engine Oil Air Cleaner Maintenance Spark Plug Maintenance Spark Arrestor Maintenance Storing Troubleshooting Specifications Wiring Diagrams Apex 3 Apex 7 Limited Warranty Limited Warranty (continued) © 2008, SYCAMORE SCS, LLC. -
Page 5: Safety Guidelines
BEFORE OPERATING. FAILURE TO COMPLY WITH INSTRUCTIONS IN THIS MANUAL COULD RESULT IN PERSONAL INJURY, PROPERTY DAMAGE, AND/OR VOIDING OF YOUR WARRANTY. SYCAMORE SCS, LLC WILL NOT BE LIABLE FOR ANY DAMAGE BECAUSE OF FAILURE TO FOLLOW THESE INSTRUCTIONS. © 2008, SYCAMORE SCS, LLC... -
Page 6: General Precautions
Gasoline fuel and fumes are flammable and potentially explosive. Use proper fuel storage and handling procedures. Always have multiple ABC class fire extinguishers nearby. • Keep the generator and surrounding area clean at all times. • Never store fuel or other flammable materials near the generator. © 2008, SYCAMORE SCS, LLC... -
Page 7: Gasoline And Oil (Continued)
CAUTION! ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT WITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE DAMAGE TO THE EQUIPMENT. SYCAMORE SCS, LLC IS NOT RESPONSIBLE FOR ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN APPROVED LINE CONDITIONER. -
Page 8: Electrical Safety
Replace terminals that are worn, discolored, or corroded. Keep terminals clean and tight. • Insulate all connections and disconnected wires. • Guard against electric shock. Prevent body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators. © 2008, SYCAMORE SCS, LLC... -
Page 9: Personal Safety
• Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one generator may become hazardous when used on another. © 2008, SYCAMORE SCS, LLC... -
Page 10: Servicing
• Maintain labels and name plates on the generator and engine. These carry important information. If unreadable or missing, contact SYCAMORE SCS, LLC immediately for a replacement. • Generator servicing must be performed by qualified repair personnel only. Service or maintenance performed by unqualified personnel could result in a risk of injury. -
Page 11: Installation (Continued)
• Do not alter or adjust any part of the generator that is assembled and supplied by the manufacturer. • Always follow and complete scheduled engine and generator maintenance. © 2008, SYCAMORE SCS, LLC... -
Page 12: Chemicals
Electric Extension Cord Cord Lengths Nameplate Amps (@ full load) 0'· 50' 50'· 100' 100'· 150' 150'· 200' 0 - 5 5.1 - 8 8.1 - 12 12.1 - 15 15 - 20 © 2008, SYCAMORE SCS, LLC... -
Page 13: Component Identification
APEX Series Owner’s Manual Component Identification Apex Generator Fuel Gauge Gas Tank Fuel Cock Choke Lever Control Panel Air Filter Oil Filler Cap/ Dip Stick Oil Drain Bolt Recoil Starter Grip On/Off Switch © 2008, SYCAMORE SCS, LLC... -
Page 14: Control Panels
ON/OFF SWITCH 20 AMP BREAKER 120V/240V SWITCH 30 AMP BREAKER LED LIGHT SWITCH 120V RECEPTACLE (L5-30R) 30 AMP MAIN CIRCUIT BREAKER DIGITAL METER 120V GFCI RECEPTACLE 30 AMP BREAKER 120V/240V RECEPTACLE (L14-30R) 30 AMP GROUNDING TERMINAL © 2008, SYCAMORE SCS, LLC... -
Page 15: Controls And Features
The recoil starter is used to pull start the engine. To start the engine using the recoil starter, pull the handle grip until resistance is felt and then pull briskly to start the engine. Do not release the starter handle allowing it to snap back against the engine. © 2008, SYCAMORE SCS, LLC... -
Page 16: Low Oil Shut-Off
This generator is equipped with a main breaker to turn off power to the control panel. The breaker should remain in the “OFF” position when not in use and while starting the generator. The circuit breaker will trip if a short circuit exists or if the generator is overloaded. © 2008, SYCAMORE SCS, LLC... -
Page 17: Voltage Selector Switch
The circuit breaker can be manually reset by pushing the push button breaker back in and holding for a few seconds. The breaker should then remain depressed and not pop back out. Reduce the load on the circuit to prevent overloading the receptacle, and then restart the generator. © 2008, SYCAMORE SCS, LLC... -
Page 18: Controls And Features
Some models are equipped with positive and negative DC voltage terminals. This is only to be used to charge 12V DC batteries. This produces a DC voltage of 12V and 8.3Amps or 100W maximum power. © 2008, SYCAMORE SCS, LLC... -
Page 19: Assembly
Then insert 1 wheel on each side of the axle by sliding wheel onto the axle end though the wheel hub. Then place another large washer onto each end of the axle flush to the wheel hub. Insert axle pin into the holes on each end on the axle for each side. © 2008, SYCAMORE SCS, LLC... -
Page 20: Battery Installation
(continued) Battery Installation (APEX 7) Sycamore Professional recommends a 12V battery of at least 235 cranking amps (not included). Model U1L small engine and lawn and garden battery is the recommended model. WARNING! BATTERIES CONTAIN SULFURIC ACID WHEN FILLED AND MAY CONTAIN EXPLOSIVE GASES. -
Page 21: Operation
Use only 4 stroke engine oil of API service classification SJ or higher. • SAE 10W-30 is recommended for general temperature conditions. For additional recommendation for you climate’s average temperature use the chart shown. Recommended Engine Oil Single Grade 10W-30 Multi-Grade 10W-40 Ambient Temperature © 2008, SYCAMORE SCS, LLC... -
Page 22: Before Starting (Continued)
If unfamiliar with the local ordinances or codes relating to the proper grounding of a generator it is highly recommended that you consult an electrician, a local inspector, or local agency to ensure properly install the generator ground. © 2008, SYCAMORE SCS, LLC... -
Page 23: Starting
Plug appliances or tools into the appropriate outlet. Refer to chart for current rating of receptacles. Do not exceed the current rating of the receptacles. Be sure that the rated power of the generator is not exceeded by the total wattage requirements of the appliances. © 2008, SYCAMORE SCS, LLC. -
Page 24: Receptacles
This prevents an electrocution hazard for line workers and others that may come into contact with these lines during an outage. Improper connection can also result in damage to the generator once power is restored. Consult your local utility company or a qualified electrician. © 2008, SYCAMORE SCS, LLC... -
Page 25: Maintenance And Storage
Every 100 hours Remove Carbon From Cylinder Head Check and Adjust Valve Clearance Clean And Adjust Carburetor Clean and Replace Carbon Brushes (for E.G.S. untis) Replace Fuel lines Overhaul Engine AC Receptacles Engine Switch Digital Meter © 2008, SYCAMORE SCS, LLC... -
Page 26: Changing Engine Oil
Check the condition of the spark plug washer and replace if necessary. Gently hand-tighten the plug to prevent cross-threading. After seated, tighten with spark plug wrench to compress washer. Reinstall spark plug cap onto the spark plug. © 2008, SYCAMORE SCS, LLC... -
Page 27: Spark Arrestor Maintenance
Pull start handle until resistance is felt, and leave in this position. Check to ensure that all bolts and screws are fastened securely and tighten if necessary. Store in a dry, well-ventilated, and clean environment of low humidity. © 2008, SYCAMORE SCS, LLC. - Page 28 Manual Manual Length 25.75 29.5 30.5 Dimensions Width 19 / 22* 21 / 25* 21.5 / 25.5* Height 19 / 24.5* 22.5 / 29* 23 / 30* *Denotes dimension with wheel kit installed on unit. © 2008, SYCAMORE SCS, LLC.
-
Page 29: Troubleshooting
Contact your local service dealer. Choke is opened too soon. Move choke to halfway position till Engine lacks power. Carburetor is running too rich or too engine runs smoothly. lean. Contact your local service dealer. © 2008, SYCAMORE SCS, LLC... -
Page 30: Wiring Diagrams
APEX Series Owner’s Manual Wiring Diagrams Apex 3 © 2008, SYCAMORE SCS, LLC... - Page 31 APEX Series Owner’s Manual Wiring Diagrams Apex 7 © 2008, SYCAMORE SCS, LLC.
-
Page 32: Limited Warranty
APEX Series Owner’s Manual Limited Warranty SYCAMORE SCS, LLC warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for two years from the date of purchase. All products covered by this limited warranty which are used in commercial applications (that is, income producing applications) are warranted to be free of defects in material and workmanship for 1 year from the date of original purchase. -
Page 33: Limited Warranty (Continued)
Owners Manual(s) supplied with the product; improper maintenance; the use of accessories or attachments not recommended by SYCAMORE SCS, LLC; unauthorized repair or alterations. • Repair and transportation costs of merchandise determined not to be defective.
