- Page 1 Formax FD 312 Paper Folding Machine Instruction Manual Provided By http://www.MyBinding.com http://www.MyBindingBlog.com...
- Page 2 FD 312 Folder OPERATOR MANUAL OPERATOR MANUAL OPERATOR MANUAL FIRST EDITION 1/2008...
- Page 4 TABLE OF CONTENTS TOPIC PAGE SPECIFICATIONS, UNPACKING FOLD PLATE ADJUSTMENT OPERATION TROUBLESHOOTING, SAFETY GUIDELINES...
-
Page 6: Specifications
Lower Fold Plate Catch Tray Front Cover FUNCTION: The Formax FD 312 Low-Volume Document Folder is designed to fold various paper sizes. The fold plates are manually adjusted for C, V, Z and various custom folds. Hopper Capacity Up to 200 sheets... -
Page 7: Operation
FOLD PLATE ADJUSTMENT Thumbscrews Half Fold Defl ector Lower Fold Plate Throat Upper Fold Plate To adjust fold plates to desired fold and length of paper, fi rst loosen the two thumbscrews on each of the two fold plates. Second, align the center bar so the marks on each side of the fold plates match up. Letter, accordion and half folds are clearly marked on each fold plate with blue lines. -
Page 8: Safety Guidelines
SAFETY GUIDELINES • The FD 312 is designed only to fold paper. Do not attempt to fold plastic sheets, plates or similar materials. • Use the FD 312 in indoor locations only. • Discontinue use if power cord is frayed or damaged. Contact Formax for assistance. •...
