Summary of Contents for Nine Eagles SOLO PRO 290

  • Page 1 Operating Instructions Operating Instructions Operating Instructions Operating Instructions Operating Instructions Operating Instructions SOLO PRO 290 RTF SOLO PRO 290 RTF 2.4 GHz 2.4 GHz No. NE2516 No. NE2516...
  • Page 2 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516...
  • Page 3 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Explanation of specialist terms: Contents Page Explanation of specialist terms / Contents Climb and descent ("Throttle/pitch"): This controls the Safety Notes 4, 5 model's climb and descent. Set contents / Specification / Recommended accessories Yaw: The model's movement around the vertical axis;...
  • Page 4 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Do not stand close to the hazard area around rotating parts when Be sure to read these Safety Notes before you assemble your mo- del. Always keep to the procedures and settings recommended in an electric motor is connected to the flight battery.
  • Page 5 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Do not carry out modifications to the radio control system components Insurance apart from those described in the instructions. Ground-based models are usually covered by standard personal third- party insurance policies. In order to fly model aircraft you will need to Operating the model extend the cover of your existing policy, or take out specific insurance.
  • Page 6 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Dear customer, Congratulations on choosing a factory-assem- bled model helicopter from our range. Many thanks for placing your trust in us. The model can be completed and prepared for flight very quickly.
  • Page 7 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Transmitter description* (Mode 1) - The mode select switch** is located on the back of the transmitter (*Complete operating instructions for the J6 transmitter can be found in the Download area at www.robbe.com)
  • Page 8 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Transmitter description* (Mode 2) - The mode select switch** is located on the back of the transmitter (*Complete operating instructions for the J6 transmitter can be found in the Download area at www.robbe.com)
  • Page 9 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Transmitter LCD display Collective pitch and throttle adjustment (default settings) Normal flight Throttle Collective pitch Mode display Transmitter voltage display Stick fully back: Throttle 0%, collective pitch -6° Collective...
  • Page 10 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Receiver outputs Charging the flight battery Connect the battery char- ger to the mains PSU, and plug the PSU into a mains socket. The red monitor LED on the...
  • Page 11 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Safety Notes regarding LiPo batteries: • Do not place the battery in water or any other liquid. • Never heat or incinerate the pack, or place it in a microwave oven. • Avoid short-circuits, and never charge the battery with reversed polarity • Do not subject the battery to pressure or shock loads, and never distort or throw the pack • Never solder directly to the battery • Do not modify or open the battery • Batteries must only be charged with a suitable charger; never connect the battery directly to a mains power supply. • Never charge or discharge a battery in bright sunlight, or close to a heater or open fire. • Do not use the battery in areas subject to high levels of static electricity. • Any of these errors can result in damage to the battery, explosion or fire. • Keep the battery out of the reach of children • If electrolyte should escape, do not expose it to fire, as the material is highly inflammable and may ignite. • Do not allow fluid electrolyte to come into contact with eyes. If this should happen, flush with copious amounts of water and contact a doctor without delay.
  • Page 12 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Pre-flight safety check Binding the receiver Before flying the model check that the receiver battery is fully This function is required in order to create the communication link bet- charged, and that the transmitter batteries still have adequate ween receiver and transmitter.
  • Page 13 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Flight preparation Open the battery compartment and insert the dry or rechargeable cells. Close the battery compartment. Move all the switches to the forward position, then switch the transmitter on (Fig. 1). If switch "A" or "B" is in the "ON" position, the screen will flash, and you will hear a warning "beep".
  • Page 14 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Flight preparation Check the correct position of the swashplate before the first flight. The swashplate must be exactly horizontal when viewed from the side and front of the model. Position the helicopter on a totally flat surface. Now move the throttle stick to the lowest throttle position, and switch the transmitter on.
  • Page 15 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Important Notes The first few flights Take-off: use the 3D switch for aerobatics only. To take off, slow- Ideally the first flight should take place in a large indoor space devoid ly and steadily increase rotor speed until the model is hovering of obstructions.
  • Page 16 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Neutral settings for tail rotor and gyro Possible problems and their remedies If you wish to adjust Heading Lock mode on the transmitter, move Check that the battery in the helicopter is the correct type, and the RVMX switch (3-D switch) to the forward position (switched that it is fully charged.
  • Page 17 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Causes of problems in flight, and how to eliminate them* Cause of problem Remedy Blade tracking Rotor blades running at different heights – Correct tracking by adjusting main rotor pushrods...
  • Page 18 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Trim settings Mode 1 Trim settings Mode 2 Throttle trim: Throttle trim: If the rotor starts to move without the If the rotor starts to move without the throttle stick being touched, or does not...
  • Page 19 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 Controlling the model in Mode 1 Controlling the model in Mode 2 Lift off: Landing: Lift off: Landing: Yaw left: Yaw right: Yaw left: Yaw right: Pitch forward: Pitch back:...
  • Page 20 Operating Instructions - SOLO PRO 290 RTF 2.4 GHz No. NE2516 robbe Modellsport GmbH & Co. KG hereby declares that this device conforms to the fundamental requirements and other relevant regulations of the corresponding EC Directive. Under www.robbe.com, you will find the original Conformity Declaration by clicking on the Logo button "Conform"...
