Figure 5
Connecting an NX Series or APM UPS to a Non NX Series or non-APM UPS
Power ON
LED1
Power Cable
Connect to NX Series or APM UPS
Table 1
Item
Power port
LED1 (red)
COM1
COM2
SWITCH
Table 2
Description
Voltage
Frequency
Current
Table 3
Description
150 Meter Kit
50 Meter Kit
COM1
COM2 SWITCH
LBS
Cable
Human interface - indicators and switches
Connect to Phase A, Neutral and Ground of output of UPS.
Power LED. It illuminates when the power is on, turns o ffwhen the power fails.
LBS Signal interface.
Connect to NX Series or APM UPS.
RS485 interface.
Connect to other Signal Adapter.
Green LED: Communication Power is OK.
Yellow LED: Adapter is connected to Non NX Series or non-APM UPS.
Switch to left: Connect to Non NX Series or non-APM UPS.
Switch to right: Connect to NX Seires or APM UPS.
Electrical rating
Rating
120V-277VAC
45-65HZ
1.5A Max.
Part number description
Part Number
NX150MLBSKIT
NX050MLBSKIT
Power Cable
Non NX Series or non-APM
Connect to
Communication Cable
up to 492 ft. (150m)
Description
3
Power ON
COM1
COM2 SWITCH
LED1
UPS
Installation
