Metek GUPS 2400A–104 Operation Manual

Global uninterruptible power supply
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GLOBAL
UNINTERRUPTIBLE

POWER SUPPLY

Model GUPS 2400A–104
Operation Manual
Contact Information
Telephone: 800 733 5427 (toll free in North America)
858 450 0085 (direct)
Fax: 858 458 0267
Email:
Domestic Sales: domorders.sd@ametek.com
International Sales: intlorders.sd@ametek.com
Customer Service: service.ppd@ametek.com
Web:
www.programmablepower.com
March 2011
Document No. M152332-01 Rev C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUPS 2400A–104 and is the answer not in the manual?

Questions and answers

Related Manuals for Metek GUPS 2400A–104

Summary of Contents for Metek GUPS 2400A–104

  • Page 1: Power Supply

    GLOBAL UNINTERRUPTIBLE POWER SUPPLY Model GUPS 2400A–104 Operation Manual Contact Information Telephone: 800 733 5427 (toll free in North America) 858 450 0085 (direct) Fax: 858 458 0267 Email: Domestic Sales: domorders.sd@ametek.com International Sales: intlorders.sd@ametek.com Customer Service: service.ppd@ametek.com Web: www.programmablepower.com March 2011 Document No.

  • Page 3: Contact Information

    About AMETEK AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader in the design and manufacture of precision, programmable power supplies for R&D, test and measurement, process control, power bus simulation and power conditioning applications across diverse industrial segments.
  • Page 4 This page intentionally left blank.

  • Page 5: Important Safety Instructions

    Important Safety Instructions Before applying power to the system, verify that your product is configured properly for your particular application. Hazardous voltages may be present when covers are removed. Qualified personnel must use extreme caution when servicing this equipment. Circuit boards, test points, and output voltages also may be floating above WARNING (below) chassis ground.
  • Page 6 Product Family: GUPS 2400A-104 Warranty Period: One Year WARRANTY TERMS AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in material or workmanship within the applicable warranty period stated above, then AMETEK may, at its option: repair or replace the Product;...

  • Page 7: Table Of Contents

    CONTENTS SECTION 1 OVERVIEW AND SPECIFICATIONS ......... 1-1 Introduction ....................1-1 General Description ..................1-1 Specifications ....................1-1 SECTION 2 INSTALLATION ............... 2-1 Introduction ....................2-1 Unpacking and Inspection ................2-1 Installation ...................... 2-2 Air Intake and Exhaust ................... 2-2 Input/Output Connectors ................
  • Page 8 Contents 3.9.2 Software Interface ................3-7 3.9.3 RS-232 Protocol ................. 3-8 3.9.4 Test Data Request Commands ............3-8 3.9.5 Elgar Terminal Interface (ETI) Data Request Commands ....3-10 3.9.6 Status Words ..................3-11 3.9.7 AC Line Loss Signal ................. 3-16 SECTION 4 MAINTENANCE ...............

  • Page 9: Section 1 Overview And Specifications

    SECTION 1 OVERVIEW AND SPECIFICATIONS Introduction The Elgar Model GUPS 2400A-104 is a 2400 VA Global Uninterruptible Power Supply (GUPS) that provides regulated 115 VRMS, 60 Hz output power at up to 20.9 Amps RMS load current. The GUPS 2400A-104 accepts 3-phase AC input line voltages from 159V to 232V at frequencies from 370 Hz to 430 Hz.
  • Page 10 Overview and Specifications Output Voltage: 115V, ±2% Output Frequency: 60Hz, ±0.1% Output Current: 20.9A(RMS) Output Distortion: 2% THD, maximum with linear load Output Power: 1920W with resistive load; 2400VA/1920W with a reactive load or a non-linear load Efficiency: 77% AC to Battery Crossover: 159V, maximum low-line voltage; 232V, minimum high-line voltage Battery to AC Crossover: 169V, maximum low-line voltage;...

  • Page 11: Section 2 Installation

    SECTION 2 INSTALLATION Introduction The Elgar Model GUPS 2400A–104 has been aligned, calibrated, and tested prior to shipment. The instrument is ready for immediate use upon receipt. However, the following checks should be made to ensure that the instrument was not damaged during shipment. CAUTION! The GUPS 2400A–104 weighs 75 pounds (34 kg) without the battery pack.

  • Page 12: Installation

    Installation When returning the instrument to Elgar, suitable shipping containers and packing material must be used. If the instrument needs to be shipped and proper packing material is not available, contact Elgar to provide containers and shipping instructions. Installation The Model GUPS 2400A–104 is 7" (178 mm) high and is designed to be installed in a standard 19"...

  • Page 13: Figure 2-1. Gups 2400A-104 (Front View)

    Installation Figure 2–1. GUPS 2400A–104 (Front View) GUPS 2400A–104 Operation Manual...

  • Page 14: Figure 2-2. Gups 2400A-104 (Rear View)

    Installation Figure 2–2. GUPS 2400A–104 (Rear View) GUPS 2400A–104 Operation Manual...

  • Page 15: Figure 2-3. Gups 2400A-104 Dimensions (Top, Side, And Front Views)

    Installation 1.75 .160 .825 25.10 1.75 16.90 15.60 6.920 1.730 .625 BOTTOM OF CHASSIS TO TOP COVER 5 EQ SP @ 3.875 = 19.375 12X PN LAC-032-2 BOTTOM EDGE OF FRONT PANEL Figure 2–3. GUPS 2400A–104 Dimensions (Top, Side, and Front Views) Figure 2 -3 GUPS 2 4 0 0 A-1 0 4 (To p and S ide Vie ws ) GUPS 2400A–104 Operation Manual...

  • Page 16: Wire Gauge Selection

    Installation Wire Gauge Selection The following guidelines assist in determining the optimum cable specification for the user's power applications. These guidelines are equally applicable to both DC and low frequency AC (up to 450 Hz) power cabling. The same engineering rules apply whether going into or out of an electrical device.
  • Page 17 Installation The following notes apply to Table 2–2 and to the power cable definition: 1. The above figures are based upon insulated copper conductors at 25°C (77°F), two current carrying conductors in the cable plus a safety (chassis) ground. Columns 3 and 4 refer to "one way" ohms and IR drop of current carrying conductors (e.g., a 50-foot cable contains 100 feet of current carrying conductor).
  • Page 18 Installation 5. Derate the above wire gauge (use a heavier gauge) for an increased number of current carrying conductors. This offsets the thermal rise of bundled conductors. Number of Current Conductors Capability 3 to 6 Above 6 6. The preferred insulation material is application dependent. Elgar recommends any flame retardant, heat resistant, moisture resistant thermoplastic insulation rated to a nominal 75°C (167°F).

  • Page 19: Section 3 Operation

    SECTION 3 OPERATION Introduction This section provides detailed information on the controls and indicators, input/output connections, start-up and shutdown sequences, battery operation, and the RS-232 data communications port. Control and Indicator Panel All controls and indicators for the GUPS 2400A–104 are located on the front panel of the unit. There are no operator adjustments inside the unit.

  • Page 20: Pushbutton Switches

    Operation TEST. A two-color LED that indicates the results of the internal self-test. The LED blinks while a self-test is in progress. When the test is complete, the LED turns green if the test is passed and red it the test is failed. 3.2.2 Pushbutton Switches OUTPUT ON.

  • Page 21: Circuit Breakers

    Operation Circuit Breakers AC INPUT The AC input breaker is located on the front panel below the Control and Indicator Panel. It is turned ON by pushing in the actuator button, and it is turned OFF by pulling out the actuator button.

  • Page 22: Connectors

    Operation OUTPUT CURRENT An AC voltage signal that is proportional to the AC output current. The output is 0.221V/A, or 4.6 VRMS at full load. This signal is transformer isolated from the other control signals. Connectors The GUPS 2400A–104 has cylindrical, metal-shell connectors with bayonet coupling for all input/output connections of power and signal.

  • Page 23: Start-Up And Shutdown Sequences

    Operation Start-Up and Shutdown Sequences To run the GUPS 2400A–104 from an AC input, perform the following steps: Turn on the AC input circuit breaker located on the front panel. Wait approximately 10 seconds for completion of the start-up routines. During this time, the GUPS performs a self-test to assure proper functionality, and the rectifier undergoes a soft-start so that current surges on the AC input are prevented.

  • Page 24: Battery Care And Handling

    Operation To turn OFF the output, press the OUTPUT ON switch again to use the alternating ON/OFF action of the switch. The unit will shut down (with no AC input present); the inverter and all control circuits will turn off. 3.8.1 Battery Care and Handling The battery used in the GUPS 2400A-104 requires proper storage and recharging to maintain...

  • Page 25: Rs-232 Data Communications Port

    Operation RS-232 Data Communications Port The RS-232 data communications port provides an interface between a data terminal (or a computer emulating a data terminal) and the GUPS 2400A–104. It allows transfer of information such as parameter values, mode of operation, and alarm conditions. 3.9.1 Hardware Interface Interface signals for communication to and from the GUPS 2400A-104 are provided via a...

  • Page 26: Test Data Request Commands

    Operation 3.9.3 RS-232 Protocol The GUPS 2400A–104 RS-232 communications port protocol is given in Table 3–4. Baud Rate 9600 Data Bits Start Bits Stop Bits Parity None Table 3–4. RS-232 Communications Port Protocol 3.9.4 Test Data Request Commands The GUPS 2400A–104 RS-232 text data mode commands have been developed for a user interface utilizing a dumb terminal interface.
  • Page 27 Operation 3.9.4.2 Display Calibration Values Enter a command ‗k‘ (lowercase K) character to display the calibration constants for the A/D converter algorithms values. For example: Calibration Constants: 80 percent current: 32F8 // Output current in hexadecimal 105 percent current: 424B 150 percent current: 50E7 Minimum voltage band: 2000 // Output voltage in hexadecimal...

  • Page 28: Elgar Terminal Interface (Eti) Data Request Commands

    Operation 3.9.5 Elgar Terminal Interface (ETI) Data Request Commands The GUPS 2400A-104 RS-232 text data mode commands have been developed for use by a program running on a host computer. The ETI mode data request commands provide formatted responses of only the measured value data in a formatted form. Each of the ETI data request commands supported by the GUPS 2400A-104 is described below.

  • Page 29: Status Words

    Operation 3.9.6 Status Words The status words may be used to examine the current state of the GUPS 2400A–104, but are not meant to be used in applications that are time–critical such as AC line loss detection. The ―Line Loss Detected‖ message sent from the GUPS 2400A–104 (refer to Section 3.9.7), or the AC Line Loss signal (relay contact closure) will have the quickest response time.
  • Page 30 Operation The definitions of the conditions and usage of the bits in Status Word 1 are defined below. Over Temperature (Status Word 1, Bit 0) The Over Temperature status bit indicates that the thermostat internal to the GUPS 2400A-104 has exceeded its trip point. A binary value of 0 indicates normal operation, while a binary value 1 indicates that the thermostat sensor has exceeded its trip point value of 95 degrees Celsius.
  • Page 31 Operation Impending Shutdown (Status Word 1, Bit 9) The Impending Shutdown status bit indicates the status of the battery of the unit. A binary value of 0 indicates more than 1 minute of back-up time is available or that the battery voltage is greater than 177 volts, while a binary value of 1 indicates that less then 1 minute of back-up time is available or that the battery voltage that is less than 177 volts.

  • Page 32: Table 3-6. Status Word 2 Data Format

    Operation 3.9.6.3 Status Word 2 Format Table 3–6 provides the bit position information and definition of the data in Status Word 2. Name Definition 0 = Running on AC Running on Battery 1 = Running on battery Reserved 0 = No Keypress Pending Inverter Keypress 1 = Inverter Keypress Pending 0 = System Operating...
  • Page 33 Operation 3.9.6.4 Status Word 2 Status Bit Condition Definitions The definitions of the conditions and usage of the bits in Status Word 2 are defined below. Running on Battery (Status Word 2, Bit 0) The Running on Battery status bit indicates that the unit is operating on batteries. A binary value of 0 indicates that the unit is running on AC input, while a binary value of 1 indicates that the unit is running on battery.

  • Page 34: Ac Line Loss Signal

    Operation Pass/Fail System Self-Test (Status Word 2, Bit 9) The Pass/Fail System Self-Test status bit indicates the results of the last run system self test. A binary value of 1 indicates that the unit passed the last self-test, while a binary value of 0 indicates that the unit failed the last self-test.

  • Page 35: Section 4 Maintenance

    SECTION 4 MAINTENANCE Introduction This section contains general information about maintenance of the GUPS 2400A-104. There are no adjustments accessible to the user. WARNING Hazardous voltages are present when operating this equipment. Please read the SAFETY NOTICE on page Error! Bookmark not defined. prior to installation, operation, or maintenance.

  • Page 36: Troubleshooting

    Maintenance Troubleshooting In the event that a problem arises during unit operation, refer to the guidelines listed in Table 4–1 to assist in determining the cause and to repair the unit as quickly as possible. Symptom Probable Cause Suggested Solution No indicators are The AC line voltage is not Energize the input circuit breaker;...
