Cyberoam NetGenie Soho Quick Start Manual

Wireless adsl2+ integrated security appliance
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
N300
ADSL2+
www.netgenie.net

QUICK START GUIDE

Wireless ADSL2+
Integrated Security Appliance
Manage access to
Protection from
Websites & Applications
Bots & Hackers
Share your 3G
VPN
USB modem Internet
Manage security from anywhere
Excellent Wireless Range
Supports ADSL, Cable Internet,
with Cloud services
& High Performance
3G USB Modem
NetGenie is furnished under the terms of NetGenie's End User license agreement, the details and links of which are given
on the last page of this Quick Start Guide. By using this Appliance, it shall be presumed that you have read the said license
and you agree to be bound by the terms and conditions of the same.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetGenie Soho and is the answer not in the manual?

Questions and answers

Summary of Contents for Cyberoam NetGenie Soho

  • Page 1: Quick Start Guide

    N300 ADSL2+ www.netgenie.net QUICK START GUIDE Wireless ADSL2+ Integrated Security Appliance Manage access to Protection from Websites & Applications Bots & Hackers Share your 3G USB modem Internet Manage security from anywhere Excellent Wireless Range Supports ADSL, Cable Internet, with Cloud services &...

  • Page 2: Section 1 Know Your Netgenie

    Section 1 Know Your NetGenie Unboxing Your New NetGenie… Congratulations on your purchase of NetGenie Wireless ADSL2+ Integrated Security appliance. After unboxing NetGenie, please ensure that you have all these components: 1. NetGenie Wireless Base Unit - NG12AO 2. Two (2) detachable Wi-Fi Antennas 3.

  • Page 3: Section 2 Connecting To The Internet

    Please note down your Manufactured in China pass key for future reference. Model Name : Cyberoam NetGenie NG12AO Serial Number : W118300302-Q26QRB MAC : 00:0E:F4:E3:04:25 2. Plug one end of the power adapter into the socket on the back of...
  • Page 4 Defaults: Default IP Address to access NetGenie: http://10.1.1.1 Default User Name: admin Default Password: admin After your first login, it is recommended that you change your default password for security reasons. Appliance Reset Button: To reset appliance to factory default settings, keep the Reset Button pressed for 5 seconds. On doing so, all past upgrades and configurations will be lost.
  • Page 5 3. Open your browser and go to the default IP Address i.e. http://10.1.1.1 to access NetGenie Web Admin Console. Use the default User Name and Password i.e. ‘admin’ to log in. 4. You need to configure network settings to connect to the Internet. You can either run the NetGenie ‘Network Configuration Wizard’...

  • Page 6: Network Configuration Wizard

    Internet Laptop Desktop NetGenie Wireless ADSL2+ Integrated Security Appliance NetGenie Power Cable Connect your Computer/ LAN here to any of the ports iii) Click the network icon in computer's system tray (bottom-right of your screen) and Select “NetGenie - XXXX”. iv) After selecting “NetGenie - XXXX”, you will be asked to enter the exact Security/Pass Key printed on the sticker at the back of your appliance.
  • Page 7 3. To access the Network Configuration Wizard, go to Network Settings and click ‘Launch Network Configuration Wizard’. 4. Click ‘Next’ to continue or ‘Skip Wizard’ to configure the network settings manually, through the NetGenie user interface. 5. Select your Internet connection type i.e. ADSL or Ethernet. Click ‘Next’ to continue.
  • Page 8 Select your country and ISP from the list. Enter Username and Password as provided by your ISP. Note: In case your ISP provides IP over DHCP, you may need not to provide any User Name and Password to connect to the Internet. You can now start surfing the Internet.

  • Page 9: Step 1: Basic Configuration

    NetGenie Splash Screen When you start surfing the Internet through NetGenie, you will be served with a splash screen. This introductory splash screen gives an overview of NetGenie features along with multiple options. You can perform following actions: 1. Click 'Learn more about NetGenie's Security' button to read detailed information regarding security features offered by NetGenie.
  • Page 10 Step 2: Adding your office users 1. To add various users, visit the Internet Controls Page. Enter the name of the individual for whom you wish to allow Internet access in the Username section. Here, for example, the username used is "Alice". 2.
  • Page 11 2. You will come across the following page. 3. Click the given link to open the website. After surfing, do not forget to click 'Logout' for security reasons. Similarly, you can apply the appropriate Internet Controls for all your users for a safe and secured Internet experience.
  • Page 12 Important Notice Cyberoam Technologies Pvt. Ltd. has supplied this Information believing it to be accurate and reliable at the time of printing, but is presented without warranty of any kind, expressed or implied. Users must take full responsibility for their application of any products.
