KING 24V
Operatore
Operateur
Operator
Torantrieb
Operador
KING 24V
KING 24V L
ITALIANO pag. 05 / FRANÇAIS pag. 16 / ENGLISH page 27 / DEUTSCH pag. 38 / ESPAÑOL pag. 49
con / avec / with / mit
OPERATORE IRREVERSIBILE PER CANCELLI A BATTENTE
OPERATEUR IRREVERSIBLE POUR PORTAILS À BATTANT
IRREVERSIBLE OPERATOR FOR LEAF GATES
TORANTRIEBE FÜR FLÜGELTORE
OPERADOR IRREVERSIBLE PARA CANCELAS DE BATIENTE
Alimentazione
Peso max cancello
Alimentation
Poids maxi portail
Power Supply
Max gate weight
Stromspannung
Max Torgewicht
Alimentacion
Peso máx verja
24Vdc
400 kg / 880 lbs
24Vdc
500 kg / 1100 lbs
T2 24V
Forza max di spinta
Force maxi de poussée
Thrust force
Max. Schubkraft
Fuerza max de empuje
N 1800
N 1800
codice
code
code
code
codigo
AA14028
AA14029
Advertisement
Table of Contents
Related Manuals for Automatic Solutions KING 24V
Summary of Contents for Automatic Solutions KING 24V
- Page 1 KING 24V 24Vdc 400 kg / 880 lbs N 1800 AA14028 KING 24V L 24Vdc 500 kg / 1100 lbs N 1800 AA14029 ITALIANO pag. 05 / FRANÇAIS pag. 16 / ENGLISH page 27 / DEUTSCH pag. 38 / ESPAÑOL pag. 49...
-
Page 2: System Layout
SYSTEM LAY-OUT ❷ ❸ ECHNICAL FEATURES KING 24V is a irreversible operator suitable for opening gates with a leaf length of up to 4,5 metres (Fig. 1). The KING 24V operator use mechanical stoppers, thus avoiding ❹ the need for electrical limit switches. -
Page 3: Pre-Installation Checks
Before inserting the pin into the gate attachment, grease thoroughly. Weld the base at the right height (Fig. 8). Fix the KING 24V and try several times to open and to close the gate, controlling that the operator does not touch the moving gate. -
Page 4: Mechanical Stopper Adjustment
ECHANICAL STOPPER ADJUSTMENT To adjust the stoppers you have to follow the scheme (Fig. 9). To set the opening limit it’s enough to fix the stopper (A) in the needed position by tightening the 8mA screw with a n. 13 key. To obtain the desired closing limit you must adjust the stopper (B) (OPTIONAL) ) in the needed position and tighten it as for stopper (A). - Page 5 ESPECT THE MEASURES FOR A CORRECT INSTALLATION B Min.÷Max Leaf attachment S3-Y 1÷1,80 45 100 100 815 KING 24V S3-X 1,81÷2,20 45 110 110 815 KING 24V 2,21÷2,50 70 140 110 815 S1-Z KING 24V S2-Y 2,51*÷3,00* 90 170 140 815 115 KING 24V 90° 3,01*÷3,50* 115 200...
-
Page 6: Electric Connections
T2 24V code BC07088 ELECTRIC CONNECTIONS T2 24V CRX code BC07089 24Vdc 0,8A ± 15% for ACCESSORY SUPPLY BLINKER 24Vdc 0,8A ± 15% for AUTOTEST SAFETY STRIPS 24Vdc 20W PEDESTRIAN ELECTRIC STEP BY STEP POWER SUPPLY LOCK 230Vac 50 Hz PHOTOCELLS FUSE COMMON... - Page 7 CONTROL PANEL FEATURES Power supply 230 Vac 50/60 Hz - external to the control panel - (120V/60Hz upon request) COM. Common contact CLOSE Closing impulse contact (NA) OPEN Opening impulse contact (NA) STOP STOP impulse contact (NC) AERIAL Radio Antenna TRANSFORMER SIGNAL Gate open state and battery state output...
- Page 8 gate closing M2 (red) SETTINGS gate opening M1 (green) gate closing M1 (red) DIP 1 (ON) - MOTOR ROTATION DIRECTION CONTROL (POINT C) automatic closing indicator (red) DIP 2 (ON) - TIMER (POINT D) photocell contact (NC) (red) DIP 3 (ON) - ACTIVATES DOOR RELEASE DURING PHASES OF sensor contact (NC) (red) SLOWDOWN AND TOTAL OPENING AND CLOSING (AS PER THE...
- Page 9 4 - The red LED DL1 remains active and you can add new codes as shown above. SETTING THE TIME FOR 2 MOTORS (#) WITH TIME OPERATION 5 - Reset DIP 1 to OFF and DIP 2 to OFF. (DIP 7 OFF) 6 - End of procedure.
- Page 10 CLOCK FUNCTION APPLICATION activated and LED DL6 is on). If during closing It is necessary to request a T2 24V control panel with firmware 02. there is a rapid movement (e.g. pedestrian) the By connecting a switch and/or a daily/weekly clock (instead of or in parallel to the gate will open again for two seconds and then open button N.O.
-
Page 11: Troubleshooting
The dead-man operation is only an emergency operation which must be ECHNICAL SPECIFICATIONS activated for a very short period and with the complete installation at sight so - Temperature range 0 ÷ 55°C to have a secure and safe control of the system. As soon as possible however, - Humidity <95% without condensation the failing safety devices must be repaired and activated. - Page 12 For the connections and the technical data of the optional equipments follow the relevant ACCESSORIES - handbooks. ADIO TRANSMITTER SUN ET SOLAR AMPLIFIER SUN 2CH code ACG6052 SUN 4CH code ACG6054 SUN CLONE 2CH code ACG6056 SUN CLONE 4CH code ACG6058 Interface for 50W solar panels.
- Page 13 KING 24V Questo prodotto è stato completamente progettato e costruito in Italia · Ce produit a été complètement développé et fabriqué en Italie · This product has been completely developed and built in Italy · Dieses Produkt wurde komplett in Italien entwickelt und hergestellt · Artìculo totalmente proyectado y producido en Italia...
- Page 14 Wait times will vary dependent on local workloads. The cost is a service fee which includes the first half hour and the hourly rate thereafter. If any Automatic Solutions provided parts are found to be defective and within warranty these will be provided free of charge.
