- Page 1 60W Sound Pack Installation AXCITY ZAC des Hauts de Wissous « Air Park de Paris » Bâtiment le Cormoran 3 rue Jeanne Garnerin 91320 Wissous, France ASBSOP0201-n°1 2012...
- Page 2 Contents 60W Sound Pack Installation Chapter 1 Pack Description Box Contents ............1-1 60W Amplifier ............1-2 100V Speakers ............1-3 Speaker Cable ............1-4 Chapter 2 Pack Implementation Step 1 Speakers Connection ..........2-5 Step 2 AM/FM Antenna Connection ......... 2-8 Step 3 Power Cord Connection .........
- Page 3 Chapter 3 Quick Troubleshooting 60W Pack ................. 3-12 Appendix A Technical Data Sheets Appendix B Associated Documents...
-
Page 4: Box Contents
Chapter 1 Pack Description Box Contents The 60W Sound Pack contains the following: items • 1 60W amplifier with USB/CD/Tuner • 6 6W/100V speakers • 1 AM/FM antenna • 1 power cord • 100 meters of speaker cable If any of these are incorrect, missing, or damaged, contact your Axcity dealer. -
Page 5: General Description
60W Amplifier General Description 3-zone mixer amplifier equipped with an AM/FM tuner and a CD MP3/USB player. The volume control covers all areas. It can also be used at full power in single zone mode. Its LCD screen provides the view of the radio station or CD/USB title playing. - Page 6 100V Speakers General Description 6W/100V speaker. Wideband, it has an excellent audio quality. Its small diameter provides a discrete installation in the ceiling. Pack Description...
-
Page 7: Speaker Cable
Speaker Cable General Description Flat loudspeaker cable dedicated to the 100 volt line. Suitable for all types of sound systems, it can be used both in fixed and mobile installations. Pack Description... - Page 8 Chapter 2 Pack Implementation Step 1: Connection of the speakers to the amplifier Beforehand, you must connect the speakers to speaker cables. Then connect the speaker cable(s) to the amplifier. General view of the rear of the amplifier Start by stripping each conductors about 5 mm. Pack Implementation...
- Page 9 Fig.1 Unscrew the COM terminal on the right. Insert the black conductors into the space between the connection plate and the fixed terminal. Screw up the COM terminal. Pack Implementation...
- Page 10 Insert the red conductors into the SP1 terminal, corresponding to the 1 zone. The SP2 and SP3 terminals correspond to zones 2 and 3. Note: 1 wired zone: 60W output power 2 wired zones: 20W output power 3 wired zones: 20W output power Pack Implementation...
- Page 11 Step 2: Connection of the AM/FM antenna to the amplifier fig.2 Connect a conductor to the GND terminal. Connect the other conductor to the 75Ω terminal. Pack Implementation...
- Page 12 Step 3: Connection of the power cord to the amplifier fig.3 Plug the power cord into the outlet provided for that purpose. Turn the amplifier on. Pack Implementation...
- Page 13 Step 4: Starting the Amplifier Press the “POWER” button, after checking that the “MASTER” button is on “0”. Select the zone(s) for distribution. Pack Implementation 2-10...
- Page 14 The red LED lights to indicate the amplifier is powered In order to access to the AM/FM tuner as well as the CD/MP3 and USB player, press the “sound volume” button. Select the desired source. To turn off, press and hold. Pack Implementation 2-11...
- Page 15 Chapter 3 Quick Troubleshooting The 60W pack does not work If the red LED on the amplifier is not lit: Check that the power supply unit is functioning properly. Check that the speakers are properly connected to each other and to the amplifier. To do so, press the CHIME button.
- Page 16 APPENDIX A Technical Data Sheets 60W Amplifier Technical Specifications RMS output power 1 x 60W (3 x 20W) Bandwidth 80 Hz – 15 kHz Signal/noise ratio – MIC > 70 dB Signal/noise ratio – LINE > 60 dB Distortion Ratio <...
- Page 17 100V Speaker Technical Specifications Speaker Size 3” Frequency Response 120 Hz – 20 kHz Rated Power 6 W RMS Nominal SPL (1W / 1M) 91 dB Max. nominal SPL (6W / 99 dB Directive 89° Power selection by wiring 3 – 6 6W / 8Ω...
- Page 18 In order to avoid electrical shock hazards, do not remove the cover. No maintenance of internal parts must be done by users, contact qualified personnel. If necessary. In order to avoid fire and electric shock hazards, do not expose this product to rain or moisture. APPENDIX A...
- Page 19 APPENDIX B Associated Documents This appendix provides links to reference documents that can help you to understand better the technologies used for your Axcity product. Documents Link Amplifier Technical Data www.axcity.fr Sheet www.axcity.fr Amplifier User Manual Speaker Technical Data www.axcity.fr...
