- Page 1 30W Sound Pack Installation AXCITY ZAC des Hauts de Wissous « Air Park de Paris » Bâtiment le Cormoran 3 rue Jeanne Garnerin 91320 Wissous, France ASBSOP0101-n°1 2012...
-
Page 2: Table Of Contents
Contents 30W Sound Pack Installation Chapter 1 Pack Description Box Contents ............1-1 30W Amplifier............. 1-2 Chapter 2 Pack Implementation Step 1 Speakers Connection ........... 2-3 Step 2 Peripheral Connection ......... 2-7 Step 3 Amplifier Start-up ..........2-9 Appendix A... -
Page 3: Pack Description
Chapter 1 Pack Description Box Contents The 30W Sound Pack contains the following items • 1 30-watt amplifier • 1 power cord • 1 FM antenna • 1 replacement fuse • 1 plastic screwdriver to adjust the recording gain If any of these are incorrect, missing, or damaged, contact your Axcity dealer. -
Page 4: General Description
30W Amplifier General Description Mixer amplifier to which you may connect two microphones on the front as well as an auxiliary source (such as a smartphone, CD player, computer...) or a phono source (such as a record player). Compact, it has a USB port and a tuner for radio. -
Page 5: Pack Implementation
Chapter 2 Pack Implementation Step 1: Connection of the speakers to the amplifier Beforehand, you must connect the speakers to speaker cables. Then connect the speaker cable(s) to the amplifier. General view of the r ear of the amplifier Pack Implementation... - Page 6 Fig.1 Unscrew the protective cover. Connect the black conductor to the COM terminal. Connect the red conductor to the 25V/70V/100V terminals according the speaker technology. For low impedance technology speakers, connect the red conductor to the 4Ω terminal. Pack Implementation...
- Page 7 In order to connect the conductors to the terminals, start by stripping each conductors of about 5 mm. Unscrew the corresponding terminal. Place conductors in the space between the connection plate and the fixed terminal. Pack Implementation...
-
Page 8: Step
Screw up the terminal. Screw up the protective cover back on Step 2: Connection of Devices to the Amplifier Pack Implementation... - Page 9 fig.2 Connect the FM antenna to the coaxial output provided for this purpose. Pack Implementation...
- Page 10 fig.3 Plug the power cord into the outlet provided for that purpose. Turn the amplifier on. Pack Implementation...
- Page 11 Step 3: Turning on the Amplifier Check that the “MASTER” button is on “MIN”, then press the “POWER” button Pack Implementation...
- Page 12 A green LED lights to indicate the amplifier is powered Press the “M4” button to turn the amplifier on. Pack Implementation 2-10...
- Page 13 Select the desired source: Tuner, USB, SD/MMC. Note: Playback and recording functions In order to use the various amplifier’s features, refer to the manual provided. To turn off the amplifier, press and hold the “M4” button. Then press the “Power” button. Pack Implementation 2-11...
-
Page 14: Appendix A Technical Data Sheets
APPENDIX A Technical Data Sheets Amplifier Technical Specifications Output Power 30 W Bandwidth 80 Hz – 18 kHz (± 3dB) Distortion Ratio ≤ 0.5% @ 1 kHz MIC 1-2 Inputs 6.3 Jack Unbalanced -50 dB/1kHz AUX (RCA) Inputs -20 dB/1kHz PHONO Input -50 dB/1kHz Speaker Outputs... - Page 15 List of Compatible Speakers 3” 100V Ceiling Speaker ref ASBSOA0601 6” 100V Ceiling Speaker ref ASBSOA0101 Sound Projector ref ASBSOA0301 PA Speaker ref ASBSOA0201 In order to avoid electrical shock hazards, do not remove the cover. No maintenance of internal parts must be done by users, contact qualified personnel.
-
Page 16: Appendix B Associated Documents
APPENDIX B Associated Documents This appendix provides links to reference documents that can help you to understand better the technologies used for your Axcity product. Document Link www.axcity.fr Amplifier Technical Data Sheet www.axcity.fr Amplifier User Manual APPENDIX B...
