1.3
Connection and display element
1.3.1
Connections on the back
1.3.2
Display elements on the front
The LEDs on the front panel show the condition of the interface lines or the
condition of the modem.
The Power LED is lit when the modem is ready for operation.
On/Off switch
Power supply connection
Serial port (V.24/RS232C interface)
Line port (RJ11 socket)
Modem operational
Data to/from modem
Modem online (off hook)
|
Introduction
|
devolo MicroLink 56k Fun II
7
|
