Quick Start Guide

Portable 150Mbps Wireless N Travel Router / Access Point - USB Powered
AP150WN1X1U
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com

Packaging Contents

• 1 x Travel Router
• 1 x USB Cable
• 1 x RJ45 Cable
• 1 x Carrying Pouch
• 1 x Instruction Manu

System Requirements

• Available USB port (or wall charger) for power

Product Overview

RJ45 Interface WPS/Reset Button

LED Indicators

Off: No Wi-Fi signal
WiFi
Solid: Wi-Fi signal broadcasting
Flashing: Activity
Off: No RJ45 connection detected
WLAN Solid: RJ45 connection detected
Flashing: Activity
Off: No power supplied to the device
POWER
Solid: Connected to a USB power source

WPS / Reset Button

WPS
WPS mode is disabled by default because it requires a secured wireless network to be
used.
1.
Once you have selected an operating mode and are connected to the
web interface (details in the following sections of this manual), configure
your desired wireless security protocol and key.
For the most up-to-date information, please visit: www.startech.com
Mode Selector Switch USB Interface
2.
Enable WPS mode.
3.
Once enabled, a single press of the button will activate it.

Reset

In order to reset the device to factory defaults:
Note: All previously configured settings will be deleted after performing a reset
1.
Ensure the AP is connected to a power source.
2.
Press and hold the reset button for 8 seconds, then release.

Installation

Please visit www.startech.com/AP150WN1X1U for full operating instructions and
specifications

Default Settings

SSID: AP150WN1X1U
LAN IP Address: 192.168.16.254
Username / Password: admin / admin

Wireless Access Point

In AP mode, the AP150WN1X1U acts as a wireless transmitter which adapts a wired
network signal into WiFi, so that other wireless devices like smartphones and tablets
within range can share the wired connection.
Widely used in: Hotel rooms, school dormitories, etc.
1.
Adjust the switch on the device to AP Mode.
2.
Connect one end of the included Ethernet cable to the RJ45 port of the AP, and
the other to the hotel wall jack/switch.
3.
Connect one end of the included USB cable to the USB port of the AP, and the
other to a USB power source (e.g. laptop, USB wall charger, etc.).
4.
Connect your wireless devices to the "AP150WN1X1U" SSID and open your web
browser to access the Internet.
NOTE: If the hotel Internet connection requires a password or has a captive portal
login, contact the front desk to obtain that information.
Manual Revision: 01/27/2014
