RESIDENTIAL OIL-FIRED WATER HEATERS
INSTALLATION AND OPERATING INSTRUCTIONS
READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING THE INSTALLATION. PROPER INSTALLATION
WILL PROVIDE SAFE AND EFFICIENT SERVICE AND AVOID NEEDLESS EXPENSE NOT COVERED BY THE
WARRANTY. READ THE PRODUCT WARRANTY CONTAINED IN THIS MANUAL AND REMEMBER TO FILL
OUT AND RETURN TO THE MANUFACTURER ALL RELEVANT WARRANTY CARDS AND CERTIFICATES.
SHOULD YOU HAVE ANY QUESTIONS, PLEASE CONTACT YOUR LOCAL DEALER OR REFER TO THE
GETTING SERVICE FOR YOUR WATER HEATER SECTION OF THIS MANUAL.
SAVE THIS MANUAL FOR FUTURE REFERENCES.
For your records, write the model and serial number here:
Model # ________________________________
Serial # ________________________________
54000006
© 2011 Giant Factories Inc. Printed in Canada
OWNER'S MANUAL
This water heater IS NOT design certified for
installation outdoors.
• DO NOT STORE, use gasoline or any
• DO NOT USE gasoline, crank case oil or oil
• DO
• DO NOT LEAVE paper or rags close to the
• Immediately call your oil supplier.
Installation and service must be performed by a quali-
fied installer, service agency or the oil supplier.
IMPORTANT
C
WARNING
DANGER
AVERTISSEMENT
WARNING
If the information in these instructions is not
DANGER
entirely followed, a fire or explosion may
result causing property damage, personal
injury or death.
AVERTISSEMENT
other flammable vapours or liquids in the
vicinity of this or any other appliance.
containing gasoline.
NOT
TAMPER with the unit or
controls.
burner or the water heater.
WHAT TO DO IF YOU DETECT OIL
US
ISO 9001
ENREGISTRÉ
ISO 9001
REGISTRED
GI-IM001En-0211
Advertisement
Table of Contents
Related Manuals for Giant Factories OG32
Summary of Contents for Giant Factories OG32
- Page 1 GETTING SERVICE FOR YOUR WATER HEATER SECTION OF THIS MANUAL. ISO 9001 SAVE THIS MANUAL FOR FUTURE REFERENCES. ENREGISTRÉ For your records, write the model and serial number here: Model # ________________________________ ISO 9001 Serial # ________________________________ REGISTRED 54000006 © 2011 Giant Factories Inc. Printed in Canada GI-IM001En-0211...
-
