RESIDENTIAL POWER VENT GAS-FIRED WATER HEATERS
READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING THE INSTALLATION. PROPER INSTALLATION
WILL PROVIDE SAFE & EFFICIENT SERVICE, AND AVOID NEEDLESS EXPENSE NOT COVERED BY THE
WARRANTY. READ THE PRODUCT WARRANTY IN THE OWNER'S MANUAL AND REMEMBER TO FILL OUT
AND RETURN TO THE MANUFACTURER, ALL RELEVANT WARRANTY CARDS AND CERTIFICATES. SHOULD
YOU HAVE ANY QUESTIONS, PLEASE CONTACT YOUR LOCAL DEALER OR REFER TO THE GETTING
SERVICE FOR YOUR WATER HEATER SECTION OF THE OWNER'S MANUAL.
SAVE THIS SUPPLEMENT FOR FUTURE REFERENCES.
For your records, write the model and serial number here:
Model # _____________________________
Serial # _____________________________
54000074
© 2017 Giant Factories Inc. Printed in Canada
(EQUIPPED WITH FVIR TECHNOLOGY)
OWNER'S MANUAL SUPPLEMENT
IMPORTANT
CAUTION
WARNING
This water heater IS NOT design certified for
DANGER
installation in a manufactured (mobile) home or
for installation outdoors.
CAUTION
AVERTISSEMENT
WARNING
ATTENTION
If the information in these instructions is not
DANGER
followed exactly, a fire or explosion may result
causing property damage, personal injury, or
death.
AVERTISSEMENT
DO NOT store or use gasoline or other
flammable vapours and liquids in the vicinity of
ATTENTION
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• DO NOT try to light any appliance.
• DO NOT touch any electrical switch.
• DO NOT use any phone in your building.
• From a neighbour's phone, immediately
call your gas supplier. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
immediately call the fire department at 911.
Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
ISO 9001
ENREGISTRÉ
R
R
ISO 9001
REGISTRED
GI-AX003En-0217
