USER MANUAL
Longo programmable controller
LPC-2.CA1 special module
Version 2
SMARTEH d.o.o. / Trg tigrovcev 1 / 5220 Tolmin / Slovenia / Tel.: +386(0)5 388 44 00 / e-mail: info@smarteh.si / www.smarteh.si

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPC-2.CA1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Smarteh LPC-2.CA1

  • Page 1 USER MANUAL Longo programmable controller LPC-2.CA1 special module Version 2 SMARTEH d.o.o. / Trg tigrovcev 1 / 5220 Tolmin / Slovenia / Tel.: +386(0)5 388 44 00 / e-mail: info@smarteh.si / www.smarteh.si...
  • Page 2 Longo programmable controller LPC-2.CA1 special module Written by SMARTEH d.o.o. Copyright © 2012, SMARTEH d.o.o. User Manual Document Version: 002 July 1, 2012...
  • Page 3 Vibrations and climatic-mechanical: EN 60068-2-6, EN 60068-2-27, • EN 60068-2-29 Smarteh d.o.o. operates a policy of continuous development. Therefore we reserve the right to make changes and improvements to any of the products described in this manual without any prior notice.
  • Page 4: Table Of Contents

    Longo programmable controller LPC-2.CA1 special module Longo programmable controller LPC-2.CA1 special module 1 DESCRIPTION...................1 2 FEATURES..................2 3 OPERATION..................3 3.1 Parameters................3 4 INSTALLATION..................4 4.1 Connection scheme..............4 4.2 Mounting frame selection............6 4.3 Mounting instructions..............7 4.4 Module labeling................9 5 TECHNICAL SPECIFICATIONS..............10 6 CHANGES ..................11...
  • Page 5: Description

    Longo programmable controller LPC-2.CA1 special module 1 DESCRIPTION LPC-2.CA1 RFID reader is intended to be used as an identity verification device at room entrance. Module also provides display for four different messages and requests, usually activated from other module inside the room. This messages are convenient to notify personnel (e.g. occupied, do not disturb, SOS, room service).
  • Page 6: Features

    Longo programmable controller LPC-2.CA1 special module 2 FEATURES Figure 1: LPC-2.CA1 special module Table 1: Technical data RFID reader LEDs for showing activated messages & requests: occupied, do not disturb, room service, SOS OK “ √ ” LED FAULT “ X ” LED...
  • Page 7: Operation

    Longo programmable controller LPC-2.CA1 special module 3 OPERATION Operation of the CA1 module is also dependent on parameters received on RS485 communication channel. Reader RFID field is active always when module is powered up. If tag is put inside RFID field, reader tries to resolve RFID tag code.
  • Page 8: Installation

    Longo programmable controller LPC-2.CA1 special module 4 INSTALLATION 4.1 Connection scheme Figure 2: Connection scheme...
  • Page 9 Longo programmable controller LPC-2.CA1 special module Table 2: K1 K1.1 Ground K1.2 10 – 24 VDC Power supply input K1.3 RS485 A Data receive/send line A K1.4 RS485 B Data receive/send line B Table 3: LEDs & Buttons On: request active...
  • Page 10: Mounting Frame Selection

    Master ● Frames of other vendors most probably suits as well, but they were not verified by Smarteh. Before installation verify compatibility of non listed frames. Module housing has a fin on each side, which can be easily removed with knife cutter or pliers. This adaptation enables housing to be build in various frame formats with two different depths.
  • Page 11: Mounting Instructions

    Longo programmable controller LPC-2.CA1 special module 4.3 Mounting instructions Figure 4: Housing dimensions Dimensions in millimeters. • All connections, module attachments and assembling must be done while module is not connected to the main power supply. Module should not be mounted outdoors.
  • Page 12 Longo programmable controller LPC-2.CA1 special module 1. Set the correct RS485 address (S1 switch) for LPC-2.CA1 (refer to the Table 4). 2. Connect interconnection cable to the connector K1. Max. allowed tractive force is 30 N. 3. Put the LPC-2.CA1 in mounting frames 4.
  • Page 13: Module Labeling

    S/N: CA1-S9-1000000003 is the serial number. • CA1 – short product name, • S9 – user code (test procedure, e.g. Smarteh person xxx), • 10 – year (last two cyphers) • 00000003 – current stack number; previous module would have the stack number •...
  • Page 14: Technical Specifications

    Longo programmable controller LPC-2.CA1 special module 5 TECHNICAL SPECIFICATIONS Table 6: Technical specifications Power supply from MCU Interconnection connector type RJ12 6/6 Power consumption RFID type EM4100, 125kHz, Manchester 64, read only Max. reading distance 4 cm Dimensions (W x H x D)
  • Page 15: Changes

    Longo programmable controller LPC-2.CA1 special module 6 CHANGES The following table describes all the changes to the document. Date Description 1.7.2012 CGP General update. 1.1.2010 The initial version, issued as LPC-2.CA1 module UserManual.
  • Page 16: Notes

    Longo programmable controller LPC-2.CA1 special module 7 NOTES...
