Page 1: Instruction Manual
DSE 2 PLUS Dual HD Digital Signage Encoder INSTRUCTION MANUAL Model Item # Description DSE 2 PLUS 1002583 HD Encoder with QAM Output 937-746-4556 www.rldrake.com © 2015 R.L. Drake Holdings, LLC. Rev: 031915 P/N 651232800B... - Page 2 We recommend that you write the following information in the spaces provided below. Purchase Location Name: Purchase Location Telephone Number: DSE 2 PLUS Serial Number: This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Reverse engineering or disassembly is prohibited.
-
Page 3: Table Of Contents
Table of Contents CAUTION STATEMENTS ................................. 4 IMPORTANT SAFETY INSTRUCTIONS ..........................4 SPECIFICATIONS ..................................6 INSTALLATION & POWER-UP ..............................7 GENERAL DESCRIPTION & FEATURES ..........................8 REAR PANEL OPERATION ..............................9 LOGIN SCREEN ..................................10 STATUS TAB ....................................11 ENCODER TAB ..................................12 CHANNELS TAB .................................. -
Page 4: Caution Statements
Accessories: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or DSE 2 PLUS | 3 Water and Moisture: Do not use this product near water—for example, near a bathtub, wash bowl, kitchen sink or laundry tub; in a wet basement;... - Page 5 11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the product's operating instructions.
-
Page 6: Specifications
Specifications ENCODER - VIDEO (Specifications are per Encoder) Video Inputs: VGA (with pass-through to monitor), HDMI (non-HDCP Copy Protected), Component (Y-Cr-Cb), Composite (via Y-Input for 480i) Video Resolution Modes: 480i (640x480 / 720x480 @ 30 fps), 480p (640x480 / 720x480 @ 60 fps), 720p (1280x 720 @ 60 fps), 1080i (1920x1080 @ 30 fps) Video Input Resolution Detection:... -
Page 7: Installation & Power-Up
............................15 within the product's enclosure that may be of The DSE 2 PLUS is designed to be 1RU 19" rack mountable in the close proximity to a 120 VAC – 60 HZ power plug............................18 sufficient magnitude to constitute a risk of electric .............................. -
Page 8: General Description & Features
General Description & Features The DSE 2 PLUS encodes up to two uncompressed programs from devices with HDMI (non HDCP encrypted), High- Resolution Component Video, Composite or VGA outputs. The DSE 2 PLUS encodes the incoming programs to MPEG-2 or MPEG-4/H.264 compressed video. An internal multiplexing QAM modulator and low-noise upconverter allows programs to be combined with existing digital and or analog programming. -
Page 9: Rear Panel Operation
Rear Panel Operation 11 15 16 17 RF Output: This type “F” connector is a high level (+29.5 dBmV to +45 dBmV), agile 5 to 1002 MHz, multiplexed output from the DSE2 Plus RF output section. DC Power Connector: This connector provides the means for connection to the 5 VDC output of the supplied external power supply. -
Page 10: Login Screen
(Chrome or Firefox recommended). Before you can communicate with the unit you must configure your computers Local Area Network connection to confirm with the DSE 2 Plus default IP of 172.16.80.1. To do so, follow these steps: Connect an Ethernet cable from your computer to the Ethernet connection on the rear panel of the DSE 2 Plus. -
Page 11: Status Tab
The status tab provides the following information (View only): The hardware version indicates the hardware version of the DSE 2 Plus The Uptime of the unit (days, hours, minutes, and seconds), which can be set on the System tab under Unit Description. -
Page 12: Encoder Tab
Encoders Tab The Encoders tab allows you to set each encoder's individual parameters. Select an encoder module from the drop-down menu and the appropriate setting selections will be displayed. www.rldrake.com 937.746.4556 |... -
Page 13: Channels Tab
Channels Tab The Channels tab provides an interface to configure the virtual channel mappings for this encoder host. If PSIP is enabled, this page will display a screen that looks as shown below; for each encoder output, the MPEG program number can be modified, along with the Major and Minor channel numbers. -
Page 14: Output Configuration Tab
Output Configuration Tab The Output tab provides an interface to set all modulator output settings for the unit. System Configuration Tab The System Tab allows you to set a unique IP address for remote access and monitoring. Pressing the rear panel IP reset button will enable the default IP 172.16.80.1. -
Page 15: Firmware Update Tab
Firmware Update Tab This tab uploads the newest available firmware for the DSE 2 PLUS and deploys firmware to the unit. While the firmware update tab is actively updating; the logging information and instructions are provided. When the update is completed, the unit will automatically reboot. -
Page 16: Catv Channel Frequencies
CATV Channel Frequencies CABLE TV CHANNELS CABLE TV CHANNELS CABLE TV CHANNELS CABLE TV CHANNELS Channel Center of Channel Center of Channel Center of Channel Center of Number Number Number Number Channel Channel Channel Channel EIA/NCTA EIA/NCTA EIA/NCTA EIA/NCTA Frequency Frequency Frequency Frequency... -
Page 17: Broadcast Tv & T Channel Frequencies
Broadcast TV & T Channel Frequencies VHF BROADCAST CHANNELS UHF BROADCAST CHANNELS Channel Center of Channel Channel Center of Channel Frequency (MHz) Frequency (MHz) Number Number T CHANNELS Channel Center of Channel Frequency (MHz) Number 8.75 14.75 20.75 26.75 32.75 38.75 44.75 50.75... -
Page 18: Service
Manual before calling or writing - this could save unnecessary phone charges. Please do not return the product without calling Drake Service and following the steps above first; it is preferred to help troubleshoot the problem over the phone (or by Email) first, saving you both time and money. -
Page 19: Warranty
(c) A detailed description of the problem, including details on the electrical connection to associated equipment and the list of such equipment. (3) Deliver the product to the R.L. DRAKE LLC or the nearest authorized service facility, or ship the same in its original container or equivalent, fully insured and shipping charges prepaid. - Page 20 R.L. DRAKE HOLDINGS, LLC Sales: 937-746-4556 • Support: 937-746-6990 • Fax: 937-806-1510 www.rldrake.com...
