Dimplex XL12N Installation Instructions Manual

Dimplex Ultra-Slim Storage Heaters
Models XL12N, XL18N, XL24N
Twin Sensor Models XLS12N Automatic,
XLS18N Automatic, XLS24N Automatic
IMPORTANT
These instructions should be read carefully and retained for future reference.
Note also the information given on the appliance.
This heater is VERY HEAVY. In order to maintain stability
and to ensure its future safety in use, it is essential that
the heater is FIXED SOUNDLY TO A WALL and that the
feet are mounted on a FIRM, LEVEL SURFACE. Care
should be taken to avoid irregular surfaces, such as may
result from tiled surrounds partially protruding under the
heater. It is important that the following instructions are
strictly followed.
IT IS IMPORTANT THAT THE FIXING DEVICE CHOSEN IS
APPROPRIATE TO THE WALL MATERIAL TO WHICH THE
HEATER IS BEING FIXED. SOME MODERN INTERNAL
BUILDING MATERIALS ARE VERY LOW DENSITY BLOCK
AND REQUIRE SPECIALISED FIXING DEVICES TO
PROVIDE A SAFE, SECURE INSTALLATION.
THE HEATER MUST BE INSTALLED WHERE IT IS IMPOSSIBLE
FOR SWITCHES AND OTHER CONTROLS TO BE TOUCHED
BY A PERSON USING A BATH OR SHOWER.
Connection to a 30 amp Ring Circuit
XLN/XLSN STORAGE HEATERS SHOULD NOT BE CONNECTED TO A 30 AMP RING CIRCUIT.
XL/XLS24N STORAGE HEATERS SHOULD NOT BE CONNECTED TO A FUSED SPUR.
A means for disconnection must be incorporated in the fi xed wiring by a double pole switch with a contact
separation of a minimum of 3mm and in accordance with the current IEE Wiring Regulations.
IMPORTANT - Due to the newness of materials the heater will produce a slight smell for the fi rst few days of operation.
ROOMS MUST BE WELL VENTILATED AND YOUNG CHILDREN, CAGED BIRDS, OR PERSONS WITH RESPIRATORY
COMPLAINTS MUST NOT REMAIN IN CLOSE PROXIMITY TO THE HEATER DURING THE COMMISSIONING PERIOD.
To commission the heater set both controls to maximum and leave for a minimum of 48 hours, after this period the controls
should be adjusted for everyday use - see operating instructions.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision for instruction concerning use of the appliance
by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
Bricks are in packs of two.
The pack catalogue
number is XT 8300
This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
XL12/XLS12N - 12kWh
8 Bricks (4 Packs)
These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC

Installation Instructions

The installation of this appliance should be carried out by
competent personnel and be in accordance with the current
IEE wiring regulations. For the assembly of the heater tools
required are a No. 2 pozidriver, an electrical screwdriver
with a 4mm wide blade and a 8mm AF open ended or box
spanner. A small mirror will aid insertion of the front panel
retaining screws.
Only Heat Resisting Cable (min. rating T85) should be used.
DO NOT COVER OR OBSTRUCT the surfaces of the
appliance.
DO NOT INSTALL the heater immediately below a fi xed
socket outlet.
DO NOT POSITION under windows where curtains may
contact the heater. (See minimum clearances, stage 6).
DO NOT PLACE OBJECTS in contact with the heater.
If, during any reassembly of the heater, a part of the thermal
insulation shows damage or deterioration which may impair
safety, it should be replaced with an identical part.
XL18/XLS18N - 18kWh
12 Bricks (6 Packs)
(96513 Iss. 21)
XL24/XLS24N - 24kWh
16 Bricks (8 Packs)
