Topfield TF 7710 HTCI User Manual

Topfield TF 7710 HTCI User Manual

High definition digital terrestrial receiver common interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TOPFIELD
TF 7710 HTCI

User Guide

High Definition
Digital Terrestrial Receiver
Common Interface

Advertisement

Table of Contents
loading

Related Manuals for Topfield TF 7710 HTCI

Summary of Contents for Topfield TF 7710 HTCI

  • Page 1: User Guide

    TOPFIELD TF 7710 HTCI User Guide High Definition Digital Terrestrial Receiver Common Interface...

  • Page 3: Table Of Contents

    Contents iii Contents 1 Introduction Features ....... Controlling the digital receiver .
  • Page 4 iv Contents 3 Preference Settings Language settings ......16 Video and audio settings ..... . 18 3.2.1 Colour model .
  • Page 5 Contents v 6 Listing Services Editing the services list ..... . . 36 Editing the favourite list ..... . 38 How to use on-screen keyboard .

  • Page 7: Introduction

    Chapter 1 Introduction The TF 7710 HTCI digital receiver is fully compliant with the international Digital Video Broadcasting (DVB) standard, and can receive digital broadcasts. For its operation you need an antenna, which must be installed appropriately. NOTE In general we equate a channel with a frequency. Unlike ana- logue broadcasts, however, digital broadcasts are not all as- signed to their own frequencies;...

  • Page 8: Controlling The Digital Receiver

    2 Introduction • You can create favourite lists of your favourite services. • You can view information about the current television or radio programme. • Has an electronic programme guide that provides an overview of scheduled programmes. • You can update the firmware of the digital receiver to the latest version, provided by the manufacturer.

  • Page 9: The Front Panel

    1.2 Controlling the digital receiver 3 1.2.1 The front panel The front panel of the digital receiver has buttons to control the digital receiver, and specific lamps and a display to indicate its status. The following indicates what they mean. TV/STB REMOTE STANDBY...

  • Page 10: The Remote Control

    4 Introduction 1.2.2 The remote control button switches the digital re- ceiver between standby mode and operation mode. pauses live television. changes video resolution. V.Format See § 3.2.4 for more details. Numeric buttons are used to en- ter a service number for service change or to specify values for menu options.

  • Page 11: What Is Common Interface

    1.3 What is common interface? 5 is not used in this model. mutes the sound. Press again to switch it back on. changes aspect ratio. See § 3.2.3 for more details. switches between television services and radio ser- vices. displays the favourite lists. is used to select a subtitle track.
  • Page 12 6 Introduction 1. Purchase a conditional access module and a subscription card for the pay service you want to watch. 2. Insert the subscription card into the conditional access module. 3. Insert the conditional access module into a common in- terface on the front of the digital receiver.

  • Page 13: Setup

    Chapter 2 Setup 2.1 Unpacking Before going any further, check that you have received the following items with your digital receiver. • Remote control unit • Two batteries for the remote control (AAA 1.5 V) • A copy of this user guide NOTE Accessories may vary according to your local area.
  • Page 14 8 Setup • The wall outlet should be near the equipment. Do not run an extension lead to the unit. • Do not expose the digital receiver to any moisture. The digital receiver is designed for use indoors only. Use dry cloth when cleaning the digital receiver.

  • Page 15: Rear Panel Connections

    2.3 Rear panel connections 9 2.3 Rear panel connections The TF 7710 HTCI has some connections on the back panel. VIDEO RF LOOP YPbPr SCART AUDIO HDMI S/PDIF RS-232 Check what connections your television set has in comparison with the digital receiver.

  • Page 16: Connecting Up Your Digital Receiver

    10 Setup VCR Audio and video input/output socket for the video cassette recorder or suchlike. S/PDIF Dolby digital output socket for the audio system. RS-232 Serial port for firmware update and data transfer. Table 2.3: Connectors specifications HDMI High definition video output Left &...

  • Page 17: Connecting The Antenna

    2.4 Connecting up your digital receiver 11 2.4.1 Connecting the antenna Whatever sort of connection you have be- tween the digital receiver and the television, you need to connect the digital receiver to your television antenna so that it can receive digital television services.
  • Page 18 12 Setup To use the HDMI connector If you have a high definition television set, you should use a HDMI cable for best re- sults. Plug one end of the cable into the HDMI socket on the digital receiver, and the other end into the matching socket on your televi- sion.
  • Page 19 2.4 Connecting up your digital receiver 13 To use the component video connector You will need to obtain a component video ca- ble (RCA cable) to use the component video connector. Plug one end of the cables into the Y (green), Pb (blue) and Pr (red) sockets on the digital receiver, and the other end into the matching sockets on your television.

  • Page 20: Connecting To Your Video Cassette Recorder

    14 Setup To enjoy Dolby digital audio, your televi- sion or audio system must be able to decode Dolby digital audio, and you will need to ob- tain a S/PDIF cable. Plug one end of the cable into the S/PIDF socket on the digital receiver, and the other end into the matching socket on your audio system.

  • Page 21: Powering On And Checking Picture

    2.5 Switching on for the first time 15 used batteries. The manufacturer accepts no liability for the damage resulting from leaking batteries. NOTE Batteries, including those which contain no heavy metals, may not be disposed of with household waste. Please dispose of used batteries in an environmentally sound manner.

  • Page 22: Preference Settings

    16 Preference Settings Chapter 3 Preference Settings 3.1 Language settings You can select the language in which the menu would be dis- played. In addition to that, you can select which language of au- dio track and of subtitle track should be output.
  • Page 23 3.1 Language settings 17 Subtitle language Set the 1st Subtitle Language option and the 2nd Subtitle Lan- guage option to your desired languages. When you watch a programme, if the programme has a subtitle track of the lan- guage that is designated for the 1st Subtitle Language, it will be displayed.

  • Page 24: Video And Audio Settings

    18 Preference Settings 3.2 Video and audio settings You have to configure the video and audio settings appropriately to your television set and other appliances. Select the System Setting A/V Output Setting menu. You should see a screen like the left figure.

  • Page 25: Television Aspect Ratio

    3.2 Video and audio settings 19 playback. But if the option is set to External A/V, the digital receiver will not pass the video automatically. To pass it, you have to press the button. 3.2.3 Television aspect ratio If you have a wide-screen television, set the TV Aspect Ratio option to 16:9.

  • Page 26: Sound Mode

    20 Preference Settings Set the Video Format option as you desire. If you set this option to 576P, the digital receiver will present even high definition programmes in resolution of 576. On the contrary, if you set it to 1080I, the digital receiver will present even standard definition programmes in resolution of 1080.

  • Page 27: Local Time Setting

    3.3 Local time setting 21 The digital receiver can output two types of digital audio sig- nals via the S/PDIF connector. One is an encoded signal, and the other is a decoded signal. If your digital audio system does not have a Dolby Digital decoder, you have to set the Dolby Digital option to PCM.
  • Page 28 22 Preference Settings Table 3.1: Time offset table Time offset City 12:00 Eniwetok, Kwajalein 11:00 Midway Island, Samoa 10:00 Hawaii 09:00 Alaska 08:00 Pacific Time US, Canada 07:00 Mountain Time US, Canada 06:00 Central Time US, Canada, Mexico City 05:00 Eastern Time US, Canada, Bogota, Lima 04:00 Atlantic Time Canada, La Paz...
  • Page 29 3.4 Parental control 23 Select the System Setting Parental Control menu. should see a screen like the left figure, and you will be asked your Personal Identifica- tion Number (PIN). The number is initially set to ‘0000’. If you wish to block 15 or above rated programmes, set the Censorship option to 15 (age).

  • Page 30: Adjusting The On-Screen Display

    24 Preference Settings 3.5 Adjusting the on-screen display You can adjust the transparency level of the on-screen display. Select the System Setting menu and set the OSD Transparency option as you desire. Its available range is from 0 to 50 percent. You can adjust the display time of the information box.

  • Page 31: Service Search

    Chapter 4 Service Search After connecting up the digital receiver, you will need to per- form a service search. 4.1 Searching broadcasting services To perform service search, select the Installation Service Search menu. You should see a screen like the left figure. If you have an antenna booster, you should set the Antenna Sup- ply 5V option to On to supply...

  • Page 32: Resetting To Factory Settings

    26 Service Search transponder. To do that, set the Search Mode option to Manual, and then at the Channel option select your desired transponder. The number ranges from 5 to 12 in VHF and 21 to 69 in UHF. To search one service of a transponder, set the Search Mode option to Advanced, and at the PID option specify the PIDs of your desired service with the numeric buttons.

  • Page 33: Daily Usage

    Chapter 5 Daily Usage 5.1 Volume control Use the buttons to alter the volume to a com- fortable level. You may need to adjust the volume on your television set too. To temporarily switch off the sound, press button. Press it again to restore the sound to previous level.
  • Page 34 28 Daily Usage On the services list, you can see the service information: • Service number and name • Transponder information A dollar sign ($) may be marked on some entries, indicating pay service. To watch pay services, you need the subscription card.

  • Page 35: The Favourite Services List

    5.2 Watching television 29 • To change the name of the highlighted service, select the Rename option; then the on-screen keyboard appears, with which you can enter a new name. See § for how to use the on-screen keyboard. • You can prevent other family members from watching the highlighted service by setting the Lock option to Locked.
  • Page 36 30 Daily Usage To display the favourite lists, press the button. should see a screen like the left figure. As you move the high- light bar up or down on the favourite group list at the left box, favourite services belong- ing to the highlighted group are listed on the right box.

  • Page 37: Viewing Programme Information

    5.2 Watching television 31 5.2.3 Viewing programme information Pressing the button displays the information box, on which you can see all of the following: • Service number and name • Transponder information • Signal level and quality • Programme name •...

  • Page 38: Selecting Audio Tracks

    32 Daily Usage 5.2.4 Selecting audio tracks Some programmes are provided with audio tacks in one or more languages. Pressing the button displays available au- dio tracks. Once you select an audio track, it will be sounded. In addition, you can enjoy audio tracks in four sound modes: Stereo, Mono, Left or Right.
  • Page 39 5.3 Viewing electronic programme guide 33 Pressing the button dis- GUIDE plays the electronic programme guide, on which you can see the following: • Scheduled programmes • programme summary • Broadcasting date • Broadcasting time To see detailed information of a desired programme, put the highlight bar on your choice with the button and press the...

  • Page 40: Watching Multifeed Programme

    34 Daily Usage 5.4 Watching multifeed programme Some broadcasts such as sports channels can provide a variety of perspectives on a programme at a same time. We call it a multifeed programme. You can select and watch a perspective you prefer. If a multifeed programme is provided on the current service, the multifeed symbol ( ) will be marked on the information...
  • Page 41 5.5 Making timer events 35 2. Set the Service option to the service which provides the programme you want. Pressing the button on this option displays a services list, from which you can select your desired service. 3. There are five timer modes: One Time means literally ‘one time’.

  • Page 42: Listing Services

    36 Listing Services Chapter 6 Listing Services 6.1 Editing the services list You would have got the services list after service search. You can rename, move, lock or delete service entries on the services list. Select the Organizing Svc/Fav Organizing Services menu. You should see a screen like the left figure.
  • Page 43 6.1 Editing the services list 37 To edit the radio services list, press the button; then radio service entries will be listed on the right column. To switch back to the television services list, press it again. To change the name of a service, select the Rename and select a desired service;...

  • Page 44: Editing The Favourite List

    38 Listing Services Provider by broadcaster 6.2 Editing the favourite list You can make your own favourite services list. In fact, you can define multiple favourite services lists, each being a ‘group’ of chosen services. Select the Organizing Svc/Fav Organizing Favorites menu. You should see a screen like the left figure.

  • Page 45: How To Use On-Screen Keyboard

    6.3 How to use on-screen keyboard 39 1. Put the highlight bar on a desired group entry in the group list and press the button to select it. The high- light bar then moves to the services list. 2. To add a service to the selected group, put the highlight bar on a desired service entry and press the button.

  • Page 46: Transferring Receiver Data

    40 Listing Services To delete a letter, put the cursor to the right of the desired letter on the input line and then select the Del key. You must select the Save key to complete naming; otherwise, if you press the button, it will not be named.

  • Page 47: Firmware Update

    Chapter 7 Firmware Update The digital receiver has a stable and convenient firmware to use. However, a new firmware may be released to improve the digital receiver. You can get the latest firmware and an update utility which runs on most versions of Windows from the Topfield website, 7.1 Checking the firmware information You have to check the firmware...
  • Page 48 42 Firmware Update NOTE You can only update with firmwares of which system identifi- cation is identical to that of yours. Otherwise you will fail in firmware update.

  • Page 49: From A Usb Memory Device

    7.2 From a USB memory device 43 7.2 From a USB memory device If you have a USB memory stick, you can update the firmware from it by performing the following steps: 1. Download a new firmware from the Topfield website. 2.

  • Page 50: From Your Computer Via Rs-232 Port

    44 Firmware Update 7.3 From your computer via RS-232 port It is possible to transfer a new firmware to the digital receiver from your computer by connecting them with a RS-232 cable. You need TFD-Down, a firmware transfer utility for this, which is available from the website, To update the firmware with this method, perform the follow- ing steps:...

  • Page 51: From Another Digital Receiver Via Rs-232 Port

    7.4 From another digital receiver via RS-232 port 45 7.4 From another digital receiver via RS-232 port It is possible to transfer the firmware from the digital receiver to another same digital receiver by connecting them with a RS- 232 cable. To update the firmware with this method, perform the following steps: 1.

  • Page 52: Index

    46 INDEX Index 16:9, Date, 16:9 Display Format, Default, 29, 1st Audio Language, Delete, 29, 1st Subtitle Language, Dolby Digital, 2nd Audio Language, download, 2nd Subtitle Language, Duration, 4:3, DVB, A/V Output Setting, Electronic Programme Guide, Access Control, Every Day, Add to Fav, Every Weekday, Advanced,...
  • Page 53 Lock, 29, specifications, 8, Start Search, Manual, stereo, Menu Language, subtitle, Mode, 21, System ID, mono, System Setting, Move, multifeed, teletext, television services list, NEW, TFD-Down, No block, time format, normal-screen television, Time Offset, Time Setting, 21, One Time, timer list, Organizing Favorites, Timer Setting, Organizing Services,...
