13 MEMORY ADJUSTABLE JUMBO
DISPLAY CALLER ID TELEPHONE
OPERATING INSTRUCTIONS
•
CALLER ID SHOWS YOU CALLER'S NAME & NUMBER
•
81 NAME & NUMBER CALLER ID MEMORY
•
TONE/PULSE SWITCHABLE DIALING
•
AUTOMATIC TIME & DATE DISPLAY
•
ONE-TOUCH CALLER ID CALL BACK
•
3 ONE-TOUCH SPEED DIAL BUTTONS
•
10 TWO-TOUCH SPEED DIAL MEMORY LOCATIONS
•
WALL/DESK USABLE
•
REQUIRES 4 "AA" BATTERIES
TO USE THE CALLER ID FEATURES OF THIS PHONE, YOU MUST
SUBSCRIBE TO CALLER ID SERVICE FROM YOUR PHONE COMPANY,
NOTE: READ AND FOLLOW THESE INSTRUCTIONS BEFORE USING YOUR TELEPHONE
IB-PH5560-WC-E-040505.pmd
MODEL PH-5560
AND REMEMBER TO INSTALL BATTERIES.
1
(NOT INCLUDED)
IB-PH5560-WC-E-040505
4/8/2005, 10:49 AM
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Durabrand H-5560
Summary of Contents for Durabrand H-5560
-
Page 1: Operating Instructions
TO USE THE CALLER ID FEATURES OF THIS PHONE, YOU MUST SUBSCRIBE TO CALLER ID SERVICE FROM YOUR PHONE COMPANY, AND REMEMBER TO INSTALL BATTERIES. NOTE: READ AND FOLLOW THESE INSTRUCTIONS BEFORE USING YOUR TELEPHONE IB-PH5560-WC-E-040505.pmd MODEL PH-5560 (NOT INCLUDED) -
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions Important Telephone Company & FCC Information Location of Controls Getting Started Step 1: Checking the Package Contents Step 2: Powering the Phone Step 3: Telephone Installation Step 4: Setting up the Telephone Basics Choosing Tone or Pulse Dialing... -
Page 3: Important Safety Instructions
There may be a remote risk of electric shock from lightning. 10 . Do not use the telephone to report a gas leak in the vicinity of the leak. 11. Do not allow anything to rest on the telephone cord. Do not locate this product where the cord will be damaged by persons walking on it. -
Page 4: Important Telephone Company & Fcc Information
The REN is useful to determine the quantity of devices you may connect to your telephone line and still have all of those devices ring when your telephone number is called. In most, but not all areas, the sum of the REN’s of all devices connected to one line should not exceed five (5.0). To be certain of the number of devices you may connect to your line, as determined by the REN, you should contact your local telephone company to determine the maximum REN for your calling area. -
Page 5: Location Of Controls
14. DISPLAY TAB - used to adjust the position of the display. 15. LINE CORD JACK - insert one end of the telephone line cord here when connecting the telephone. 16. RINGER HI/LOW/OFF SWITCH - adjusts the volume of the ringer or turns off ringer for undisturbed privacy. -
Page 6: Getting Started Step 1: Checking The Package Contents
GETTING STARTED Step 1: Checking the Package Contents Your new PH-5560 jumbo display Caller ID telephone has all the features of a 13 memory telephone plus Caller ID display functions. As you unpack this set, make sure you have the following items in the package. -
Page 7: Step 3: Telephone Installation
You may need to set up the LCD contrast, language, area code, time and date for your telephone when you install the batteries for the first time or when you move to an area that has a different area code. This is necessary because the phone must distinguish local or long distance calls to properly dial calls from the Caller ID list. -
Page 8: Basics
DELETE button to accept. You do not have to set up the Time and Date because the telephone company will automatically update this with your Caller ID when your phone rings (twice or more). -
Page 9: Making And Receiving Calls
Useful for call waiting or getting a new dial tone. If you are using the telephone when a new call comes in (you will hear a beep or click), press the FLASH button on your telephone, you will put on hold the parter you are having the conversation with and you will be able to talk to the new caller, after you finish the conversation with the 2nd caller, press FLASH button to return to the 1st call. -
Page 10: Telephone Features Memory Dialing
TELEPHONE FEATURES Memory Dialing You can quickly dial the numbers you stored into the 3 one-touch speed dial buttons or 10 two-touch speed dial memories. STORING PHONE NUMBERS INTO MEMORY 1. Press the STORE button. 2. Dial the phone number you want to store. You can store up to 22 digits (including a TONE ( ) and a PAUSE (REDIAL/PAUSE), each of which is counted as one digit). -
Page 11: Caller Id Features Understanding The Caller Id Service
The caller’s phone number and/or name will not appear in the following cases: - The call is made through a telephone c ompany which does not offer Caller ID service (including international calls). The display will show “ UNAVAILABLE ” . -
Page 12: Calling Back From The Caller Id List
CALLER ID FEATURES Calling back from the Caller ID List A. When the Handset is on the Base. 1. Display the phone number you want to call back using the UP or DOWN button. 2. Press the CALL BACK button. the display will show “PICKUP OR ADJ”. 3. -
Page 13: Using Message Waiting/Mailbox
Your PH-5560 will only respond to FSK type of message delivery. 1. If the message is sent by the telephone company which is preceded by a ring, the display will show “MESSAGE WAITING” and the message waiting symbol display and flash. -
Page 14: Wall Mounting Without A Modular Wall Phone Plate
3. Leave 3 / 16 " (5 mm) of the screws exposed to mount the phone. 4. Place the TELEPHONE BASE on the 2 mounting screws and gently push down to lock into place (anchors and screws are not included). -
Page 15: Trouble Shooting
TROUBLE SHOOTING PROBLEMS The Caller ID display does not show the caller’s information No dial tone Phone does not work Phone does not ring Can not dial Cannot s tore numbers int o memory Caller ID does not work The Caller ID display gets dim or is blank Static noise on line or cannot hear calling party or calling... -
Page 16: Trouble Shooting
Unplug the telephone and try it on another jack in a different room or in a neighbor’s home to see if the phone line is bad or the phone. -
Page 17: Ib-Ph5560-Wc-E
During the initial 1 year period after original purchase, we will service the set that is returned to LENOXX ELECTRONICS CORP., prepaid, at no charge. After the initial 1 year period expires, we will exchange, at no charge, any part that is defective, but will charge for the cost of labor, return postage paid by LENOXX.
