Flashes:
Printing or scanning over wireless LAN. Also flashes while configuring the wireless LAN
connection.
(9) paper output cover
Open to replace the FINE cartridge or remove jammed paper inside the machine.
(10) paper guides
Align with both sides of the paper stack.
(11) front tray
Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same
time, and fed automatically one sheet at a time.
Loading Plain Paper / Photo Paper
Loading Envelopes
(12) front cover
Open to load paper in the front tray.
(13) paper support
Extend to load paper in the front tray.
(14) output tray extension
Open to support ejected paper.
(15) paper output support
Extend to support ejected paper.
(16) paper output tray
Printed paper is ejected.
(17) platen glass
Load an original here.
